COMPONENTS
MDC-H6290VTD-24H & 42 (70Ø) / 32 & 40H (90Ø)
1 Lens
2 IR-LED / Heater (Option)
3 Zoom / Focus Lever
4 OSD Joystick (Option)
5 Cable Management Bracket
6 VBS-Extra for connecting to LCD (Option)
MICRODIGITAL
3
1
2 4
5
6
VBS-EXTRA
