Instruction Manual
Thank you for purchasing OS product.
The installation of the device requires technical knowledge
and please do not install it on your own.
Please contact the installer or the distributor for
installation.
To installers: After installation, please hand over the
manual to the user
STP-***HM-MRK2
Please kindly read this instruction manual carefully and use the product properly. This manual
should be kept for future reference.
Electric Screen
Tab-tensioning system
Index
Safety Precaustions
Construction
Accesssories
Installation, Remote controller
How to use the screen
Maintenance Option
FAQ
P Selection
Advertisement
Related Manuals for OS STP-***HM-MRK2
Summary of Contents for OS STP-***HM-MRK2
- Page 1 Electric Screen P Selection Tab-tensioning system Instruction Manual Thank you for purchasing OS product. The installation of the device requires technical knowledge and please do not install it on your own. Please contact the installer or the distributor for installation.
-
Page 2: Safety Precautions
Safety Precautions Please strictly comply with the following for safety This instruction manual is intended to prevent any danger to the user and the third parties, or any damage to the property. The following indicators are to remind users to strictly observe the instructions. ■... - Page 3 Stop using, when anything like metal, water, or liquid goes into the screen, and pull out the power plug. The continuous use may cause a fire and an electric shock. Stop using it, and consult with the dealer or distributor. Pull out the power plug, when the screen is not used for long.
-
Page 4: Cautions In Handling
Cautions in handling Never use a moist cloth or chemicals such as benzene, thinner etc. It may cause the poor projection image. The surface of the screen is specially processed to enhance projection image. The contamination or damage may result in poor projection image. Pay close attention to the followings when handling this product. - Page 5 Please confirm the accessories before installation. Accessories Operation method Other accessories, screws etc. Sliding brackets Remote control ×2 Side Brackets ×1set Screw Cross recess Truss tapping screw Infrared remote controller ×1 AAA dry batteries×2 (4×40)×6 Screw Cross recess Truss tapping screw (4×12)×4 Infrared receiver ×1 Sticker(spare)×1...
-
Page 6: Installation
Installation Make sure the power is off when you connect it to the screen. It may destroy the product or cause an electric shock. Plug in the IR receiver plug tightly. If not, it may cause mal-functioning. Connect the modular plug of the Infrared receiver to the modular jack. IR receiver Modular type Remove the dust, water, oil and moist on the location, and stick the Infrared receiver tightly,... - Page 7 How to use the screen Storing the screen U P button The screen moves up. When the screen is deployed, push the button of the remote controller. STOP button The screen is rolled up and stored, and it stops The screen stops. automatically.
- Page 8 Memorizing the position 1. At the desired position, push button for 5-6 seconds, and then push button within 2 seconds. 2. Upon receiving the command, the screen moves up approx. 10cm, and then stops at the preset position. To lift down the projection position Deploy the screen Push button for 5-6 seconds...
-
Page 9: Maintenance
Maintenance The replacement of the fabric When the screen fabric is damaged, the fabric can be replaced. For details, please contact the dealer or distributor. For details on replacing the fabric, please refer to the attached manual of the replacement fabric. Giving tensions to the screen When the tension near the weight bar is lost, please perform linearity adjustment by a tension adjustment knob. - Page 10 1 second before applying adjusted. manual duly followed? the necessary adjustments OSI CO., LTD. Room 1605, 16/F, Seaview Centre, 139 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong PHONE : +852-3580-0087 FAX : +852-2367-4300 E-mail : info-hk@os-worldwide.com U R L : http://www.os-worldwide.com...
