Audio Design Associates PTM-3245 Installation Manual

Power amplifier
Hide thumbs

Advertisement

Quick Links

Download this manual
PTM - 3 2 4 5
Powe r Am pli f ie r
I ns t a l la t ion M a n ua l

Advertisement

loading
Need help?

Need help?

Do you have a question about the PTM-3245 and is the answer not in the manual?

Questions and answers

Related Manuals for Audio Design Associates PTM-3245

Summary of Contents for Audio Design Associates PTM-3245

  • Page 1 PTM - 3 2 4 5 Powe r Am pli f ie r I ns t a l la t ion M a n ua l...

  • Page 2: Table Of Contents

    Monolithic IC Output Stages Rack Mountable Low Noise Fan Cooling for Long Term Reliability Removable IEC AC Cord Handcrafted in the U.S.A. HANDCRAFTED WITH PRIDE IN THE U.S.A. Audio Design Associates 602-610 Mamaroneck Ave. White Plains, New York 10605 (800) HD-AUDIO (432-8346) www.ada-usa.com...
  • Page 3 PTM-3245 Figure 1: ADA PTM-3245 Front and Rear Panel Drawings www.ada-usa.com...

  • Page 4: Welcome And Thank You

    The PTM-3245 can be configured in many different ways and can also be programmed for automated operation. We strongly encourage you to read this entire manual to learn all of its advanced features and capabilities and how to properly connect it to your specific system.

  • Page 5: Input Connections To The Ptm-3245

    Rack Mounting Your ADA PTM-3245 When mounted in a in a standard 19" equipment rack, the PTM-3245 chassis and front panel height occupies three rack spaces (5 1/4" or 176 mm). A single standard rack space allows 1-3/4" vertical inches in a 19-inch wide equipment rack.
  • Page 6 Board of the Suite-16. 3. Plug one end of an interconnect cable into Zone 1 red Right (R) input jack on the PTM-3245. 4. Plug the other end of this cable into the red right output jack on the P-16 Audio Preamplifier Board on the Suite-16.
  • Page 7 Once you have terminated the speaker wire to the detachable female connectors, plug them into the corresponding male rear panel connectors on the rear panel of the PTM-3245. The connectors are keyed so they can only be inserted one way. Never try to force the connectors into place.

  • Page 8: Providing Power To The Ptm-3245

    Zone trigger output of the P-16 and the trigger inputs of the PTM-3245. If you are using a different type of triggering source, you can apply 9-12 Vdc to the corresponding pin of each zone you want to activate.

  • Page 9: Maintaining Your Ada Amplifier

    Power Fuse There are two fuse posts on the rear panel of the PTM-3245 labeled Standby and Main. In the event of a power surge, voltage spike, or internal failure, one or both of these fuses may blow. If the PTM-3245 stops operating, check both of these fuses.

  • Page 10: Troubleshooting Chart

    If we determine that your PTM-3245 will need further inspection or servicing, we will authorize return of the unit to us and advise you of the correct procedure.
  • Page 11 PTM-3245 Warranty and Returning the PTM-3245 for Factory repair ADA power amplifiers are under warranty for here (3) years effective upon the dealer’s receipt of the product. If ADA determines that you should send your amplifier to ADA for factory repair, you will be given a Return Authorization (RA) number.This RA number must be clearly marked on the outer carton.
  • Page 12 Audio Design Associates ADA PTM-3245 Specifications Continuous Power Output 45 watts RMS x 2, 20 Hz-20 kHz 72 watts RMS x 2, 20 Hz-20 kHz Frequency Response 1 Watt, 8 Ω 20 Hz-20 kHz +0 dB, -0.3 dB Power Bandwidth...
