www.fetco.com
FETCO Models:
1 gallon
Hot Beverage Brewers-Standard Electrical Configuration
Commercial Hot Beverage Equipment
Contact Information........................................................ 2
Description & Features .................................................. 2
Factory settings.............................................................. 2
Accessing equipment and control screens .................... 3
Layout of the brewer ...................................................... 3
Operating Instructions.................................................... 4
Programming- operator access programming ............... 6
© 2014 Food Equipment Technologies Company
CBS-2141
Fetco CBS-2141XTS & CBS-2142XTS Extractor Touch Screen models shown with optional LUXUS® L3D dispensers
NOTICE TO INSTALLER: Please leave this book with the machine.
CBS-2142
XTS
Table of Contents
Menu Features: Batch Parameters ................................7
How to calibrate the flow rate .......................................10
Operator Training .........................................................12
Service Guide to a Successful Installation ...................13
Installation Directions ...................................................14
Error Codes ..................................................................19
Final Setup for Startup..................................................20
Parts and Wiring Diagrams ..........................................21
User's Guide
XTS
P130 UPDATED NOVEMBER -2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fetco CBS-2141XTS
Summary of Contents for Fetco CBS-2141XTS
-
Page 1: Table Of Contents
User’s Guide www.fetco.com FETCO Models: CBS-2141 CBS-2142 Fetco CBS-2141XTS & CBS-2142XTS Extractor Touch Screen models shown with optional LUXUS® L3D dispensers 1 gallon Hot Beverage Brewers—Standard Electrical Configuration Commercial Hot Beverage Equipment Table of Contents Contact Information............2 Menu Features: Batch Parameters ........7 Description &... -
Page 2: Contact Information
CBS-2140 single and Twin: 1 gallon/3.8 liters per brew Coffee Filters: 13” X 5” FETCO Product #F002 Brew Time, all models: Factory set at 5.5 minutes=[4 minute brew time + 1.5 minute drip delay] Temperature Control: Water temperature is factory set at —93°C/200°F... -
Page 3: Accessing Equipment And Control Screens
Accessing equipment and control screens Layout of the brewer Touch-screen for brewer operation Brew basket sensor (internal) SD card interface port (Load & Save) Hot Water Faucet Airpot or Dispenser Locator Main power switch Slide out back panel for service access Accessing batch and programming menu screens Regular 1.50... -
Page 4: Operating Instructions
Quick brewer setup NOTES Install plumbing and electrical utilities -See Installation Section in this guide Turn rear power switch “ON” -Located on back, lower right side Brewer hot water tank will fill in 4-8 minutes ▪ -Ready screen will display ” FILLING”... - Page 5 1:50 Decaf 1 CBS-2142XTS has right and left enabled when tank temperature CBS_2132 3L 05:30 1.50 Ready Tank Temp °F Decaf 2 CBS-2141XTS single side 05:30 reaches the temperature set 1:50 Decaf 2 Heating 05:30 CBS-2142XTS dual side 1.00 point...
-
Page 6: Programming- Operator Access Programming
Programming- operator access programming -The FETCO CBS-2140XTS brewers have four brew batch menus per side. Menus are preprogrammed by the factory with basic settings that will operate the equipment as purchased. There are two batches each marked “Regular” and two marked “Decaf”... -
Page 7: Menu Features: Batch Parameters
Batch 4 Right ** Batch Copy Copy From Batch L1-L4;R1-R4 Copy To Batch L1-L4;R1-R4 L1 L2? Copy? |_______________ (example) Batch 1&4 cannot be disabled. ( Batch 1 cannot be disabled. ( Batch can be disabled, and removed from display CBS-2142XTS CBS-2141XTS... - Page 8 Programming Factory set Programming Range GENERAL Notes Items Default (display) 200 °F Correction for high 200°F Tank Temp. |______________[]___| altitude below “OFF” allows Brew at Temp. “ON” SEE NOTE BELOW! |________[]_______| brewing at any ON AUTO temperature. °F • Temperature Units of Meas.
- Page 9 *Flow Rate for flow rate Valve Calib 1900 2600 Left Valve display is only for CBS-2142xtx Series- dual station brewer. CBS-2141xts Single series displays RIGHT SIDE only TEST Runs Valve to verify flow. Right Valve • Right Valve Test (Press to test)
-
Page 10: How To Calibrate The Flow Rate
For factory or qualified service professional use only How to calibrate the flow rate Set the flow rates of components to adjust for taste profile and for over or under potting. Built-in algorithms in Brewer controller software corrects brew parameter to customer preferences or to trim variations in flow control components NOTICE: This operation requires operator hold finger on keypad position for one minute—without lifting it. - Page 11 Programming Factory set Programming Range OTHER Notes Items Default (display) See Error Code Chart Error Codes • Display Errors (Codes) for references Reset !!Errors must be • Reset Errors (Reset) |_______________[]____| corrected and cleared!! Setup upload Brewer --------------------------------------------------------------------------- Copy Program •...
-
Page 12: Operator Training
5. Do not attempt to move hot beverage equipment once it is filled. Drain equipment before moving. FETCO commercial coffee brewers prepare large amounts of coffee or tea in a single batch using very hot water. For safety, the brewer control locks the brew basket for 5.5 minutes after starting the brew. Do not attempt to defeat the factory set (default) time that the brew basket locked for safety from start of brew. -
Page 13: Service Guide To A Successful Installation
3. Verify voltages, polarity, circuits, and circuit breaker access before attaching equipment. 4. The electrical diagram is located in the Users Guide and online at www.fetco.com. 5. Make sure of the tight grounding of the equipment and use the external ground bolt. -
Page 14: Installation Directions
General: Utilize only qualified beverage equipment service technicians for installation. A Service Company Directory may be found on our web site, http://www.fetco.com. Water Connection 1. This equipment is to be installed to comply with the applicable federal, state, or local plumbing codes. -
Page 15: Electrical Connection
Electrical-General 1. All FETCO brewers require Ground. Installation without ground may cause a hazard. 2. The electrical diagram with universal wiring instructions is located on the inside of the lower cover. 3. The installation must comply with applicable federal, state, and local codes having jurisdiction at your location. - Page 17 14.0 gal/53 liter Has CE and NSF-4 certification. Internal EMI filter. Not cUL and UL listed Designs, materials, specifications, physical dimensions, firmware and software protocol for equipment or replacement parts are subject to review and change by FETCO without notice...
-
Page 18: Cbs-2140Xts Dimensions & Utility Connections
518mm 21.3kg 41.7kg 51.9 kg 22.1 l 26.3kg 584x635x737mm Rough-in CBS-2141XTS —Single station version Rough-in CBS-2142XTS —Dual station version CBS-2140XTS Utility Requirements Water Requirements: Inlet Water Temperature: Cold supply 20-75 psig (138-517kPa) 1½gpm/(5.7lpm) Coffee Filter Size: CBS-2140XTS 13”X5” Water inlet fitting is a 3/8 inch male flare. -
Page 19: Error Codes
Error Codes Contact specialized personnel for error codes How to Clear Code Description Possible Cause Corrective Action Error Codes Improper start-up Restart , if still fault: reload Software error-error on start up or corrupted software or shutdown software Shorted temperature probe Probe failure. -
Page 20: Final Setup For Startup
CBS_2132 3L EXTRACTOR SCREENS SHOWN TO THE RIGHT WILL APPEAR TOUCHSCREEN 4. The water tank will begin filling. FETCO Home Screen #1 will read Ready Touch “FILLING”. Heating screen 5. When the water level rises and is sensed by the probe at the top of the tank Filling unlock™... -
Page 21: Parts And Wiring Diagrams
Parts and Wiring Diagrams CBS-2142,XTS Back Panel UL Drawings 1109.00087.00 SERVICE PARTS ITEM NO PART NO DESCRIPTION 1052.00002.00 TERMINAL BLOCK, 3 POLE, W/ MARKING STRIP 1086.00008.00 CONNECTOR, CABLE CLAMP, 3/4" 1058.00020.00 SWITCH, PWR ROCKER RED, ILLUM. 250VAC 1052.00001.00 POWER SUPPLY, 90-264VAC/24VDC, 1.8A 1029.00012.00 SPACER, .25"... - Page 22 CBS-2142,XTS Drawings 1109.00060.00 SERVICE PARTS ITEM NO PART NO DESCRIPTION 1071.00010.00 FAUCET HPSC-BR-8 REGULAR HANDLE 1102.00210.00 ASSEMBLY FRONT PANEL, CBS-2130, GRAVITY VERSION 1024.00040.00 CARD PLUG, HWD-2100 1102.00203.00 ASSEMBLY, SPRAY HOUSING, DSVP11 DESIGN 1102.00220.00 ASSEMBLY, BYPASS VALVE, RIGHT 1102.00113.00 SWITCH, REED, ASSEMBLY 1102.00219.00 ASSEMBLY, BB LOCKER, 24VDC 1102.00221.00...
- Page 23 CBS-2142,XTS Drawings TANK 1109.00077.00 SERVICE PARTS ITEM NO PART NO DESCRIPTION 1024.00053.00 LEVEL AND TEMP PROBE GROMMET 1107.00005.00 ASSEMBLY,IMMERSION HEATER, 3000W, 240VAC 1003.00005.00 BRACKET, ONE SHOT THERMOSTAT 1053.00003.00 THERMOSTAT, SINGLE SHOT, 240V/40A 1003.00140.00 ALUMINUM BRACKET FOR SSR 1052.00033.00 RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR 1081.00042.00 STANDOFF, 1/4"...
- Page 24 CBS-2141,XTS Drawings 1109.00059, 55.00 SERVICE PARTS ITEM NO PART NO DESCRIPTION 1102.00210.00 ASSEMBLY FRONT PANEL, CBS-2130, GRAVITY VERSION 1071.00010.00 FAUCET HPSC-BR-8 REGULAR HANDLE 1024.00040.00 CARD PLUG, HWD-2100 1024.00063.00 O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50 1102.00203.00 ASSEMBLY, SPRAY HOUSING, DSVP11 DESIGN 1102.00220.00 ASSEMBLY, BYPASS VALVE, RIGHT...
- Page 25 CBS-2141,XTS Drawings TANK 1109.00078, 72.00 SERVICE PARTS ITEM NO PART NO DESCRIPTION 1024.00053.00 LEVEL AND TEMP PROBE GROMMET 1107.00005.00 ASSEMBLY,IMMERSION HEATER, 3000W, 240VAC 1107.00029.00 HEATER ASSEMBLY, IMMERSION 2300W/120VAC 1107.00030.00 HEATER ASSEMBLY, IMMERSION 1500W/120VAC 1107.00031.00 HEATER ASSEMBLY, IMMERSION 1700W/120VAC 1003.00005.00 BRACKET, ONE SHOT THERMOSTAT 1053.00003.00 THERMOSTAT, SINGLE SHOT, 240V/40A 1003.00140.00...
- Page 26 CBS-2141,XTS Back Panel UL Drawings 1109.00088.00 SERVICE PARTS ITEM NO PART NO DESCRIPTION 1052.00002.00 TERMINAL BLOCK, 3 POLE, W/ MARKING STRIP 1086.00008.00 CONNECTOR, CABLE CLAMP, 3/4" 1058.00020.00 SWITCH, PWR ROCKER RED, ILLUM. 250VAC 1052.00001.00 POWER SUPPLY, 90-264VAC/24VDC, 1.8A 1029.00012.00 SPACER, .25" HEX X 1" LG, FEM #4-40 THREAD CBS-2141,XTS Back Panel CE Drawings 1109.00046.00 SERVICE PARTS ITEM NO PART NO...
