- Page 1 ww.pyleaudio.com OWNER S MANUAL OWNER S MANUAL Mobile Audio System Mobile Audio System PLL Synthesizer Stereo Radio Digital Compact Disc Player Automatically Memory storing Hiding Panel Preset Equalization Auxiliary Input Funxtion Remote Control PLDTF5M...
-
Page 3: Table Of Contents
Characteristics And Specifications CHARACTERISTICS Frequency range : 87.5-108.0MHz Intermediate frequency : 10.7MHz Practicality neat (S/N 30dB) : less than 22dB Stereo separation : more than 25dB Frequency range : 522-1620KHz Intermediatef requency : 450KHz : less than 48dB Practicalityn eat (S/N 20dB) SPECIFICATIONS Power : DC12-13.8V, -earth... -
Page 4: Safety Precaution
Safety Precaution CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN Caution: Warning: The exclamation The lightning flash To reduce the risk point within an with an arrowhead of electric shock, equilateral triangle symbol, within an don't open the is intended to equilateral triangle,... -
Page 5: Installation
Installation CAUTION: 1. Always use an experienced installation technician. 2. The location of the player must not obstruct the driver . 3. Do not install the player in excessive dusty, shakable, high-temperature or humid condition. Note : these conditions will adversely affect the player s operation. 4. -
Page 6: Function Characteristic
Function Characteristic DVD Player Features 6. Support DVD Audio The unit is fully compatible with the 1. Fully Compatible high-quality audio DVD Audio discs, Fully compatible with most of the without requiring the support from discs on the market. additional software. It will enable the Please refer to the list on page 5 for end-users to enjoy an excellent audio details. -
Page 7: Disc Handling And Maintenance
Troubleshooting What appears to be trouble is not always serious, when you meet following problems in using, please check the following points before calling a service. Problem Action POWER The power supply Please check whether the DC power has been has disconnected. -
Page 8: Playable Disc
Playable Disc This unit can play DVD, S-VCD, VCD, CD, MP3 etc. format discs. Recorded Recorded Disc types Disc types Disc symbols Disc symbols Disc Sizes Disc Sizes Contents Contents Audio+Video (Motion Picture) V I D E O V I D E O Audio+Video S-VCD SVCD... -
Page 9: Advanced Operations
Advanced Operations (DRC) It is divided into 2 options: adjustment has 2 options for ON and OFF. When the option is set your setting: 4:3 and 16:9. This up ON, the dynamic range will option is used to display image due compress by reducing treble and to the panavision on the normal TV increasing soft sounds, making a... -
Page 10: Panel S Diagram
Panel s Diagram 1. LCD 9. Brightness control 2. Radio searching down/DVD last song 10. Volume control & function button & fast-backward 11. Reset button 3. Radio searching up/DVD next song & fast-forward 12. Angle adjustment 4. Clock display button 13. -
Page 11: Remote Control S Diagram
VCD Control Functions (Press Items Icon Symbols Up/Down to select the items needed.) Display the current chapter number and the total number of the Chapter 2/32 disc chapters. Users Control can jump to the chapter number needed. Display the time that the disc has elapsed. -
Page 12: The Panel Button S Function Instructions
The Panel Button s Function Instructions Power on/off & mute button Press and hold it for more than 2 seconds to search down Press this button once to turn on the automatically. player. In turn on mode, press short 2 In disc playing mode, press to activate the selecting mode of select the last track. -
Page 13: Dvd Video Control
DVD Video Control Functions (Press Items Icon Symbols Up/Down to select the items needed.) Display the current title number and the Title total number of the disc 1/17 Control titles. Users can jump to the title number needed. Display the current chapter number and the total number of the Chapter... -
Page 14: Basic Operations
Basic Operations Turn on the DVD player If the format of the disc inserted is recognized by the unit, the TV screen First, press the POWER/MUTE button will show the corresponding disc to turn on the unit. symbol, and the unit will begin to play Notice: automatically. -
Page 15: Advanced Operations
Basic Operations Radio/auto-memory & scan TITLE/ZOOM BUTTON storage/programme 1. In playback mode, press remote control ZOOM button as enlarge 1. In radio mode, press this button on picture function, then press remote control to use auto-memory select the desired angle. and scan storage function. - Page 16 Basic Operations you want to enjoy. This type of menu can 4 FAD also be called PBC (Playback Control). Press 'SEL' button four times, FAD will be activated, then depress VOL'+/-' button to adjust front or rear louder-speaker output. MENU SET-UP 5 LOU When playing this type of discs: Press 'SEL' button five times, LOUD...
