Page 1: Installation Guide
MAINBOARD Installation Guide Rev: 1.00H Date: May - 99 ∗ All other product names are trademarks or copyrights of their respective owners. ∗ Specifications and information contained in this manual are subject to change without notice. -
Page 2: Table Of Contents
Table of Contents INTRODUCTION ................3 Product Description ..................3 Features & Specifications................4 Package Checklist...................6 Board Level Feature..................7 Comprehensive Mainboard View ..............10 INSTALLATION................11 Installing the CPU ..................11 Setting the Jumpers..................12 Connections....................16 Installing an AMR Card ................26 Installing the Memory Modules (DIMM) ............27 Installing the Support Drivers and Utilities ...........28 SOFTWARE SUPPORT.............. -
Page 3: Introduction
INTRODUCTION Product Description Designed as a flexible, high-performance and cost-effective solution for System Integrators and End Users alike, this mainboard provides the power and expandability to meet the requirements of the most advanced operating systems and software applications. This mainboard is a high performance Pentium ®–based (FSB 100MHz) system board that utilizes the Intel®... -
Page 4: Features & Specifications
INTRODUCTION Features & Specifications Processor Socket 370 support Intel® Celeron processors up to 500 MHz Intel ® 810 Chipset Award ® BIOS support DMI, Plug-and-Play, ACPI, Boot from BIOS CD-ROM, LS-120 120MB F.D.D., ZIP Devices Symbios® SCSI BIOS Support Anti-virus BIOS for prevention against boot-virus System Memory 2×168-pin DIMM Sockets up to 512MB SDRAM Memory Capacity. - Page 5 INTRODUCTION Installation Guide...
-
Page 6: Package Checklist
INTRODUCTION Remark: The XStore Pro IDE Driver enhances memory management by working with the Windows 95/98 operating system, resulting in higher system performance by implementing "read-ahead caching after seeking". This is especially effective with the large block sizes of modern hard disks. PC-cillin anti-virus software provides a powerful defense against viruses to protect data integration. -
Page 7: Board Level Feature
INTRODUCTION Board Level Feature PCI slots USB connectors AC97 codec chip PS/2 mouse connector (top) Digital Video Out PS/2 keyboard connector (bottom) AMR Slot CPU socket (Socket 370) MIDI/Game port Power connector Intel® ® 810 chipset Audio port COM2 connector DIMM sockets VGA port Primary IDE connector... - Page 8 INTRODUCTION PCI Slots: (3) 32-bit PCI slots are provided. AC97 Codec Chip: AC97 Audio Codec chip. Digital Video Out: A manufacturer’s proprietary bus that connects to the optional TV-Out or Panel-Link daughter board. AMR Slot: The Audio Modem Riser is a new standard interface for cost- effective AMR AC97/MC97 audio/modem cards.
- Page 9 INTRODUCTION 20. Floppy Connector: Built-in floppy controller supports (2) 5.25" or 3.5" (1.44MB or 2.88MB) floppy drives. Installation Guide...
-
Page 10: Comprehensive Mainboard View
INTRODUCTION Comprehensive Mainboard View Installation Guide... -
Page 11: Installation
INSTALLATION Static Precautions Static electricity can be a serious danger to the electronic components on this mainboard. To avoid damage caused by electrostatic discharge, observe the following precautions: ü Don’t remove the mainboard from its anti-static packaging until you are ready to install it into a computer case. -
Page 12: Setting The Jumpers
INSTALLATION Setting the Jumpers Jumpers are used on this mainboard to select various settings and features. A 2-pin jumper has two settings: Open and Short (or Closed). The jumper is closed by placing the Jumper Cap across the two pins, thereby connecting them. 3-pin jumpers can be set to pins 1-2 or 2-3 connected. - Page 13 INSTALLATION Setting the Bus Clock Override Jumper (JP2) Setting the Bus Clock Override Jumper to Enabled overrides the CPU’s default Bus Clock and set it at 100 MHz. • Over-clocking may cause serious system damage. Locking/Unlocking the Flash BIOS (JP3) To re-program the mainboard BIOS, short this jumper to unlock the flash BIOS.
- Page 14 INSTALLATION Onboard AC97 Audio Selection Jumper (JP4) Set this jumper to Enabled if you are using the onboard AC97 audio features. Also make sure the “AC97 Audio” option is Enabled (default) in the Integrated Peripherals of the BIOS. (Please refer to the BIOS, Driver & Utility Guide.) Installation Guide...
- Page 15 INSTALLATION Clear CMOS (JP5) If you have set the password, either to protect the BIOS configuration or to restrict access to the computer, the password is stored in CMOS RAM. If you forget the password, the CMOS can be cleared by setting this jumper to Clear CMOS. In case there is a CMOS error or improper CPU setting through the mainboard’s BIOS that causes boot failure, the CMOS must cleared by setting this jumper to Clear CMOS to allow the system to boot.
-
Page 16: Connections
INSTALLATION Connections Cooling Fans These connectors are small 3- pin Header Connectors that provide 12-Volt power for CPU and chassis cooling fans. Plug cable connector. Pin-2 corresponds to the RED power lead as shown: Power Supply Connector This mainboard features an ATX-style Power Supply Connector. This connector is keyed to prevent connection in the wrong direction. - Page 17 INSTALLATION System Function Connector Block (CN4) Pins [3 & 5] Power LED lead – Pins 3 and 5 connect to the power LED lead from the system’s case. In case you case comes with a five-pin keylock & power LED connector, use the connector block marked as Keylock.
- Page 18 INSTALLATION Soft Power Switch (CN2) Connects to the Power Switch featured on ATX case designs. This switch must be hooked up before the system can be powered on, unlike traditional “Baby-AT” designs where the power switch is located on the Power Supply itself. Note: Under the following two conditions, you have to press and hold the switch for more than 4 seconds to power off your system, regardless of the “Soft-Off by PWR-BTTN”...
- Page 19 INSTALLATION IrDA-Compliant Infrared Module Connector The IrDA connector bracket hooks directly to this connector on the mainboard. This connector provides support for the optional wireless transmitting and receiving infrared module. You must first configure through the BIOS setup where UART2 is directed, COM2 or IrDA. Installation Guide...
- Page 20 INSTALLATION Wake-up On LAN Connector (CN10) The Wake-up On LAN function will allow the network to wake up a Soft Power Down (Soft-Off) PC. However, if your system is in the Suspend mode, you can wake-up the system only through an IRQ or DMA interrupt. To use the Wake-up On LAN function, you may also have to enable the related option in the mainboard BIOS.
- Page 21 INSTALLATION Serial and Parallel Ports A 25-pin D-Sub header is provided on the back panel for a multi-mode bi- directional parallel port. One 9-pin D-Sub headers are also provided on the back panel for Serial ports. For the second serial port, plug the 10-pin cable of the serial port bracket to the COM2 connector on the mainboard.
- Page 22 INSTALLATION Digital Video Out This is a manufacturer’s proprietary bus that connects to the cable from optional TV-Out or Panel-Link daughter board. This bus support traditional TVs as well as the new digital flat panel displays. USB Connectors These two connectors permit connection of two USB peripheral devices directly to the system without an external hub.
- Page 23 INSTALLATION SB-Link Connect SB-Link cable on the Creative Sound Blaster Card to this connector. This PC to PCI bridge provides backward compatibility between PCI and ISA audio chips for earlier DOS games. Floppy Drives The on-board floppy controller supports (2) floppy disk drives with the floppy ribbon cable provided.
- Page 24 INSTALLATION IDE Hard Drives and CD-ROMs The on-board Enhanced IDE controller can support up to (4) IDE hard drives or other ATAPI devices, such as CD-ROMs. This controller, as with all Enhanced IDE controllers, consists of both Primary and Secondary ports. Each port has an associated connector and cable which can support up to (2) ATAPI devices each.
- Page 25 INSTALLATION MIDI/Game Port You may plug a joystick or game pad to this 15-pin female connector for game playing, or connect a MIDI device for playing or editing audio. Audio Port You can connect powered speakers or headphones to Line Out jack. Cassette players or other external audio sources can be connected to Line In jack.
-
Page 26: Installing An Amr Card
INSTALLATION Audio Connectors Two types of CD Audio connectors are available for connecting the CD-ROM drive using CD audio cables. Make sure red lead is oriented toward pin 1. Installing an AMR Card One AMR (Audio/Modem Riser) standard interface connector is provided for Audio Codec 97 (AC97) and/or Modem Codec 97 (MC97) cards. -
Page 27: Installing The Memory Modules (Dimm)
INSTALLATION Installing the Memory Modules (DIMM) • This mainboard has two sockets available for 168-pin DIMMs. They can be 3.3 volt Unbuffered Synchronous DRAMs (SDRAM), 3.3 volt FPG or EDO DRAMs. • To ensure reliability, it is recommended to use PC100 SDRAM for your 100MHz clocked SDRAM performance requirement. -
Page 28: Installing The Support Drivers And Utilities
INSTALLATION Installing the Support Drivers and Utilities Included in your mainboard package you can find a CD-ROM containing support drivers and utilities. Just insert the CD-ROM, and from the Autorun screen, click the driver/utility that you want to install. Follow the on-screen instructions to complete the installation. - Page 29 INSTALLATION Installing Intel 81x Chipset Driver for Windows Windows 95/NT4.0 Just click Install Intel 81x Chipset from the Autorun screen and follow the on- screen instructions. Windows 98 Click Install Intel 81x Chipset from the Autorun screen and follow the on-screen instructions.
-
Page 30: Software Support
SOFTWARE SUPPORT For detailed information, please refer to the BIOS, Driver & Utility Guide included in your mainboard package. Mainboard BIOS Shortly after the system is powered on, provided that the system is properly setup, you will see the message: Press DEL to enter SETUP •... -
Page 31: Flash Bios Programming Utility
SOFTWARE SUPPORT Flash BIOS Programming Utility Since this mainboard features FLASH BIOS, the user can simply re-program the old BIOS using the AWDFLASH Utility (found under “Utilities” folder of the supplied CD-ROM) as follows: 1. First, boot the system with DOS or to “Safe Mode” under Windows 95. This is the only correct way to run the AWDFLASH Utility program. -
Page 32: Symbios Scsi Configuration Utility
SOFTWARE SUPPORT Symbios SCSI Configuration Utility This mainboard features built-in Symbios SCSI BIOS. The Symbios SCSI Configuration Utility is a menu driven utility that allows you to view and change the default configuration settings for host adapters using Symbios 53C8XX chips. In most cases you should not need to change the default configuration of your host adapter. - Page 33 FCC & DoC Compliance Statement This device complies with Part 15 of the FCC rules, operation is subject to the following two conditions. 1. This device may not cause harmful interference and, 2. This device must accept any interference received, including interference that may cause undesired operation.
- Page 34 27-0M0370-07...
