Summary of Contents for Metos LL600
- Page 1 HEATED PLATE TYPE: 600, 800 Installation and Operation Manual S/N: 045610/01 Rev.: 2.1...
- Page 3 13.3.2006 Rev. 2.1 Dear Customer, Congratulations on deciding to choose our appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied customer like thou- sands of customers we have around the world. Please read this manual carefully.
- Page 4 13.3.2006 Rev. 2.1...
-
Page 5: Table Of Contents
13.3.2006 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relationship of the appliance and the manual .......... 1 2. Safety ......................2 2.1 Safe use of the appliance ....................2 2.2 Safety instructions in case of malfunction .............. - Page 6 13.3.2006 Rev.
-
Page 7: General
13.3.2006 Rev. 2.1 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations. -
Page 8: Safety
13.3.2006 Rev. 2.1 Safety 2. Safety 2.1 Safe use of the appliance Because the appliance has hot surfaces during normal use, the following warnings and in- structions should be observed: • During long-time operation even the frame of the appliance gets hot. •... -
Page 9: Functional Description
13.3.2006 Rev. 2.1 Functional description 3. Functional description 3.1 Intended use of the appliance The hot plates LL-600, LL-800 and LLM-800 are designed for holding the serving tem- perature of foods and drinks. 3.1.1 Use for other purposes Use of the hot plate for any other purpose than that mentioned above is prohibited. The manufacturer shall not be held liable for any situations which may arise from failure to comply with the warnings and instructions given in this manual. -
Page 10: Operating Principle
13.3.2006 Rev. 2.1 Functional description LLM-800 Power regulator (position 0: power off, position 1: full power) Yellow pilot light PLATE SWITCHED ON Switch for heating lamps (position 0: lamps off, position 1: lamps on) 3.3 Operating principle The heat surface of the hot plate is heated by heating elements located under the surface. Heat is distributed evenly on the heat surface by means of a heat transfer plate. -
Page 11: Operation Instructions
13.3.2006 Rev. 2.1 Operation instructions 4. Operation instructions 4.1 Operation procedures 4.1.1 General There is a slight smell of metal and thermal insulation when the plate is heated for the first time. This is completely normal and disappears by heating. 4.1.2 How to use the hot plate The power regulator functions both as a current switch and a temperature regulator. -
Page 12: After Use
13.3.2006 Rev. 2.1 Operation instructions 4.2 After use 4.2.1 Cleaning Use of a hose or pressure washer for cleaning the hot plate is forbidden. When cleaning the hot plate, observe that the surface is hot quite a long time after use. Hot plates are electrical appliances, which means that there are restrictions regarding cleaning them with water. -
Page 13: Installation
13.3.2006 Rev. 2.1 Installation 5. Installation 5.1 Packing The LL-600 and LL-800 models are delivered in cardboard boxes. The adjustment pads and fixing screws come in a plastic bag. The LLM-800 model, assembled in the factory, is packed in a wooden box. The heating lamps are delivered with the appliance, in packages. -
Page 14: Troubleshooting
13.3.2006 Rev. 2.1 Troubleshooting 6. Troubleshooting If the appliance fails to work, check to ensure • that it has been used according to the instructions • that the electric plug has been connected • that the circuits breakers (fuses) on the distribution board are in working order. Ask a qualified person to check overload protection. -
Page 15: Spare Parts
13.3.2006 Rev. 2.1 Spare parts 7. Spare parts General parts and electric components13 General parts and electric components15 Sneeze guard, illumination ....17... - Page 16 13.3.2006 Rev. 2.1 Spare parts...
-
Page 17: Voltage Codes
13.3.2006 Rev. 2.1 Spare parts 7.1 Voltage codes Voltage Voltage code 3/N/PE∼400/230V 50Hz ∼250V 16A 50Hz 3/N/PE∼380/220V 50Hz 3/PE∼200V 50-60Hz 2/PE 220−240V 50Hz 3/N/PE∼415/240V 50Hz 3/PE∼230V 50Hz 3/PE∼220V 60Hz 3/PE∼380 50Hz 3/PE∼400V 50Hz 3/PE∼415V 50Hz 3/PE∼440V 60Hz 3/PE∼460V 60Hz 3/PE∼480V 60Hz 1/N/PE~220-240V 50Hz 2/PE~220-230V 60Hz 3/N/PE∼400/230V 50Hz... - Page 18 13.3.2006 Rev. 2.1 Spare parts...
- Page 19 13.3.2006 Rev. 2.1 Spare parts Code Model Type Voltage Description Module:General parts and electric components 3594585 Sheating 3594578 Sheating 3672107 Sheating 3594546 Heat distributor 3594497 Heat distributor 3672115 Heat distributor 3594521 Support plate 3594514 Support plate 3672117 Support plate 3594602 Heating element 500W, E1 3594602 LL,LLM...
- Page 20 13.3.2006 Rev. 2.1 Spare parts...
- Page 21 13.3.2006 Rev. 2.1 Spare parts Code Model Type Voltage Description Module:General parts and electric components 3594673 Washer 3594666 Screw M6x50 3594659 Nut M6 3021418 Washer M5 3021418 LL,LLM Washer M5 3021175 Washer M5 3021175 LL,LLM Washer M5 3026014 Nut M5 3026014 LL,LLM Nut M5...
- Page 22 13.3.2006 Rev. 2.1 Spare parts...
- Page 23 13.3.2006 Rev. 2.1 Spare parts Code Model Type Voltage Description Module:Sneeze guard, illumination 3701005 Sneeze guard 3672113 Guard plate 3255945 Screw M5x10 3672118 Connection cable, W2 3547518 Switch for lamp, S2 3700993 Lamp holder, ceramic 3701153 Heating lamp, H3, H4 LL=LL, LLM=LLM 600=600, 800=800 F=2/PE 220−240V 50Hz, P=1/N/PE~220-240V 50Hz...
- Page 24 13.3.2006 Rev. 2.1 Spare parts...
-
Page 25: Technical Specifications
13.3.2006 Rev. 2.1 Technical specifications 8. Technical specifications Connection diagram S00015B4 Installation drawing 84110-63 [LL] Installation drawing T00247A3 [LLM]... - Page 26 Connection diagram S00015B4...
- Page 27 Installation drawing 84110-63 [LL]...
- Page 28 Installation drawing L00093A3[LLM valid to 29.2.2004]...
- Page 29 Installation drawing T00247A3[LLM valid from 1.3.2004]...
-
Page 30: Technical Specifications
13.3.2006 Rev. 2.1 Technical specifications Item Model Type Specification Dimensions WxDxH 300 x 600 x 118 mm Dimensions WxDxH 800 x 600 x 118 mm Dimensions WxDxH 800 x 600 x 680 mm Heating area 1800 cm2 Heating area LL,LLM 800 4800 cm2 Power regulation Stepless, 0°...
