Global Security Devices Ltd: No.3 Broomhill Business Complex, Tallaght,
Dublin 24, Ireland, Phone: +353 (1) 524 2691, Email: info@globalsecurity.ie
www.globalsecurity.ie
Contents
3
Installation Instructions
4
6
8
9
12
19
Wi-Corporate Controller
Installation & User Manual
YOUR SECURITY IS OUR PRIORITY
V2.07

Advertisement

loading
Need help?

Need help?

Do you have a question about the Wi-Corporate Controller and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GSD Wi-Corporate Controller

  • Page 1: Table Of Contents

    YOUR SECURITY IS OUR PRIORITY Other products from GSD Contents Installation Instructions Installation Diagrams System Overview Wiring Diagrams Network Diagrams Operation Instructions Fingerprint Enrollment Wi-Corporate Controller Installation & User Manual Global Security Devices Ltd: No.3 Broomhill Business Complex, Tallaght, V2.07 Dublin 24, Ireland, Phone: +353 (1) 524 2691, Email: info@globalsecurity.ie...
  • Page 2 Technical Specification Installation Steps Installation Steps Technical Specs - GSD Wi-Corporate Controller Power Supply 230 VAC Current consumption 30mA Step Description Page Fuse Rating 230VAC 315mA T Install the Controller using the Installation Diagrams Moisture Resistance Indoor Use Only Dimensions W.
  • Page 3: Installation Diagrams

    Installation Diagrams Installation Diagrams Control Panel opening Control Panel features cable entry mount with 4 x 1.5 inch access to rear No. 8 Security Type screws mount hole void for wiring spirit level remove screw cap remove retaining screw mains pcb cable entry cable...
  • Page 4: System Overview

    System Overview System Overview RS485 Connection to Door Controls Wireless Connection to Door Controls TCP-IP connection to Controllers TCP-IP connection to Controllers Note: If using a single Controller, Note: If using a single Controller, RS485 Network to Controllers an RS232 cable may be used. RS485 Network to Controllers an RS232 cable may be used.
  • Page 5: Wiring Diagrams

    Set the Direct address to ALL dip switches OFF (see below ) Pull Remove Battery Tab VOUT 3V Lithium Direct Connect - All Dip Switches OFF TCP_IP See page 11 on “Configuring GSD Controller Communication” to setup the application for serial communications...
  • Page 6 All dip-switches ON. The dip-switches’s should then be set to the controller Address 1 - Set SW1 ON Address 2 - Set SW2 ON Address 3 - Set SW3 ON address as shown above in section “Setting the GSD controller address”...
  • Page 7: Operation Instructions

    Setting up TCP-IP - DHCP Step Description Step Description Note: see help video on the GSD CD for Static IP address setup Note: see help video on the GSD CD for DHCP setup. Default the Controller. See Restore Factory settings on page 11. The Default the Controller.
  • Page 8 – this gives the Controller a clean set of instructions before beginning to (see instructions on page 11) enroll doors onto the network. This will take approximately 1 minute. Follow instructions on the CD provided to install the GSD PC application. WARNING! A New Network should only be created on first installation.
  • Page 9 Operation Instructions Operation Instructions Phase 3 - Enrolling Door Controls Phase 3 - Enrolling Door Controls Step Description Step Description The controller is now ready to allow Door Controls to enroll onto the All Door Controls should be installed at this point and powered up. Network –...
  • Page 10: Operation Instructions

    Operation Instructions Operation Instructions Phase 4 - Configuring Users Phase 3 - Enrolling Door Controls Step Description Step Description Once all Door Controls are enrolled onto the network – go back to the Enable a User by ticking the ‘Enabled’ box for each User Controller application and click the ‘Secure Network’...
  • Page 11: Fingerprint Enrollment

    Operation Instructions Operation Instructions Enrolling User FingerPrints Phase 5 - Configuring Access Levels Step Description Step Description Access Levels are controlled by creating UserGroups and assigning the Note: Make sure the USB Fingerprint reader is attached to the PC UserGroup to a User as described in section ‘Configuring Users’. On the Users Tab , Select a User for fingerprint enrollment UserGroups are created by combining pairs of DoorGroups with Timezones.
  • Page 12 Finger Placement Wi-BIO Finger Placement Wi-BIO Correct Finger Placement Incorrect Finger Placement Note: Incorrect placement : finger does not fully cover the sensor window. Good Quality Image Poor Quality Image Note: Ensure that the core of finger is centered on the sensor window during the enrollment process.
  • Page 13 Finger Placement Wi-BIO Finger Placement Wi-BIO Correct Finger Placement Incorrect Finger Placement...
  • Page 14 Installation Records Installation Record Ctrl Door No. Door Type Door Location Name Walk Test Ctrl Door No. Door Type Door Location Name Walk Test...
