Step 1: Getting Started

A. Thermostat Buttons and Indicators
1
Left Arrow
2 Up Arrow
3 Action Button
4
LED Light
5 Right Arrow
6 Down Arrow
7
SYSTEM Button
8
FAN Button
9
Soft Keys
Pepco Web-Programmable Thermostat Homeowner's Manual
9
Navigates menu items
Raises temperature setpoint and changes selected menu item
Selects action of selected menu item
Indicates status of pending, active, or overridden conservation periods
Navigates menu items
Lowers temperature setpoint and changes selected menu item
Changes system selection (OFF, COOL, HEAT, AUX [displayed on heat pump
units only])
Changes fan setting (Auto/On)
Performs action listed on display above the button
3
1 2
8 7
4
5
6
3
