INSTRUCTION MANUAL

PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING
THIS MODEL.
KEEP THIS MANUAL FOR PARTS NUMBERS WHEN ORDERING .

Advertisement

loading
Need help?

Need help?

Do you have a question about the Titan Monster Track 4WD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ofna Racing Titan Monster Track 4WD

Summary of Contents for Ofna Racing Titan Monster Track 4WD

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING THIS MODEL. KEEP THIS MANUAL FOR PARTS NUMBERS WHEN ORDERING .

  • Page 2: Required For Operation

    REQUIRED FOR OPERATION You will need to buy a few items to start the engine and run the car. THINGS NEEDED • Use 20% nitro CAR fuel. Do not use airplane or heli fuels, they will over heat engine. • Buy LONG glow plugs, like OFNA/PICCO Plug (#51007). Use plugs without idle bar.
  • Page 3 MUST READ THIS BEFORE RUNNING Running a nitro kit is fun and easy, but to make this a safe rusting. • Clean oil and dirt from chassis with a degreaser. and good experience you must observe a few rules. This kit is extremely fast, easily over 40MPH, and can seriously Precautions injure someone if you are not careful.
  • Page 4 CHECKING ENGINE THROTTLE * Align throttle servo same as shown. Brake (C) 1. Insert AA batteries into 1. Push trigger to full 1. Pull Full Throttle. brake position. transmitter (8 Pcs). 2. Adjust alum. Stopper to 2.Turn on transmitter. increase or decrease 3.Turn on receiver.

  • Page 5: Plastic Parts

    PLASTIC PARTS 40003 40017 36901 40056 Diff. Case Front and Rear Gear Boxes Plastic Shock Parts Tree Front Knuckles, Pivot Ball 40040 31304 Center Diff Mount Tree Rear Hub, Pivot Ball 40031 40201 40202 Servo Saver Plastic Tree Front and Rear Upper Arms Front and Rear Lower Arms.
  • Page 6 ASSEMBLY OF THE DIFFERENTIAL ( Builds two differentials for front and rear.) 30701 4x4mm 40010 Set Screw *Put the O-ring 2.5x13.8mm in inside of the diff. case 40006 and press it flush against 40010 Cap Joint the bottom. 40009 2.5x13.8mm O-Ring 40009 36053...
  • Page 7 ASSEMBLY OF THE FRONT ARMS HOLDER 40242 Misc. Screws and Hardware 4X15MM Tapping Screw ( Small Head) 90026 Screw Cement 5x5mm Set Screw 4X45MM Tapping Screw 36730 ( Small Head) Cap Joint 40022 Front Lower Arm Holder (Front/Alum.) 40015 Option: Front Lower Arm 49002 Holder (Rear/Plastic)
  • Page 8 ASSEMBLY OF THE FRONT CVA JOINTs Screw Cement 36055 2.5x17mm 36053 8x16mm Ball bearing 90026 5x5mm 36054 36052mm Set Screw 8mm Alum. CVA Joint 36053 Wheel Hub 8x16mm Ball bearing 36055 2.5x17mm Screw Cement 36052 CVA Joint 36053 8x16mm Spare: Ball bearing 15073 36053...
  • Page 9 ASSEMBLY OF THE SERVO SAVER UNIT ASSEMBLY OF THE 40037 Steering Plate SERVO SAVER 40031 Hex Screw 40037 Servo Saver Steering Plate Plastic Bushing Hex Screw 4x8mm Plastic Bushing 4x8mm Plastic Bushing 40035 Alum. Servo Saver Tube * Take the 4x8mm Plastic Flange bushing and Plastic Bushing from servo saver plastic parts tree 40032...
  • Page 10 ASSEMBLY OF THE REAR UPPER ARM Assembly of the right and left hand side are the same. *Builds two arms for left and right hand side. 36850 36690 7mm Ball Plastic Ball End 40201 Upper Arm 36860 5x35mm Turnbuckle ASSEMBLY OF THE REAR HUB Assembly of the right and left hand side are the same.
  • Page 11 ASSEMBLY OF THE FRONT GEAR BOX ONTO 4x15mm UPPER CHASSIS Screw 4x15mm Screw 4x10mm Flat Head Screw 4X16mm Flat Head Tapping Screw 40234 Main Chassis 40205 Center Diff. Mount 35314 35314 Nylon Nut Nylon Nut ASSEMBLY OF THE FRONT SHOCK TOWER 40203 Shock Tower 40040...
  • Page 12 ASSEMBLY OF THE REAR GEAR BOX ONTO 4x10mm UPPER CHASSIS 4x16mm Flat Head Flat Head Screw Tapping Screw Rear Gear Box Assembly ASSEMBLY OF THE REAR SHOCK TOWER 40203 Shock Tower 40040 Center Brace 3x15mm Tapping Screw Mount ( Rear ) 35314 4x15 4x25...
  • Page 13 ASSEMBLY OF THE TWO SPEED TRANSMISSION 40219 40208 3X13.8mm 28T Helical 90026 90026 Gear 5x5mm 5x5mm 35227 Set Screw Set Screw 2 Speed Clutch Cam 2nd Gear Assembly 30170 Brake Joint 36053 36053 8x16mm 8x16mm Ball bearing Ball bearing 40217 40218 Center Gear 8x12x1mm...
  • Page 14 ASSEMBLY OF THE 2 SPEED TRANSMISSION INTO CENTER MOUNT 40040 * Put the brake disk Center Diff. into the brake cap joint Mount before assembly the 36650 center diff. mount. Brake Disk 40216 40216 Center Center Drive Shaft Drive Shaft (Short/86.5mm ) ( Long/93mm ) 40040...
  • Page 15 ASSEMBLY OF THE LOWER CHASSIS BRACE 40200 6mm Plastic Ball End 40200 40212 6mm Plastic 30411 43.9mm Ball End 6mm Ball Chassis Stiffener ( Rear/lowe/Long) 30411 6mm Ball 40200 40213 40200 6mm Plastic 35.7mm 6mm Plastic Ball End Chassis Stiffener Ball End 30411 ( Front/lowe/Short)
  • Page 16 ASSEMBLY OF THE BUMPER SUPPORT PARTS 3x15mm Tapping Screw 40207 Bumper Support 40207 Bumper Support 3x15mm Tapping Screw 3x15mm Tapping Screw 3x15mm 40207 Tapping Screw Bumper Support...
  • Page 17 ASSEMBLY OF THE SHOCK ABSORBER * Fit the o-ring into 40059 groove. * Made eight shocks for front and rear use. 14.7mm O-Ring 40060 40059 2.5mm 14.7mm Nylon Nut O-Ring 32235 40076 Shock Piston Shock Body 40090 3.5mm O-Ring 2.6x5mm Washer 40090 40056...
  • Page 18 ASSEMBLY OF THE FRONT AND REAR SHOCK INTO SHOCK TOWER 3x8mm 3X15mm Washer Screw 30411 6mm Ball 30411 3x8mm 6mm Ball Washer 3X15mm Screw Shock Assembly 3X15mm Screw 3X15mm Screw 3x8mm Washer 3X15mm Screw 30411 30411 6mm Ball 6mm Ball 3x8mm Washer 3X15mm...
  • Page 19 ASSEMBLY OF THE FRONT AND REAR CHASSIS SKIP PLATE ( FRONT ) 3x20mm Flat Head Tapping Screw 3x20mm Flat Head Tapping Screw 40204 Skip Plate 3x12mm Tapping Screw 4x20mm Flat Head Tapping Screw (REAR ) 3x20mm Flat Head Tapping Screw 3x20mm Flat Head Tapping Screw...
  • Page 20 ASSEMBLY OF THE SIDE PLATE MOUNT M4x10 Flat Head Screw 40205 Side Chassis Brace Plastic 35314 M4 Nylon * Put the M4 nylon nut into the side chassis Assembly of the right and left hand side brace plastic before assembly are the same.
  • Page 21 ASSEMBLY OF TE CHASSIS STIFFENER PLATE Assembly of the right and left hand side are the same. 4x15mm Screw 40202 Alum. Side Plate For Plastic Chassis Brace aSSEMBLY OF THE CHASSIS STIFFENER Assembly of the right and left hand side are the same.
  • Page 22 ASSEMBLY OF THE RADIO TRAY AND RECEIVER BOX 3x10mm Tapping Screw * Connect throttle 3x10mm 30560 wire to receiver. Tapping Screw Antenna Pipe THROTTLE SERVO 3x10mm Tapping Screw 40236 Radio Tray * Connect battery wire 10274 to receiver. Servo Post 10274 Battery Case Servo Post...
  • Page 23 ASSEMBLY OF THE BRAKE LINKAGE 30800 - SERVO LINKAGE KIT, COMPLETE * Cut the shaded 2x8mm area as shown. 2x4mm 2mm Rod Screw Screw 2x6mm Washer Servo 10768 Mount Servo Horn 3x3mm 3x25mm Set Screw Screw Tie-Rod 36140 Adjust Mount 30530 3x3mm Throttle...
  • Page 24 ASSENBLY OF THE ENGINE MOUNT * Fit the flywheel using a pair of the plier and 30481 cross wrench. 3x20mm Hex Screw ( 4 Pcs ) 10102 Clutch Spring 10330 10010 Clutch Shoes Tapper cone SG Type Crank Shaft 30481 10040 10098 * Only use this 6.3mm tapered cone...
  • Page 25 ASSEMBLY OF THE AIR FILTER AND MANIFOLD *Put the manifold spring 10120 * Apply filter oil to the around the Engine. Spring sponge before use. 10034 Manifold Nylon Straps Air Filter ( Small ) Mount 10021 Air Filter 10016 Connecter 10069 Air Filter Manifold,...
  • Page 26 ASSEMBLY OF THE ENGINE ONTO CHASSIS 40227 Muffler Stay 35314 Nylon Nut 90026 5x5mm 10111 Set Screw Engine Mount 4x10mm Flat Head Screw 10111 3mm Hex Screw for Engine Mount...

  • Page 27: Left-Hand Side

    ASSEMBLY OF THE FUEL TUBE AND PRESSURE TUBE * Snap the throttle ball end into the valve ball of the carburetor *Connect to fuel nipple. Fuel Tube *Connect to fuel tank pressure nipple. *Connect to muffler pressure nipple. *Connect to carburetor ASSEMBLY OF THE TIRES AND WHEELS OF THE ASSEMBLY OF THE TIRES AND WHEELS OF THE...
  • Page 28 ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB ( FRONT ) ( REAR ) * Apply instant glue into the * Apply instant glue into the both side of the groove of both side of the groove of the wheel.
  • Page 29 ASSEMBLY OF THE SPOT LIGHT AND * Put the spot light assemble ROLL BAR - p/n#40206 into the groove of the roll bar. Spot Light Plastic 3x20mm Tapping Screw Nylon Nut 3x20mm Hex Screw 3x20mm 2X8mm Screw Tapping Screw 40206 Roll Bar Plastic ASSEMBLY OF THE SPOT LIGHT AND ROLL BAR ONTO BODY...
  • Page 30 Anticlockwise---Shift timing will become quicker. CLUTCH GEAR: 2. Adjust the clutch shift timing for your track conditions with 4x4mm set screw. OFNA Racing-USA As you tighten (Clockwise) the 4x4mm set screw , the shift timing will become slower. Tel:949-586 2910 USA Parts No.
  • Page 31 ALIGN THROTTLE SERVO AND BRAKE SAME AS SHOWN ( Neutral Position ) Engine at idle ( Braking Position ) Brake is not on Brake is on Brake Adjust Nut ( Full Throttle Position ) Less Brake More Brake Engine at full throttle Loose Tighten * Tighten or loose the adjuster nut...
  • Page 33 APPENDIX PAGES...

  • Page 34: Important Notice

    IMPORTANT NOTICE YOU MUST CHECK THE FOLLOWING BEFORE STARTING 1) RADIO SWITCH SETTINGS - DOES THROTTLE OPEN & CLOSE? DOES FULL BRAKE APPLY? DOES STEERING OPERATE IN THE RIGHT DIRECTION? IF NOT, CHECK RADIO SETUP SWITCHES. 2) TRUCK THROTTLE AND BRAKE LINKAGE - DOES LINKAGE PULL AND PUSH CORRECTLY WITH RADIO CONTROLS, SPECIAL FOR BRAKING AND THROTTLE CLOSING.
