AudioControl The Epicenter Plus Owner's Manual

Bass restoration processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Greetings from the rainforest dwellers of the Pacific Northwest. We would like to
congratulate you on your purchase of The Epicenter Plus from AudioControl. As the
name suggests this processor is based on AudioControl's legendary (and patented)
bass restoration circuitry, appropriately named The Epicenter. Whether this is your
first AudioControl product, or you are already a firm believer, the bass restoration
enhancements of The Epicenter Plus will leave you breathless. Extra octaves of deep,
body shivering bass can dramatically increase the enjoyment of your performance
autosound system.
The Epicenter Plus is for audio enthusiasts who want to use their factory-installed
source units so it is equipped with AudioControl's high-impedance, speaker-level
inputs. Additionally, an auxiliary input allows users of factory-installed radios and
portable audio players (like iPods™) to also appreciate the performance of its bass
restoration circuitry.
We are sure that by now the thought of adding The Epicenter Plus to your perfor-
mance autosound system is probably making you salivate. However, we strongly
encourage you to take a few minutes to sit back, grab a beverage of your choice
and read through this manual. Although many autosound enthusiasts feel reading
an "owner's manual" is only for novices, this particular manual may save you some
phone calls during the installation process. It also contains lots of useful facts and
information (and besides, we spent a lot of time writing it)!!
Key Features Of The Epicenter Plus
Here are a few key features that you will find in The Epicenter Plus:
• Patented Bass Restoration Circuitry
• Speaker-Level Inputs for Integration with Factory Audio Systems
• Auxiliary Input for iPod's, MP3 players or Satellite radio tuners
• GTO™ Signal Sensing Inputs for Automatic Turn-on
• Bass Maximization Circuitry
• 12 volt trigger output
• Dash mount control
• PFM Subsonic Filter
• Balanced Pre-amp inputs
What all this means is more bass and better bass from your performance audio
system. Enjoy the ride...
22410 70th Avenue West • Mountlake Terrace, WA 98043 USA
Phone 425-775-8461 • Fax 425-778-3166 • www.audiocontrol.com
Bass Restoration Processor
Owner's Enjoyment Manual
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The Epicenter Plus and is the answer not in the manual?

Questions and answers

Summary of Contents for AudioControl The Epicenter Plus

  • Page 1 (like iPods™) to also appreciate the performance of its bass restoration circuitry. We are sure that by now the thought of adding The Epicenter Plus to your perfor- mance autosound system is probably making you salivate. However, we strongly encourage you to take a few minutes to sit back, grab a beverage of your choice and read through this manual.

  • Page 2: Features And Highlights

    The Auxilia- ry input is easily activated by tapping the dash control knob. You will be happy to know that The Epicenter Plus has a cool blue LED indicator that will light when the Auxiliary input is activated.
  • Page 3 The Epicenter Plus has a high-current 12-volt output (labeled “Remote Out”) that will provide a trigger to these remote devices, when The Epicenter Plus is powered up. Please note that this output is not to be used as the main power for these devices.
  • Page 4 The Epicenter Plus may be too low. Try finding a full range signal or use an AudioControl LC6i to sum the signals together.
  • Page 5 LED indicator above the “Aux Input” will identify when this input is being used. 2. Speaker-level Inputs: If you would like to use The Epicenter Plus with a factory-installed source you will be happy to know that it is equipped with Au- dioControl’s high impedance speaker-level inputs.
  • Page 6 Do not use for system power!! 7. Remote In: Allows The Epicenter Plus to be turned on remotely with a 12- volt signal.
  • Page 7 Figure 3: Inside view of The Epicenter Plus Factory Setting Shipped Options Bass Maximization Voltage 5 volts 5 or 7.5 volts Input Circuit Unbalanced Balanced Ground Isolation Isolated 200 ohm or Ground PFM Subsonic Filter 33Hz 20Hz, 25Hz, 30Hz, 35Hz, 40Hz, 45Hz Optional PFM modules are sold separately.
  • Page 8 Up to this point everything you have read has served to educate you on the operations of The Epicenter Plus. We are sure that you are chomping at the bit to install The Epicenter Plus so we recommend you read the following sections very carefully.
  • Page 9 Remote connector on The Epicenter Plus. Remote Out: If you are going to use the The Epicenter Plus to turn on any external signal processors or amplifiers, connect an 18 to 22 gauge wire from the Remote Out on the The Epicenter Plus to the remote turn-on of the processors or amplifiers.

  • Page 10: System Diagrams

    System Diagrams Figure : Two channel system with equalizer and crossover Figure : Four channel system with crossover page 10...
  • Page 11 Figure : Interfacing with a factory installed radio plus a XS crossover Figure 8: Interfacing with a factory installed radio/amplifier using an AudioControl Li for signal summing page 11...
  • Page 12 Connect the speaker wires to the Speaker-Level Inputs on The Epicenter Plus. Make sure to get your “pluses” and “minuses” connected properly.

  • Page 13: Troubleshooting

    If you still don’t hear any affect, then you need to make sure that you have The Epicenter Plus in the right part of the signal chain. It must be installed BEFORE any crossovers in the system for best, thundering performance.
  • Page 14 No Sound Check the source selection LED’s on The Epicenter Plus chassis and/or the dash control. If you have the auxiliary input selected but you are not using and a secondary source you will get no sound. Tap the dash control to change inputs.
  • Page 15 “...who’s good with electronics”, try to repair your AudioControl product. So go ahead, read this warranty, then take a few days to enjoy The Epicenter Plus before sending in the warranty card and comments.

  • Page 16: Specifications

    ©2008, AudioControl, a division of Electronic Engineering and Manufacturing, Inc. All rights reserved. AudioControl, The Epicenter, The Epicenter Plus, Making Good Sound Better, 6XS, DQT, DQX, DQS, DQXS, DDC, and EQL are all trademarks of Electronic Engineering and Manufacturing, Inc.
