INSTRUCTION MANUAL
To our Users:
This instruction manual describes handling of the
screen.
Refer to the Installation Manual for installing the screen.
The screen surface may have an odor at first. Please ventilate enough by opening the window. Any
such odor will gradually fade.
When the odor is strong, please keep the screen pulled out, even not in use. (It might take several days
till the screen does not have an odor any more.)
Thank you for your purchase.
Ensure that you read this instruction manual carefully and use the screen correctly. Be sure to retain this
instruction manual for future reference.
A1 Manual Screen
Index
2 3
4
5
6
7 8
9
Advertisement
Table of Contents
Related Manuals for OS A1
Summary of Contents for OS A1
-
Page 1: Table Of Contents
A1 Manual Screen INSTRUCTION MANUAL To our Users: This instruction manual describes handling of the screen. Refer to the Installation Manual for installing the screen. The screen surface may have an odor at first. Please ventilate enough by opening the window. Any such odor will gradually fade. -
Page 2: Important Safety Instructions
Important Safety Instructions Ensure you follow the below instructions for safety. This manual explains the necessary precautions to prevent the harm to the user or the others and any damage to property. The marks show the level of harm and damage caused by the mal-handling or the disregard to the precautions. -
Page 3: Safety Precautions 2
CAUTION Do not pull out the screen more than the STOP label point. The screen fabric may fall out. Do not put anything or fragile thing below the screen. Anything could block the movement of the screen causing damage. Do not use the sharp cutlery or pointed metal near the screen. It might damage the screen fabric. -
Page 4: Accessories
Please confirm the accessories before use. Accessories The mounting brackets, stoppers, bolts, screws, washers and hex-head wrench are used for installation. Refer to the Installation Manual. Mounting Brackets x2 Stoppers x2 Bolts(M4x10) x4 Screws(4x40) x4 Washers(M4) x4 Hook bar x1 Hexagonal spannerx1... -
Page 5: Construction & Parts Name
Construction & Parts name The screen is composed of parts as below. Please confirm before use. Screen main unit Case Screen fabric Label Adjustment knob Handle Under pipe (Tension adjustment mechanism) Hook bar Hook the elliptical part of the hook bar to the handle for pulling out the screen. -
Page 6: Cautions In Handling
Cautions in handling The surface of the screen is specially processed to enhance projection image. The contamination or damage may result in poor projection image. Pay close attention to the followings when handling this product. Do not touch the screen surface. Do not draw anything on the screen surface. -
Page 7: Using The Screen
The pull down and up make the rocking breaks work and repeat the lock and release each time. Please hold the handle when you pull down and up the screen. Using the screen 1. Hook the attached hook bar onto the handle of the screen, and then pull the bar down. Handle Hook bar 2. -
Page 8: Usage 7
Storing the screen Pull the screen slightly down to unhook the stopper and release it. It will scroll up automatically. Applying tension to the screen If the screen fabric is less tensioned around the under bar area after use, adjust the tension using the tension adjustment mechanism. Turn the knobs attached on both edges of the under pipe to the right, and then the fabric is tightened. -
Page 9: Specifications
Side View Total Length A From screw to screw G Mounting Bracket From screw Model to screw Specifications and design may change without prior notice. - Page 10 OSI CO., LTD. Room 1605, 16/F, Seaview Centre, 139 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong...
