F O R Z A 2 5 SP
INSTRUCTIONS
MANUAL
FOR
A
MOTORIZED BACKPACK
SPRAYER
USERS´MANUAL
BN818.002-1002-E/EX
REV.00

Advertisement

loading
Need help?

Need help?

Do you have a question about the FORZA 25 SP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SP Systems FORZA 25 SP

  • Page 1 F O R Z A 2 5 SP INSTRUCTIONS MANUAL MOTORIZED BACKPACK SPRAYER USERS´MANUAL BN818.002-1002-E/EX REV.00...
  • Page 2 Dear Customer: Congratulations for purchasing one of the best motorized sprayers on the market. To obtain best results, we recommend you take a few minutes to read and understand the instructions for using the sprayer, as well as its care, maintenance, and solutions guide to correct any damages that your sprayer could get.
  • Page 3 FEATURES ! ! ! ! ! Double piston pump that supplies constant and sufficient pressure to your sprayer; additionally, it considerably reduces vibrations and pounding. ! ! ! ! ! Centrifugal clutch that gives the pump and the motor independence to ease ignition, filling of the fuel tank, and for other operations.
  • Page 4: Before Ignition

    1.- BEFORE IGNITION 1.1 Fill the fuel tank with gasoline and oil. 4 cycle engines do not require an oil or gasoline mixture. 1.2 Adjust the hose and nozzle connections perfectly. Make sure there are no seals missing. 1.3 Verify that the filter and the tank drain plug are secured before filling it. 1.4 When preparing the mix, add water to half the tank;...
  • Page 5 3.- SPRAYING 3.1 Elect the desired pressure turning the ribbed knob clockwise (high) or counterclockwise (low), deppending on the work to be performed. Remember that to apply herbicides, the pressure must be low. For fungicides, insecticides, and foliaters, higher pressure can be used. 3.2 Hold the spray lance well and begin the spraying operation.
  • Page 6: Maintenance

    5.3 When the equipment will not be in use for some time, empty the fuel tank. 6.- MAINTENANCE 6.1 Disconnect the supply and return hoses from the pump loosening the respective clamps. 6.2 Take the caps off the cylinder, loosening the screws. 6.3 Take the cylinder off of the pump.
  • Page 7 6.5 Take the seals off the cylinders (next to the pump); wash the pieces if necessary. 6.6 Replace the check valves in the same position they were located previously. 6.7 Replace the caps and tighten the screws firmly. COMMON PROBLEMS AND POSSIBLE CORRECTIONS PROBLEM CAUSE SOLUTION...
  • Page 8: Specifications

    SPECIFICATIONS FORZA 25 Model Dimensions (L x A x H) 41x35x64 cm. 16.4x14x25.6 Weight 9.9 Kg. with one gun 22.3 6.7 gallons 25 litres Liquid tank capacity Double piston Type 2.6 GPM 9.6 lts/min. Maximum flow Pump Pressure (BAR) 10-22 BAR (with a limit) Nozzle type NN-D-6 (Wide coverage) .30 GMP 1.16 lts./min.
