Service Notes; Technical Data - Audi Navigation Plus Manual

ATTENTION!
All information without warranty!
Manipulating the navigation systems' hard- and software is based on your own risk. We advise you
making updates not by yourself. Please contact an authorized dealer!
While a video (CVBS) signal is fed in, the multimedia interface 1417 is activated! Therefore it is
always switched on or off simultaneously with the connected source. For this reason the connected
source should always be connected with the signal for ignition, avoiding an empty battery. The
multimedia interface 1417 is able to process PAL as well as NTSC. Switching is done automatically.

Service notes

This unit does not need any servicing.
Do not open the housing. There are no user-serviceable parts inside.
Wipe gently with a dry cloth over the surface to clean the unit. If there is more tough dirt, first use a light wet
cloth and then use a dry one. Never use corrosive cleaners to clean the unit.

Technical data

Software: SW 1.2.3
Working Voltage: 10,0 – 14,6 V DC
Quiescent current: 30 mA
Power consumption: 0,40 W
Temperature range: -40 - +85 °C
Weight: 0,192 kg
Dimensions: 114 x 75 x 22 mm
This unit is only for automotive use and has therefore a lifetime of max. 10 years.
®
Audiotechnik Dietz Vertriebs-GmbH
Benzstr. 12
D-67269 Grünstadt
Germany
info@dietz.biz
www.dietz.biz
®
Copyright © by Audiotechnik Dietz Vertriebs-GmbH ● Germany
Rev 0, Stand: 12 / 2006
