    Thank you for buying HeliArtist Products.600 scale fuselage is designed as an easy way to assembly. Please read this Instruction manual carefully before assembling the model,and follow all precautions and recommendations in the manual.Make sure to retain the manual for future reference,routine maintenance,and tuning.The scale fuselage is designed for T-REX 600E/Nitro Helicopter series.You can easily put it on your T-REX 600E/Nitro for new clothing.

  • Page 3: Before Assembling

    Fly only in safe areas,away from other people.Do not operate R/C aircraft within the vicinity of homes or crowds of people.R/C aircraft are prone to accidents,failures,and crashes due to a variety of reasons including lack of maintenance,pilot error,and radio interference.Pilots are responsible for their actions and damage or injury happened during the operation or as a result of R/C aircraft models.
  • Page 4 Insert the Plastic Landing Gears into Insert the Aluminum Skids into the the landing gear position on the Main Landing Gears according to the above Scale Body. photo. Use M3x4 Set Screws to secure the Use M3x10 Self-Tapping Screws to secure Aluminum Skids to the Landing Gears.
  • Page 5 Insert the heli assembly into the Guide the tail rod of the heli assembly fuselage. out of the tail hole on the fuselage. Use the sponge collar to hold the Assemble the tail gear box of the heli heli's tail boom according to the above back to the tail boom.
  • Page 6 Glue a LED cover on the bottom position Glue another LED cover on the top of the of the front canopy cover according to fuselage body. the photo shown above. Fit the Vertical stabilizer onto the Cut the Side Window covers as to fit the trough on the Horizontal stabilizer and side window on the fuselage and glue it use epoxy to secure them.
