Page 1: Operation Manual
CW-5HD Operation Manual US Version 2nd Edition IDX Company, Ltd. - Page 2 CW-5HD TX Important Notification of Use CAUTION IDX requires that CW-5HD TX (transmitter) be installed on the V-Mount interface of a video camera. Depending on connectivity, installing CW-5HD TX with equipment other than a video camera may cause problems to CW-5HD TX or other equipment.
-
Page 3: Table Of Contents
CW-5HD RX ....................9 LED indicators ....................11 3.1. LED indicator functions ................11 CW-5HD Link Initialisation (common to TX/RX) ........ 12 Selecting frequencies and power output ..........13 4.1. Service frequencies and transmitted output by regions ....13 4.2. Automatic frequency selection .............. 13 Link modes - UNICAST/MULTICAST ............ -
Page 4: Safety Instructions
Product misuse may cause fire, shock, injury, product failure or other hazards. Please read this manual prior to using your CW-5HD and retain for future reference. - Page 5 Therefore a license for radio station use is not required to operate this product. CW-5HD uses 5GHz band radio frequencies and it has been shown not to interfere with medical devices. However, when in use, it is recommended to keep the CW-5HD at least 30cm (12in.) away from medical devices to ensure safety.
-
Page 6: Contents
The transmission distance may vary depending on surroundings, radio wave conditions, buildings, etc., the transmission distance of approximately 50m is not guaranteed. When CW-5HD is placed near a device such a TV, the TV image may be disrupted. Please increase the distance between TV and CW-5HD when this happens In locations with many other devices operating in the 5GHz wireless bandwidth, CW-5HD operation can be affected, and images may be interrupted. -
Page 7: Getting Started
Manual selection CH1 CH4 Automatic selection AUTO In AUTO position, transmitted frequency is selected automatically. 4. POWER MODE Selects transmitted output (HIGH/LOW) 5. POWER SW Turns ON/OFF the power of CW-5HD TX. 6. V-Mount Mounts V-Mount type Lithium Ion battery. - 7 -... - Page 8 Multicast mode 10. DC-IN Connects when external power supply is used. Connector XLR-4P male connector Input range DC 11 17V Pin assign No.1 negative(-) No.4 positive(+) 11. V-Plate Mounts CW-5HD TX to the V-Mount of selected source. - 8 -...
-
Page 9: Cw-5Hd Rx
1. LINK LEVEL LED Indicates intensity of received signal. 2. LINK LED Indicates link status (Link on or Searching). 3. POWER SW Turns ON/OFF the power of CW-5HD RX. 4. V-Mount Mounts V-Mount type Lithium Ion battery. - 9 -... - Page 10 MULTI Multicast mode 8. DC-IN Connects to external power supply. Connector : XLR-4P male Input range : DC 11 17V Pin assign No.1 negative(-) No.4 positive (+) 9. V-Plate Mounts CW-5HD RX to V-Mount of selected device - 10 -...
-
Page 11: Led Indicators
3. LED indicators 3.1. LED indicator functions MODE STATUS LED Indicates the manually selected transmitted output power mode (HIGH/ LOW), and the UNICAST/MULTICAST setting. POWER MODE HIGH 2 lights on POWER MODE LOW 1 light on UNICAST LED light color is Green MULTICAST LED light colour is Amber LINK LED... -
Page 12: Cw-5Hd Link Initialisation (Common To Tx/Rx)
CW-5HD Link Initialisation (common to TX/RX) When the power switch of CW-5HD is turned on or the link of the transmitted signal is lost, the CW-5HD TX and CW-5HD RX will start to search for each other. The three LED lights will alternate on and off from bottom to top in sequence, repeating this process until a link is established. -
Page 13: Selecting Frequencies And Power Output
4. Selecting frequencies and power output The CW-5HD TX is equipped with a FREQ SELECT switch and POWER MODE switch. With the FREQ SELECT switch, the transmitted frequency is set. The frequency selection is needed only on the TX. The frequency of the RX does not have to be selected because RX searches for the transmitted frequency automatically. -
Page 14: Link Modes - Unicast/Multicast
5. Link modes - UNICAST/MULTICAST The UNI/MULTI switch is used to select the link mode. The UNI/MULTI select switches on both the CW-5HD TX and CW-5HD RX must be set in the same mode. 5.1. UNICAST mode 1:1 communication With UNI/MULTI switch in UNI position, CW-5HD links in UNICAST mode. In UNICAST mode, the link is made only between the same serial numbered pair of TX and RX (shipped as a pair). -
Page 15: Multicast Mode 1:N Communication
5.2. MULTICAST mode 1:n communication With the UNI/MULTI switch in MULTI position, the CW-5HD links in MULTICAST mode, in which the CW-5HD TX can send video and audio to more than one CW-5HD RX. In MULTICAST mode, the transmitted signals are not encoded by 256bit AES encryption. -
Page 16: Operation Guide
6. Operation guide 6.1. Set up The CW-5HD does not include the various accessories that may be used in its operation. Please separately access the following items as needed for your specific application prior to use. BNC cable for HD-SDI or SDI signal connectivity IDX ENDURA system batteries or external power supply Note: Power supply;... -
Page 17: If Reception Is Unstable
If reception is not stable, please look for the best condition by adjusting the location, height, and other environmental variables. When CW-5HD TX and RX are used close to each other, the received signal becomes too strong and may disturb the video signal. When they are placed close to each other (less than 3m as an example), set the POWER MODE switch of CW-5HD TX to LOW. -
Page 18: Notes On Use
30m (POWER MODE=HIGH), however this is not a guaranteed operational level When the CW-5HD TX and RX are located close to each other, the received signal may be too strong and may disturb the video. When the CW-5HD TX and RX are used close to each other (say 3m or less as an example), set the POWER MODE switch of CW-5HD TX in LOW mode. -
Page 19: Specifications
III. Specifications 8. CW-5HD TX Video / Audio Video input signal HD-SDI (conforms to SMPTE 292M) SD-SDI (conforms to SMPTE 259M-C) BNC 1 type Video input connector BNC 1 type input signal direct loop through Video output connector SDI Embedded... - Page 20 Display / Operation Power switch Power ON/OFF Input battery power runs through to the output side when the power is OFF. Frequency 5-position rotary switch selector selecting CH1, CH2, CH3, CH4, AUTO Transmitted Slide switch shifting HIGH/LOW output switch UNI/MULTI Slide switch UNI/MULTI switch UNI Unicast mode 1:1 communication / encrypted...
-
Page 21: Cw-5Hd Rx
5765MHz, 5785MHz, 5805MHz, 5200MHz Channels are selected automatically or manually. Transmitted Uplink output in Unicast mode output Automatically set according to the output from CW-5HD TX. MIMO / OFDM / JSCC Transmitting method Antennas Built-in pattern antennas - 2dBi each... - Page 22 Power Battery input 11-17V using P-V2 IDX V-Mount Power supply DC input 11-17V [XLR-4 male : No.1 negative (-)/ No.4 positive (+)] Power output V-Plate IDX A-NH2E or equivalent Applicable IDX ENDURA System Li-ion batteries batteries Battery input power is connected directly to camera side V-Mount. Automatically switches to battery supply when DC supply failed.
- Page 23 The material contained in this manual consists of information that is the property of IDX Company, Ltd. and is intended solely for the use by the purchasers of the equipment described in this manual. IDX Company, Ltd. prohibits the duplication of any portion of this manual or the use herein for any application other that the operation or maintenance of the equipment described in this manual without the express written permission of IDX Company, Ltd.
