User Instruction & Installation Manual
M9 & M10 Searchlight
Product Reference Number:
A2059 – M9 Silver Finish
A2060 – M9 White Finish
A2084 – M10 Silver Finish
A2085 – M10 White Finish
Manufacturer's details:
Francis Searchlights Ltd
Union Road, Bolton
Lancashire, BL2 2HJ, UK
Tel:
+44 (0) 1204 558960
Fax:
+44 (0) 1204 558979
http://www.francis.co.uk
E-mail: sales@francis.co.uk
Manual Part Number: C24187
Distributor details:
Issue: 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M9 and is the answer not in the manual?

Questions and answers

Related Manuals for Francis M9

Summary of Contents for Francis M9

  • Page 1 User Instruction & Installation Manual M9 & M10 Searchlight Product Reference Number: A2059 – M9 Silver Finish A2060 – M9 White Finish A2084 – M10 Silver Finish A2085 – M10 White Finish Manufacturer’s details: Distributor details: Francis Searchlights Ltd Union Road, Bolton...

  • Page 2: Table Of Contents

    CONTENTS - Introduction - Safety Precautions - Technical Information - Unpacking and Installation Instructions - Electrical Installation - Operating Instructions - Fault Finding - Maintenance and Servicing - General Assembly Drawing - Spare Parts List...

  • Page 3: Introduction

    For your future reference please keep this manual in a safe place. Thank you for specifying a product from the Francis Searchlights range. All Francis products are designed to give complete customer satisfaction and are manufactured to the highest engineering standards in order to ensure optimum performance and service life.

  • Page 4: Safety Precautions

    2 - Safety Precautions The following instructions must be adhered to, in order to ensure a safe working environment and the safety of the user. Prevent rain, snow, condensation and water droplets from contacting the lamp as this may cause bulb failure, and possible shattering; Quartz halogen lamps run with a high internal pressure in excess of atmospheric.

  • Page 5: Technical Information

    3 – Technical Information This product has been designed to operate in accordance with the product specification. The M9 & M10 searchlights have the following features: Constructed from marine grade aluminium; Polished, electro-brightened super purity aluminium parabolic reflector; Stove enamel painted;...

  • Page 6: Unpacking And Installation Instructions

    4 - Unpacking and Installation Instructions The following instructions should be read and fully understood prior to installing the equipment to ensure that the correct procedures are followed and all safety precautions are observed. If the equipment has been in storage for a considerable time, it is advisable to conduct a routine maintenance check on all parts before installation.

  • Page 7: Electrical Installation

    5 - Electrical Installation For safety purposes, only competent personnel should perform the electrical installation. All equipment should be installed to current Electrical Regulations and Standards. In order to obtain the maximum light output from the searchlight, it is essential that the full operating voltage of the lamp fitted be applied to the lampholder contacts.

  • Page 8: Operating Instructions

    This equipment is designed for use out of doors, in free air. Never place anything on, or cover, the searchlight when in use as this may present a hazard. M9 Searchlight The searchlight can be tilted ±35° by using the rear handle mounted on the rear of the searchlight.
  • Page 9 Setting to Work Safe service in use necessitates the strict observance of the following precautions. Any article fabricated from quartz or glass is inherently fragile and care should therefore be taken, at all times, when handling lamps; Eye protection must be worn when handling lamps that have been removed from their packaging materials.
  • Page 10 Testing Upon correct installation and connection to an electrical supply, the equipment can be tested in order to ensure its correct performance. A competent person with some knowledge of electrical equipment must carry out this work. Equipment required: Multimeter with leads; Ammeter;...

  • Page 11: Fault Finding

    Fault Finding If a fault occurs the following procedures should be adopted. Any work to be carried out should be conducted by a competent person. A multimeter should be used for fault finding purposes. Fault Lamp fails to light Causes 1) Power not supplied.

  • Page 12: Maintenance And Servicing

    8 - Maintenance and Servicing In order to prolong the service life and performance of your searchlight, the following maintenance guidelines are recommended: Maintenance checks should be conducted before every voyage or at least every three months; Before checking, disconnect the equipment from the supply; Visually inspect the condition of the equipment;...

  • Page 13: General Assembly Drawing

    9 - General Assembly Drawing Drawing Number Description A2060 M9 G.A. A2085 M10 G.A.
  • Page 15 Back To Top...

  • Page 16: Spare Parts List

    Gasket Seal Kit In order to prolong the life and performance of your product, we recommend that you only specify Francis Searchlights spare parts. This will ensure that any warranties on your equipment will not be invalidated. When ordering spare parts please contact the Sales Department at Francis Searchlights Limited.
