Page 1: Table Of Contents
TABLE OF CONTENTS 1. Safety Instruction 2. Technical Specification 3. Lamp 4. How To Set The Unit 5. How To Control The Unit 6. DMX512 Configuration 7. DMX512 Connection 8. Troubleshooting 9. Maintenance and Cleaning User Guide Professional Entertainment Technology... -
Page 2: Safety Instruction
1. Safety Instruction Warning To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or Please read carefully the instruction, which includes important information moisture. about the installation, usage and maintenance. Never touch bulb with bare fingers as it is very hot after using. WARNING Hot lamp explosion hazard. -
Page 3: Lamp
2.1 Beam Angle 3.1 HID 150W Lamp Installation Or Replacement • Always switch power off before installing or replacing the lamp. Never try to replace the IM-200S-ELC IM-200S-HID lamp when it is hot. • Do not touch the bulb with bare hands. Cleaning the lamp with denatured alcohol and wipe with a lint free cloth when lamp is dirty. -
Page 4: How To Set The Unit
Pressing ENTER Sensitivity button and the display will blink. Use DOWN and UP button to change the DMX512 address. To adjust the sound receiving sensitivity Once the address has been selected, press the ENTER button to setup or automatically DMX input/output return to the main functions without any change after 8 seconds. - Page 5 Sound Mode Channel Mode Press the MENU button up to when the is shown on the display. Pressing ENTER Press the MENU button until the is showing on the display. Pressing ENTER button button and the display will blink. Use DOWN and UP button to select the (8 Channel) or (11 and the display will blink.
-
Page 6: How To Control The Unit
4.3 Home Position Adjust (Led on) or (Led off) mode. Once the mode has been selected, press the ENTER button to setup or automatically return to the main functions without any change after 8 Press MENU button for at least 5 seconds into offset mode to adjust the home position, use seconds. -
Page 7: Dmx512 Configuration
Press the MENU button up to when the is showing on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to change the DMX512 address. Once the address has been selected, press and keep ENTER button pressed up to when the display stops blinking or storing automatically 8 seconds later. -
Page 8: Dmx512 Connection
7. DMX512 Connection The DMX 512 is widely used in intelligent lighting control, with a maximum of 512 channels. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit. -
Page 9: Troubleshooting
8. Troubleshooting G. If The pan belt is broken 1. Turn off the main power. Following are a few common problems that may occur during operation. Here are 2. Unscrew all the screws and open the base-housing cover. some suggestions for easy troubleshooting: 3. -
Page 10: Maintenance And Cleaning
9. Maintenance and Cleaning Maintenance (for HID lamp only): EC Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive Filter, capacitor Ignitor Ballast...
