LED MOUNTING
1. Ask the customer where to mount the LED.
2. It must be easily visible from any direction, but should
not be exposed to direct sunlight.
3. To mount:
a.
Press the LED out of its plastic receptacle.
b. Drill an 8mm hole in the desired LED location.
c.
Press the receptacle into the hole from the front.
d. Press the LED into the receptacle from behind.
TESTING THE INSTALLATION
When the installation is complete, follow the Owner's
Manual and completely test the unit.
MOUNTING THE CONTROL MODULE
Screw it onto the car body out of sight, or cable-tie to the
vehicle's wire harness or other suitable location.
DEACTIVATION COIL INSTALLATION
NOTE: Be sure to inform the customer if you choose to
install the deactivation coil in a location other than
those shown below.
Best Range
Around
ignition
cylinder
Below
ignition
cylinder
Correct
Best Range
No bends or kinks
in the antenna
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the SECO-LARM policy is one of continual development and
improvement. For this reason, SECO-LARM reserves the right to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
®
SECO-LARM
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
Inferior Range
Too far back
Touches the
cylinder
Incorrect
Angle faces away
from key
Inferior Range
Antenna is bent
Website: www.seco-larm.com
E-mail: sales@seco-larm.com
SLI-762PP-ISS CONNECTION DIAGRAM
+12VDC (Red label)
Ground (Black label)
+12VDC (Red label)
(Black label)
Ignition (Purple label)
Ground (Black label)
Spare Armed Output to cut fuel pump
(Brown label, circuit 3)
+12VDC (Red label)
Spare Armed Output to cut fuel pump
(Brown label, circuit 3)
NOTE: This wire must
Ignition (Purple label)
show +12V when the
ignition switch is in the
NOTE: This wire must
ON and START position.
Spare Armed Output to cut fuel pump
show +12V when the
(Brown label, circuit 3)
NOTE—This wire
ignition switch is in the
must show + 12V
ON and START position.
when the ignition
NOTE: This wire must
switch is in the ON
show +12V when the
and START position.
ignition switch is in the
ON and START position.
Black heat shrink
3
Starter Solenoid
Circuit 1
(Red tube, Circuit 1)
Starter Solenoid
(Red tube, Circuit 1)
Starter Solenoid
(Red tube, Circuit 1)
Black heat shrink
Ignition Coil
3
(White tube, Circuit 2)
Circuit 2
Ignition Coil
Ignition Coil
(White tube, Circuit 2)
(White tube, Circuit 2)
Copyright © 2011 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be
reproduced or copied, in whole or in part, without the written permission of SECO-
NOTES:
1. PURPLE label ignition wire
must be connected at all times
for proper operation.
2. RED label power wire must be
connected via 5A fuse.
3. Circuit 1 or Circuit 2 must be
used to disable the starter in
Ground (Black label)
order to be consistent with
explanations in the Owner's
Manual.
Ground (Black label)
Ground (Black label)
Ground (Black label)
LED
5A
Constant
Black 2-strand
+12VDC
5A
Two separate sources
Switched
Constant
of chassis ground.
+12VDC
+12VDC
(Black label)
Switched
Ignition (Purple label)
+12VDC
(White label)
N.O. door (—) switch
* DIODE 1N4001
5A
(optional)
Switched
Constant
1
(Purple
label)
+12VDC
+ 12VDC
* DIODE 1N4001
87a
Switched
.
.
(optional)
+12VDC
86
2
(Red
label)
5A
30
(Green label) Circuit 3
87a
86
30
* DIODE 1N4001
(optional)
87
87a
86
85
30
Fuel
Pump
Ignition coil
Ignition coil
Ignition coil
