350Z Installation Guide Intelligent Video Surveillance GUI Display with USB Mouse Control Please read instructions thoroughly before operation and retain it for future reference. For the actual display & operation, please refer to your DVR in hand. D748_746_744_Quick_V1.1...
IMPORTANT SAFEGUARD CAUTION RISK OF ELECTRIC SHOCK CAUTION: To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of such damages.
2. CONNECTION AND SETUP Before the DVR is powered on, make sure you have installed a hard disk, connected at least one camera and a monitor. For details, please refer to the following sections. Note: The DVR is designed to automatically detect the video system of the connected cameras (NTSC or PAL).
2-2 To install on the second bracket Connect the power connector and data bus connector to the HDD. When connecting the power cable, make sure the cable is passed through the power cable of DVD writer. This is to prevent the HDD power cable from interfering with the fan spinning.
2.5 DVR Power On This device should be operated only with the type of power source indicated on the manufacturer’s label. Connect the indicated AC power cord to the power adapter, and plug into an electrical outlet. The power LED will be on. Note: Before the DVR is powered on, make sure (1) the cameras are connected and power-supplied for the detection of the camera video system to be correct, and (2) a monitor (either LCD or CRT monitor) is connected to the DVR for correct video output detection.
SYSTEM TOOLS BAUD RATE 2400 SYSTEM INFO HOST ID USB BACKUP R.E.T.R DVD BACKUP AUTO KEY LOCK NEVER CLEAR HDD HDD-0 RESET DEFAULT SUBMIT REMOTE CONTROL ID SERIAL TYPE RS485 VIDEO FORMAT NTSC VERSION 1019-1008-1010-1010 EXIT 2.8 Password Setting Right-click to show the main menu, and select “SYSTEM” “TOOLS”...
3) In “CONNECTION”, it shows the examining result for DCCS signal transmission between the DVR and camera. The message is as follows: MESSAGE SHOWN MEANING CHECKING The DVR is checking the DCCS signal transmission between the DVR and camera. The signal transmission is fine and the DCCS function works properly. FAIL The signal transmission is too weak or not available for the DCCS function to work properly.
3. GUI DISPLAY WITH USB MOUSE CONTROL 3.1 Connect USB Mouse Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there’s a mouse icon ( on the screen, indicating the USB mouse is detected properly. Move your mouse to enter the DVR password with the password keypad.
Click to set the system configurations. EVENT INFORMATION Click to enter the event search menu. Click to set CAMERA, DETECTION, ALERT, ADVANCE CONFIG NETWORK, DISPLAY, RECORD, REMOTE, DCCS, IVS & NOTIFY. SCHEDULE SETTING Click to set record timer and detection timer. Main Menu Structure...
Page 12
EVENT RECORD IPS TIMER RECORD IPS PRE-ALARM RECORD OVERWRITE EVENT RECORD ALL CHANNEL KEEP DATA LIMIT (DAYS) REMOTE DCCS CAMERA (Selected Models Only) IVS MODE DISPLAY LINE SENSITIVITY RESET COUNT VIRTUAL FENCE AREA SCENE CHANGE SCENE CHANGE SENSITIVITY NOTIFY GUARD SCHEDULE SETTING...
Press to quickly search the recorded files by event lists: RECORD / MOTION / ALARM / TIME / HUMAN DETECTION / IVS / STATISTIC, or select FULL to show all the event logs. To quickly search the time you want, select “QUICK SEARCH”. For details, please refer to “5.4.1 QUICK SEARCH”...
15) USB port There are two USB ports on the front panel, one for connecting your USB mouse for mouse control, and the other one for connecting your USB flash drive for video backup. Note: It’s not allowed to have two USB mice or two USB flash drives connected on the front panel. Note: For the compatible USB flash drive list, please refer to “APPENDIX 3”...
5. BASIC OPERATION 5.1 Live Page Icon Function Icon Function Icon Function Live audio channel (1~4) Playback audio channel (1~4) Audio channel off Digital zoom on Digital zoom off Timer recording Network disconnected Internet connected LAN connected USB mouse connected USB flash drive / device connected No USB device connected Key lock...
RECORD / MOTION / ALARM / TIME / HUMAN DETECTION / IVS / STATISTIC, or select FULL to show all the event logs. To quickly search the time you want, select “QUICK SEARCH”. For details, please refer to “5.4.1 QUICK SEARCH”...
move your mouse to show the password input keypad, and enter the password of the user level you want. 5.5 Video Output Switch It’s not allowed to have video output simultaneously on a CRT monitor (connected to MONITOR) and LCD monitor (connected to VGA).
APPENDIX 1. SET IPHONE PUSH NOTIFICATION This IVS DVR series supports instant event notifications to your iPhone with our self-developed program, “EagleEyes”, installed. When a man is detected by a human detection camera, the DVR will immediately receive alarm signals and send to your iPhone.
Step2: Give a meaningful title to this IP setting, and enter the IP information needed to access this IVS DVR. Step3: Make sure all the information is correct, and select “Save” on the top right corner to save your setting and return to the address book page.
Select the title you just added, and make sure the button is set to “ON” to enable the Push Notification support of this IVS DVR. Step3: Try to trigger the human detection alarm and see if you will be notified.
Click “SUBMIT” to reset the flow counting number to 0 when the IVS mode is set to “FLOW COUNTING” and activated. VIRTUAL FENCE AREA Click “SETUP” to draw the detection line for IVS, and set the detection direction from left to right, or right to left. This area setting is the detection base for IVS MODE. SCENE CHANGE Select “ON”...
Step1: Go to “VIRTUAL FENCE AREA” to draw a detection line with your mouse, and decide the detection direction by selecting “REVERSE”. Step2: Finish the IVS setting and return to the live view. The IVS icon “ ” will be shown on the status bar. Click it to show the flow counting panel as follows.
Step1: Go to “VIRTUAL FENCE AREA” to draw a detection line with your mouse, and decide the detection direction by selecting “REVERSE”. Step2: Finish the IVS setting and return to the live view. When anyone walks across the detection line, the system will determine his movement is in or out, and: An event happens for anyone walking across the detection line, and “...
A2.2 IVS STATISTICS Click “ ” “ ” to enter the event search menu. Then, select “STATISTIC” LIST QUICK SEARCH CHANNEL RECORD INFLOW EVENT TYPE MOTION OUTFLOW ALARM VIRTUAL FENCE TIME ONE WAY PASS HUMAN DETECTION HUMAN DETECTION MOTION FULL...
