- Page 1 5105 Microwave Switch System Operation Manual THE RF/MICROWAVE SWITCHING TECHNOLOGY SOLUTION COMPANY...
- Page 2 Copyright © Dow-Key Microwave Corporation 2005, All rights reserved. Information in this publication supersedes that in all previous ly published material. Specifications and price change privileges reserved. Printed in the U.S.A. Dow-Key is a registered trademark of Dow-Key Microwave Corp.
- Page 3 WARRANTY Dow-Key Microwave Corporation warrants this product to be free from defects in material and workmanship for a period of 1 year from date of shipment. This warranty does not apply to defects resulting from product tampering or modification witho ut Dow- Key’s express written consent.
- Page 4 Manual Revision History The revision history shown below lists of all revisions and addendums created for this manual. The revision level increases numerically as the manual undergoes subsequent updates. Addendums are released between revisions and contain important change information that the user should incorporate immediately into the manual. When a new revision is created, all addendum associated with the previous revision of the manual are incorporated into the new revision of the manual.
-
Page 5: Table Of Contents
Table of Contents General Information......................1 Introduction ........................1 Specifications ......................1 Safety Precautions ....................2 Inspection........................2 Maintenance .......................2 Repacking for shipment..................2 System Layout........................3 Front Panel Layout ....................3 Rear Panel Layout.....................3 Schematic Layout ......................4 Ethernet ERNI Pin Out Layout................5 Connections ........................6 Power Connections....................6 3.1.1 Line Voltage ......................6 3.1.2 Line Power Connection..................6... - Page 6 Table of Contents 6.4.3 *RST ........................19 6.4.4 *WAI........................19 System Commands ....................20 6.5.1 SYST:ERR? ......................20 Module Command Set ...................22 6.6.1 [ROUTe]:MODULE<x>,<y>,<z> ..............22 6.6.2 Setting module to position x,y,z...............22 6.6.3 ROUTe:CLOSURES?..................23 Appendix A ..........................24 List of Figures Figure 2-1 Front Panel Layout ....................3 Figure 2-2 Rear Panel........................4 Figure 2-3 Schematic .........................4 Figure 2-4 Erni 973101 Connector –...
-
Page 7: General Information
General Information Introduction The Dow-Key Microwave Model 5105 is a Physical Ethernet Switch to switch 10/100base-T with the option to physically switch 1 Gbps Ethernet. The matrix is an expandable design that allows for up to 8 modules on the rear panel that can easily be inserted or removed by the customer. -
Page 8: Safety Precautions
Dow-Key Microwave immediately for necessary repairs. This system is not field repairable. Repacking for shipment Should it become necessary to return the Model 5105 for repair, carefully pack the unit in its original packing carton or the equivalent, and follow these instructions: •... -
Page 9: System Layout
System Layout Front Panel Layout Figure 2-1 shows the general layout of the front panel of the Model 5105 which includes: • 4 x 40 LCD Display • 16 Button Keypad Figure 2-1 Front Panel Layout KEYPAD DISPLAY Rear Panel Layout... -
Page 10: 2.3 Schematic Layout
System Layout Figure 2-2 Rear Panel Power Entry Module Line Fuse Module Number 2.3 Schematic Layout Figure 2-3 Schematic SHOWN IN FAILSAFE POSITION... -
Page 11: Ethernet Erni Pin Out Layout
System Layout Ethernet ERNI Pin Out Layout Figure 2-4 Erni 973101 Connector – Rear View Channel 2 Channel 1 INPUT INPUT OUT 1 OUT 1 OUT 2 OUT 2 OUT 3 OUT 3 OUT 4 OUT 4... -
Page 12: Connections
Power Connections 3.1.1 Line Voltage – The Model 5105 operates from a line voltage in the range of 110V to 240V at a frequency of 50 or 60Hz. Line voltage selection is automatic. CAUTION: Operating the unit on an incorrect line voltage may cause damage, possibly voiding the warranty. -
Page 13: Figure 3-1 Power Entry Module
Connections Figure 3-1 Power Entry Module Insert small bladed screwdriver to release the fuse. Table 3-1 Line Fuse Line Fuse Rating Manufacturer Manufacturer Part No. Voltage 110-240V 1.5A, Fast Acting, 250V, ¼” x 1-1/4” Littelfuse 312015... -
Page 14: Gpib Control Connection
Connections GPIB Control Connection The Model 5105 comes equipped with a 24-pin connector which mates with any GPIB control interface cable with metric mating screws. The GPIB has 16 signal lines and 8 ground return or shield drain lines. All GPIB devices share the same 24 bus lines. -
Page 15: Configuring The Matrix
Configuring the Matrix Configuring the Matrix Before you configure your matrix, you will need to contact your network administrator to obtain the following information: • IP address for the matrix • TCP port number Each device on your network must have a unique address so that all devices can communicate simultaneously over the same network. -
Page 16: Testing The Ethernet Communication
It was designed to operate with common network utilities and drivers. If the Matrix fails to communicate, contact your network administrator for additional assistance. If your network administrator is unable to locate the problem, please contact Dow-Key Microwave Corporation at 1-805-650-2325. -
Page 17: Manual (Local) Operation
Figure 5-1 Start-up display Power On Position the rocker switch on the rear panel of the Model 5105 to the on position (Figure 2-2). The LCD will illuminate with a yellow background and the display will show the main menu. Upon power up all positions shall be in the failsafe position and the unit will be in ‘LOCAL’... -
Page 18: Manual Operation Through Front Panel
Manual (LOCAL) Operation Manual Operation through Front Panel Manual mode of operation for the Model 5105 is facilitated by using the front panel keypad and LCD display. Make sure that the operation in the lower right corner is set to ‘LOCAL’. Press [MODE] key to switch between ‘LOCAL’ and ‘REMOTE’. -
Page 19: Front Panel Controls, First Set Of Menus
You have just completed connecting an RF path to Module 4, Channel 2 and Output 3. To change another path, follow the same procedure. Refer to Rear Panel Figure 2-2 and Schematic Figure 2-3 in setting the correct Module #, Channel # and Output #. -
Page 20: Clear Positions Command (3)
Manual (LOCAL) Operation Figure 5-8 Clear errors display Figure 5-9 Main menu display showing no errors 5.5.3 Clear Positions Command (3) Clears or opens all switch paths in the system. Press [3] then [ENTER] to clear all positions. Press [MENU] to take you back to the main display. Figure 5-10 Clear command display 5.5.4 GPIB Address (4) -
Page 21: More Options (8)
Manual (LOCAL) Operation 5.5.5 More Options (8) Takes you to the second set of menus. Front Panel Controls, Second Set of Menus Press [8] to display the second set of menus for the front panel controls. Figure 5-12 Second menu commands 5.6.1 IP Address Command (1) Sets the IP address as assigned by your network administrator. -
Page 22: Tcp Number Command (2)
Manual (LOCAL) Operation 5.6.2 TCP Number Command (2) Sets the TCP port number as assigned by yo ur network administrator. Refer to section 4.1 “configuring the matrix”. Press [2] and enter your new IP address. Figure 5-14 TCP port number display 5.6.3 Factory Setup (3) This is for the factory use only. -
Page 23: Remote Operation
SCPI is a command structure that is based on the IEEE-488.2 specification which Dow-key has adapted to work with both GPIB and Ethernet control. The model 5105 has internal software loaded that can be written using SCPI command structure. SCPI is the abbreviation of Standard Commands for Programmable Instruments. -
Page 24: Command Separators
• A semicolon (;) is used to combine commands from the same subsystem into one message string. • A colon and a semicolon is used to link commands from different subsystems. Common Commands The following contains the common commands of SCPI that the 5105 matrix is compatible with. 6.4.1 *IDN? Syntax... -
Page 25: Opc
Remote Operation 6.4.2 *OPC? Syntax *OPC? Description This query returns an ASCII character “1” when all pending operations have been finished. Result ASCII character “1”. Example ROUTE:MODULE1,2,3;*OPC? Result “1” 6.4.3 *RST Syntax *RST Description This command performs a device reset. This will set the instrument so that all modules are set to failsafe output 1. -
Page 26: System Commands
Remote Operation System Commands The following contains the system commands of SCPI that the 5105 matrix is compatible with. 6.5.1 SYST:ERR? Syntax SYSTem:ERRor? Description Query the instrument’s error queue. A record of up to N errors is stored in the instrument’s error queue. - Page 27 Remote Operation Explanation of Error Queue “-1”INVALID CHARACTER”” Invalid character detected. Would be caused by “ROUTE:MODULE1,2,Y”. The software is expecting a switch position number and you have entered a letter instead. Hence ‘Y’ is an invalid character. Solution: check your syntax in the offending message.
-
Page 28: Module Command Set
Remote Operation Module Command Set The following contains the module (switching) commands of SCPI that the 5105 matrix is compatible with. 6.6.1 [ROUTe]:MODULE<x>,<y>,<z> Syntax [ROUTe]:MODULE<x>,<y>,<z> Description This command is used to control the position of the modules. Module positions are specified in a 1 to N fashion, therefore legal values for <x> are from 1 to 8, <y>... -
Page 29: Route:closures
Remote Operation 6.6.3 ROUTe:CLOSURES? Syntax [ROUTe]:CLOSURES? Description This command is used to query the matrix to return a list of closed contacts. The list will be in the form of <module1path1output,module1path2output….. module8path1output,module8path2output>. Note: upon power-up, all module:path pairs will be set to output 1. If ROUTE:CLOSURES? was sent after power-up before any other switching takes place, you would expect the following string returned. - Page 30 Appendix A The following is the available configurations for the Model 5105. Number of Modules Part Number Installed 5105-1 5105-2 5105-3 5105-4 5105-5 5105-6 5105-7 5108-8...
