- Page 1 PLDVD92 OWNER’S MANUAL Mobile Video System • Digital Audio Out-Coaxial • DVD Player • Vacuum Fluorescent Display • Multi-subtitle Languages Function • Multi-audio Languages Function • Multi-angle Function • Parental Control • Remote Control...
-
Page 2: Use This Product Safely
Use Authorized Service Centres FEATURES Do not attempt to disassemble or adjust this precision product. Please refer to Compatible with PAL DVD (Video the Service Centre list included with this CD) and NTSC DVD (Video CD) product for service assistance. This player can play discs recorded in either PAL or NTSC format. -
Page 3: Table Of Contents
CONTENTS Safety Information ..................4 Disc Notes .....................5 The Player ......................6 Installation .....................7 Mechanical Installation ...................7 Electrical Connection....................7 Remote Control.....................8 Preparing the Remote Control ................10 Loading a DVD/VCD/CD Disc................10 Ejecting a Disc ......................10 Basic Operation ..................11 On-Screen Display Function.................13 Multi-audio Language Function................14 Menu Function ......................14 Title Menu Function ....................14 Multi-subtitle Language Function .................14... -
Page 4: Safety Information
SAFETY INFORMATION CAUTION: Region Management Information MOBILE DVD PLAYER IS A CLASS I Region Management Information: LASER PRODUCT. HOWEVER THIS This Mobile DVD Player is designed and MOBILE DVD PLAYER USES A manufactured to respond to the Region VISIBLE/INVISIBLE LASER BEAM Management Information that is recorded WHICH COULD CAUSE HAZARDOUS on a DVD disc. -
Page 5: Disc Notes
DISC NOTES Disc formats supported by this player Note these scratches are not an indication of any problem with the player. 12 cm disc Label side up (Single-sided disc only) Video CD 12 cm disc Do not touch the underside 12 cm disc of the disc 12 cm disc... -
Page 6: The Player
THE PLAYER Front View 1. Power ON/OFF ( 10. PAUSE ( ) 2. Power Indicator 11. VFD Display 3. Tray OPEN/CLOSE ( A. Operating status indicator (Play/Pause) 4. Disc Loading Tray B. Title number indicator 5. Remote Sensor C. Chapter number indicator 6. -
Page 7: Installation
INSTALLATION Install your DVD player on a stable flat surface. There must be sufficient space in front of the player for the drawer to be opened. Don’t expose your player to extremes of temperature or humidity. Avoid standing it on a hot surface such as on top of other hot running equipment and ensure that there is adequate ventilation to the player. -
Page 8: Remote Control
REMOTE CONTROL... - Page 9 REMOTE CONTROL POWER Press POWER to turn the unit ON or OFF. EJECT Press to eject the disc. MUTE Press to mute the sound. SUBTITLE Changing of the SUBTITLE language on multi-subtitle language DVD disc. ANGLE Changing of the view angle on multi-angle DVD disc. DISPLAY Display statistical disc information during playback.
-
Page 10: Preparing The Remote Control
REMOTE CONTROL Preparing the Remote Control Ejecting a Disc Open the disc loading tray by pressing Inserting the Batteries button on the front panel or on the 1. Open the battery compartment cover. remote control, and then the disc will 2. -
Page 11: Basic Operation
BASIC OPERATION Stopping Play MUTE - Brief press the (Stop) button to stop Will mute the sound, but the disc the unit playback, when press the continues playing. When you unmute the (Play) button it can continuous normal sound (press MUTE again), a later playback. - Page 12 BASIC OPERATION Disc Search (GOTO) pen or thin metal object. Reset button is FOR DVD: to be activated for the following reasons: Press GOTO button twice, the screen will - Initial installation of the unit when all display the following message: wiring is completed.
-
Page 13: On-Screen Display Function
BASIC OPERATION On-Screen Display Function (2) Press DISPLAY for the second time: Press the DISPLAY button during SINGLE REMAIN playback to display the contents of the current disc on the screen. 00:03:15 Example: DVD: (3) Press DISPLAY for the third time: (1) Press DISPLAY for the first time: TITLE 01/03 CHAPTER 002/025 TOTAL ELAPSED... -
Page 14: Multi-Audio Language Function
BASIC OPERATION (4) Press DISPLAY for the fourth time: MONO LEFT MONO RIGHT STEREO TOTAL REMAIN 00:40:35 MENU Function (For DVD Only) Press MENU button while the disc is TOTAL TRACK : 14 playing and the disc menu will be TRACK : - 01 displayed. -
Page 15: Mp3 Disc Play
BASIC OPERATION MP3 Disc Play MP3 disc is playing as the format of FOLDER. For example: SMART NAVI ROOT ROOT MP3 MUSIC MP3 HEAR YOUR PLAY MODE DISC to select the item or folder, then press ENTER button. Pressing REPEAT button repeatedly can select three kinds of repeat play mode. -
Page 16: Setup
SETUP INITIAL SETUP GENERAL SETUP SETUP MENU --- MAIN PAGE --- GENERAL PAGE --- GENERAL SETUP TV DISPLAY NORMAL/PS SPEAKER SETUP PIC MODE NORMAL/LB AUDIO SETUP ANGLE MARK WIDE PREFERENCES OSD LANG CAPTIONS SCR SAVER EXIT SETUP 1. Press SETUP in the stop mode. MAIN PAGE (Press the stop button twice to ensure the player under STOP mode.) - Page 17 SETUP --- GENERAL PAGE --- --- GENERAL PAGE --- TV DISPLAY TV DISPLAY PIC MODE AUTO PIC MODE ANGLE MARK HI-RES ANGLE MARK OSD LANG N-FLICKER OSD LANG ENGLISH CAPTIONS CAPTIONS SCR SAVER SCR SAVER MAIN PAGE MAIN PAGE PIC mode setup OSD LANG type setup Select AUTO, the player PIC mode will Select the preferred OSD language by...
-
Page 18: Speaker Setup
SETUP --- GENERAL PAGE --- AUDIO SETUP --- AUDIO SETUP --- TV DISPLAY PIC MODE AUDIO OUT ANALOG ANGLE MARK OP MODE SPDIF/RAW OSD LANG DYNAMIC SPDIF/PCM CAPTIONS LPCM OUTPUT SCR SAVER MAIN PAGE SCR SAVER setup MAIN PAGE Select the SCR SAVER output ON/OFF. AUDIO OUT SPEAKER SETUP This is to activate the audio output from... -
Page 19: Preferences Setup
SETUP --- AUDIO SETUP --- PREFERENCES SETUP --- PREFERENCES PAGE --- AUDIO OUT TV TYPE AUTO FULL OP MODE AUDIO NTSC DYNAMIC SUBTITLE LPCM OUTPUT DISC MENU PARENTAL PASSWORD DEFAULTS SMART NAV MAIN PAGE MAIN PAGE Dynamic Range Control TV type setup Select DRC and adjust the dynamic This player can play discs recorded in range of a Dobly Digital encoded... - Page 20 SETUP --- PREFERENCES PAGE --- --- PREFERENCES PAGE --- TV TYPE TV TYPE AUDIO AUDIO SUBTITLE ENGLISH SUBTITLE 3 PG DISC MENU FRENCH DISC MENU 4 PG 13 PARENTAL SPANISH PARENTAL PASSWORD CHINESE PASSWORD 6 PG-R DEFAULTS JAPANESE DEFAULTS 7 NC-17 SMART NAV SMART NAV 8 ADULT...
-
Page 21: Defaults Table
SETUP --- PREFERENCES PAGE --- DEFAULTS TABLE TV TYPE General Setup TV Display Normal/LB PIC Mode AUTO AUDIO Angle Mark SUBTITLE OSD Language English DISC MENU Captions PARENTAL SCR Saver Speaker Setup Downmix Stereo PASSWORD Audio Setup Audio Out SPDIF/RAW DEFAULTS RESET OP Mode... -
Page 22: Specifications
SPECIFICATIONS Supply Voltage : 12V DC (11V-15V), test voltage 14.4V, negative ground Current Consumption : Less than 2A Signal System : Compositive video 1.0Vp-p 75Ω Discs Played : (1) DVD-VIDEO Disc 5” (12 cm) single-sided, single-layer 5” (12 cm) single-sided, double-layer (2) Compact Disc (CD-DA, VIDEO CD) 5”... - Page 24 www.pyleaudio.com 88-V1351-12...
