Flat Par 7x3W
Copyright triAngle lights
Last updated on Mach 28
triangle.lights@gmail.com
1. INTRODUCTION
Please read this user manual carefully and thoroughly before
operation.
1.1 What is Included
a) 1X flat par 7x3w with lead
b) 1X user manual
Carefully unpack the carton, check the contents to ensure that all
parts are present and in good condition. Contact your supplier if any
part is missing or damaged.
1.2 Safety Instructions
▪ This product is intended for indoor use only!
▪ Always turn off, unplug power and allow fixture to cool before
servicing.
▪ Ensure that fixture is properly grounded.
▪ Please keep this User Guide for future reference.
▪ Always make sure that you are connecting to the proper voltage
and that the line voltage you are connecting to is not higher than that
stated on decal or rear panel of the fixture.
▪ To prevent risk of fire or shock, do not expose fixture to rain or
moisture.
▪ Make sure power cord is never crimped or damaged.
▪ Do not look into the beam from a distance of less than 40 cm (16
2012
th
inches).
WARNING!!! To reduce risk of fire, electric shock, or
injury, follow these important safety instructions
1/8
Copyright 2011 triAngle lights
Advertisement
Table of Contents
Related Manuals for Triangle Lights Flat Par 7x3W
Summary of Contents for Triangle Lights Flat Par 7x3W
- Page 1 1.1 What is Included Flat Par 7x3W a) 1X flat par 7x3w with lead b) 1X user manual Carefully unpack the carton, check the contents to ensure that all parts are present and in good condition. Contact your supplier if any part is missing or damaged.
- Page 2 DMX cables to link the units from DMX IN to DMX OUT. 2.3 AC Power The fixture is designed to work on 100V-240V 50/60Hz. Warning!!! All fixtures must be connected to circuits with a suitable Earth Ground. Copyright 2011 triAngle lights Copyright 2011 triAngle lights...
- Page 3 Up/Down button to set DMX address for the fixture. Similarly, Bxxx for 3CH work under Auto , Static Color mode. Others are to be set Slave mode mode. (A001). 3. Operate the Master fixture to run the whole system. Copyright 2011 triAngle lights Copyright 2011 triAngle lights...
- Page 4 It does matter which way the inputs and outputs are connected. and the environment, ensure that this product is recycled at the end of its life. Disconnect from mains before servicing. N INTRODUCTIO Copyright 2011 triAngle lights Copyright 2011 triAngle lights...
