LED PAR64 18W 6CH LCD SOUND

1 Specifications

Number of LEDs
Power Consumption
Beam angle
Projecting distance
LED Lumen
LED Expected Life
Control system
DMX Channel
Connection
Input Voltage
Operating Voltage
LED Current
Operating temperature
Storage temperature
Dimension
Package Dimension
Housing
Gross Weight

USER MANUAL

18X1W LED R:6, G:6, B:6
30W
25°
15M
80,000 hours
DMX 512
6 Channels
3 pins XLR-sockets
100V~256VAC
24VDC
320mA ±5%
-18° C ~ +40° C (0° F ~ +104° F)
+5° C ~ +30° C (41° F ~ +86° F)
L22*W19*H16CM
20X20X27CM
PLASTIC
2.0kgs±5%
¡
triangle.lights@gmail.com
www.storexp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED PAR64 18W 6CH LCD Sound and is the answer not in the manual?

Questions and answers

Related Manuals for Triangle Lights LED PAR64 18W 6CH LCD Sound

Summary of Contents for Triangle Lights LED PAR64 18W 6CH LCD Sound

  • Page 1: User Manual

    LED PAR64 18W 6CH LCD SOUND USER MANUAL 1 Specifications Number of LEDs 18X1W LED R:6, G:6, B:6 ¡ Power Consumption Beam angle 25° Projecting distance LED Lumen LED Expected Life 80,000 hours Control system DMX 512 DMX Channel 6 Channels...

  • Page 2: Control Modes

    2 Control Modes Select effects using the LCD panel Stand Alone Mode International standard DMX512 signal control Sound Active Light effects change to music Master/Slave Mode Auto Mode 3 LCD Control Panel 1- Menu Push button to return to the Main menu. This is a menu browsing button.
  • Page 3 4 LCD Control in Details Main and Sub Level Menus are shown below: Main Menu Menu Description ADDR A001-A512 DMX address setting RL - - RL00-RL12 Red Dimmer Green and Blue color are not affected, and can stay on GL - - GL00-GL12 Green Dimmer Red and Blue color are not affected, and can stay on...

  • Page 4: Dmx Chart

    5 DMX CHART Channel No. DMX Value Description Master Dimmer 0~255 Must be on for CH2,3,4 and 5 to work Red Dimmer 0~255 CH1 must be on Green Dimmer 0~255 CH1 must be on Blue Dimmer 0~255 CH1 must be on Master Strobe 0~255 Ch1 and at least one of CH2,3 and 4 should be on to work...
  • Page 5 how much you contribute. www.storexp.com triangle.lights@gmail.com...
