  • Page 1: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instruction 2. Technical Specification 3. Lamp 4. How To Set The Unit 4.1 Control Panel 4.2 Main Function 4.3 Home Position Adjustment 5. How To Control The Unit 5.1 Master/Slave Built-In Preprogrammed Function 5.2 Easy Controller 5.3 iSolution Operation / DMX Controller 5.4 DMX 512 Configuration 5.5 DMX 512 Connection...

  • Page 2: Safety Instruction

    Warning To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or 1. Safety Instruction moisture. Please keep this User Guide for future consultation. If you sell the unit to another Never touch bulb with bare fingers, as it is very hot after using. user, be sure that they also receive this instruction booklet.

  • Page 3: Technical Specification

    - Pan: 540° in 2.8 second. - Tilt: 270° in 1.6 second. - Automatic pan/ tilt position correction DMX Channels - Standard DMX512 signal addressing and can be controlled by any universal DMX controller. 16 Channels: Channel 1 = Pan...

  • Page 4: How To Set The Unit

    By connecting to the 1/4” microphone jack to control the unit for Stand by, Function, and Mode function. Sensitivity To adjust the sound-receiving sensitivity Microphone To receive audio signal for sound activation DMX input/output For DMX512 link, use 3-pin XLR plug cable to link the unit together.

  • Page 5: Main Function

    Use DOWN and UP button to select the (normal) button and the display will blink. Use DOWN and UP button to change the DMX512 address. (2 light show) mode. Once the mode has been selected, press the ENTER...
  • Page 6 the MENU button. Blackout Mode Display normal mode for the fixture putting on the floor. Press the MENU button up to when the is shown on the display. Pressing ENTER Display inversion mode for the fixture fixing under ceiling. button and the display will blink. Use DOWN and UP button to select the (yes blackout) or (no blackout) mode.

  • Page 7: Home Position Adjustment

    5. How To Control The Unit 4.3 Home Position Adjustment You can operate the unit in three ways: Press MENU button for at least 5 seconds into offset mode to adjust the home position, the 1. By master/slave built-in preprogram function functions are shown below: 2.

  • Page 8: Isolution Operation / Dmx Controller

    Press the MENU button up to when the is shown on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to change the DMX512 address. Once the address has been selected, press and keep ENTER button pressed up to when the display stops blinking or storing automatically 8 seconds later.

  • Page 9: Dmx512 Connection

    Connect the unit together in a “daisy chain” by XLR plug from the output of the unit to the input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX512 is a very high-speed signal. Inadequate or damaged cables, soldered joints or corroded connectors can easily distort the signal and shut down the system.

  • Page 10: Troubleshooting

    6. Troubleshooting G. If The pan belt is broken Following are a few common problems that may occur during operation. Here are 1. Turn off the main power. some suggestions for easy troubleshooting: 2. Unscrew all the screws (A) and open the base-housing cover (B). A.

  • Page 11: Fixture Cleaning

    7. Fixture Cleaning Pay attention to the belt tension when install the belt. The cleaning of internal and external optical lenses and/or mirrors must be carried out Please refer to the photos below: periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
