Summary of Contents for Manhattan 208000

  • Page 1: User Manual

    HDMI SwItcH USER MANUAL MODELS 208000 & 208017 MAN-208000/208017-UM-0407-02...
  • Page 2 HD devices, risking damage to ports and expensive cables. With this MANHATTAN HDMI Switch, everything stays connected, accessible and ready to use, making it ideal for use with home theater and dual computer systems.
  • Page 3: Installation

    INStALLAtIoN 1. Using standard HDMI cables, connect the HDMI output port of your video source to the HDMI input port of the switch. Make sure all HDMI sources and the display are turned off before connecting the cables. 2. Plug the 9V power supply into the switch’s power input port. 3.
  • Page 4: Hdmi Connector Pin Assignments

    HDMI coNNEctoR PIN ASSIgNMENtS Pin No. Description Pin No. Description 1 TMDS DATA  + 11 TMDS Clock SHIELD  TMDS DATA  SHIELD 1 TMDS Clock -  TMDS DATA  - 1 CEC  TMDS DATA 1 + 1 RESERVED 5 TMDS DATA 1 SHIELD 15 SCL...
  • Page 5: Troubleshooting

    tRoUbLESHootINg The switch will not operate. 1. Make sure the 9V power adapter is plugged into the switch. 2. Check to see if the LED light is on. No picture or signal; 1. Make sure your video display is HDCP compliant. or poor picture.
  • Page 6: Specifications

    SPEcIfIcAtIoNS • Model 208000: 2 HDMI inputs and 1 HDMI output • Model 208017: 4 HDMI inputs and 1 HDMI output • DDWG and HDCP compliant • Plug and Play; no installation software required • DC 9 V / 500 mA power adapter; remote control (CR2025 lithium battery included)
  • Page 7 NOTES...
  • Page 8 PC Components, Peripherals, Cables ® and Accessories. Ask your local computer dealer for more information or visit us online at www.manhattan-products.com Copyright © MANHATTAN All products mentioned are trademarks or registered trademarks of their respective owners.
