User Instruction & Installation Manual
A2661 – VM330 WHITE 115v/240v 350w
A2663 – VM330 MIRRORED STN.S (CHROME) 115v/240v 350w
Manufacturer's details:
Francis Searchlights Ltd
Union Road, Bolton
Lancashire, BL2 2HJ, UK
Tel:
+44 (0) 1204 558960
Fax:
+44 (0) 1204 558979
http://www.francis.co.uk
E-mail: sales@francis.co.uk
Voyager Remote Control
Em Arc Searchlight
Product Reference Number:
Manual Part Number: C24076
Issue: 7
Distributor details:
26-1-17
Advertisement
Table of Contents
Related Manuals for Francis Voyager
Summary of Contents for Francis Voyager
- Page 1 User Instruction & Installation Manual Voyager Remote Control Em Arc Searchlight Product Reference Number: A2661 – VM330 WHITE 115v/240v 350w A2663 – VM330 MIRRORED STN.S (CHROME) 115v/240v 350w Manufacturer’s details: Distributor details: Francis Searchlights Ltd Union Road, Bolton Lancashire, BL2 2HJ, UK...
-
Page 2: Table Of Contents
CONTENTS - Introduction - Safety Precautions - Technical Information - Unpacking and Installation Instructions - Electrical Installation - Operating Instructions - Fault Finding - Maintenance and Servicing - Wiring Diagrams & General Assembly - Spare Parts List... -
Page 3: Introduction
For your future reference please keep this manual in a safe place. Thank you for specifying a product from the Francis Searchlights range. All Francis products are designed to give complete customer satisfaction and are manufactured to the highest engineering standards in order to ensure optimum performance and service life. -
Page 4: Safety Precautions
2 - Safety Precautions The following instructions must be adhered to, in order to ensure a safe working environment and the safety of the user. Note: When unpacking or manoeuvring the searchlight into its fixing position, suitable lifting points must be used in order to prevent damage to the equipment or personal injury. -
Page 5: Technical Information
3 - Technical Information This product has been designed to operate in accordance with the product specification. The VM330 RC searchlight has the following features: All marine grade materials and fixings; Parabolic glass reflector; Stove enamel painted or Mirrored 316 Stainless Steel (Chrome); ... -
Page 6: Unpacking And Installation Instructions
4 - Unpacking and Installation Instructions The following instructions should be read and fully understood prior to installing the equipment to ensure that the correct procedures are followed, and all safety precautions are observed. Note: If the equipment has been in storage for a considerable amount of time, it is advisable to conduct a routine maintenance check on all parts before installation. -
Page 7: Electrical Installation
5 - Electrical Installation For safety purposes, only competent personnel should perform the electrical installation. All equipment should be installed to current Electrical Regulations and Standards. In order to obtain the maximum light output from the searchlight, it is essential that the full operating voltage of the lamp fitted be applied to the lampholder contacts. -
Page 8: Operating Instructions
6 - Operating Instructions This equipment is designed for use out of doors, in free air. Never place anything on or cover the searchlight when in use as this may present a hazard. The searchlight can be remotely positioned via the joystick control panel, with the facility for movement up, down, left and right. - Page 9 Setting to Work Safe service in use necessitates the strict observance of the following precautions. Any article fabricated from quartz or glass is inherently fragile and care should therefore be taken, at all times, when handling lamps; The following safety equipment must be worn when handling lamps eye protection i.e.
- Page 10 When fitting the lamp: Always isolate the equipment from the supply when inserting a lamp; Ensure the circuit is suitably fused; Ensure the lamp is of the correct power rating and type; Check the lampholder is in a good dry condition. Never allow water to collect in the lamp fitting or come into contact with the lamp.
-
Page 11: Fault Finding
7- Fault Finding All fault finding must be conducted by a competent person or qualified Electrical Engineer. Failure of Lamp to light Causes: 1) Power not supplied; 2) Fuse blown; 3) Failed lamp Remedy: 1) Check voltage at supply. If supply is not present the fault is at the customer supply. If power is present, see remedy 2;... -
Page 12: Maintenance And Servicing
8 - Maintenance and Servicing In order to prolong the service life and performance of your searchlight, the following maintenance guidelines are recommended: Maintenance checks should be conducted before every voyage or at least every three months; Before checking, disconnect the equipment from the supply; ... -
Page 13: Wiring Diagrams & General Assembly
9 - Wiring Diagrams and General Assembly Drawing Number Description C25392 Wiring Diagram C23949 Slave Panel Wiring Diagram C24497 Multiple Slave Panel Wiring Diagram A2645 VM330RC General Assembly Drawing C23976 Joystick Control Panel Main Slave & Slave C23991 Joystick Control Panel C24933 Junction Box Assembly Back To Top... -
Page 21: Spare Parts List
C22104-00 In order to prolong the life and performance of your product, we recommend that you only specify Francis Searchlights spare parts. This will ensure that any warranties on your equipment will not be invalidated. When ordering spare parts please contact the Sales Department at Francis Searchlights Limited.
