DMX Mode
DMX (Digital Multiplex) is a universal protocol used as a form of
communication between intelligent fixtures and controllers. A DMX
controller sends DMX data instructions from the controller to the
fixture. DMX data is sent as serial data that travels from fixture to
fixture via the DATA "IN" and DATA "OUT" XLR terminals located on
all DMX fixtures.
The Dualex II is a DMX enabled fixture and the DMX mode and
DMX address settings are controlled via the Digital control panel. It
also carries the standard 3-pin XLR connections for DMX use.
To set your fixture for use with a universal DMX controller:
Press the MODE Button and use the UP and DOWN buttons until
you see 'A001' on the screen, press ENTER. Your fixture is now
set in the DMX mode on channel 1 of the DMX universe and is
awaiting input from your DMX controller. Based on a DMX controller
having 16 channels per fixture:
Light 1 in the DMX universe
Light 2 in the DMX universe
Light 3 in the DMX universe
Please consult the manual of your DMX controller for more informa-
tion on addressing fixtures.
Display A001
Display A017
Display A034
Mounting Your Fixture
Your light is designed to be hung from either a Ceiling, DJ Truss
or T-Bar Stand. The bracket comes supplied with a hole to allow
mounting of the fixture.
Always ensure the fixture is tightly fitted to whatever it is your mount-
ing it too. The Bracket thumb wheels can be adjusted and tightned
to place your fixture at a desired position.
Also a safety hook is mounted on the unit. Please be sure to con-
nect a safety chain or safety cable to the hook.
Care and Maintenance
Cleaning your fixture will keep it looking great for many years and
also ensure its long life and trouble free operation. Clean your fixture
with a slightly damp, lint-free cloth. Never use chemicals to clean the
fixture as this could impair its finish. Always make sure the fixture is
powered off before cleaning.
If you need to replace the fuse, always make sure you replace with
the same fuse specification. NEVER attempt to wrap foil around the
fuse.
