Page 1: User Manual
Powerlink Speaker Adaptor OneRemote Type 30012718 User Manual OneRemote - www.oneremote.dk 30012718u1uk... - Page 2 Content Operation................................3 Plug & Play ............................. 3 Installation ................................. 4 Sound level balancing ..........................4 PowerLink Speaker Adaptor 2718 – Application Examples ................5 Non B&O TV, all Beo4 operated ........................ 5 B&O system with PowerLink Speaker Adaptor connecting: Airport Express, Bluetooth adapter or DAB+ tuner ................................
- Page 3 Operation The OneRemote PowerLink Speaker Adaptor is for use with active (powered) B&O speakers or B&O power amplifiers like ML/MCL Converter, connected to the sound source using PowerLink DIN cables. The 2718 PowerLink Speaker Adaptor enables PowerLink connected speakers or amplifiers to be shared by two sound sources. Switching between the connected sources is automatic.
- Page 4 Installation The OneRemote PowerLink adaptor is easily installed. 1. Connect the speakers with PowerLink cable(s). Not included. 2. Connect the B&O sound source with a PowerLink cable. Not included. Connect the (non- B&O) AUX source using the appropriate cable. Not included. 4.
- Page 5 PowerLink Speaker Adaptor 2718 – Application Examples When the B&O radio is powered up, sound Non B&O TV, all Beo4 operated from the radio is automatically routed to the speakers. When only the TV is powered up, TV sound is routed to the speakers. If Beo4 is modified with a OneRemote RMB4 converter, it can operate both the TV and the radio.
- Page 6 Specifications Included with this PowerLink Adaptor: Power Adaptor, 12VDC @ 400mA PowerLink Adaptor Connecting cables Not included with the Sockets: Powerlink IN: DIN 8-pin B&O radio, TV or similar. Powerlink OUT: DIN 8-pin PowerLink. AUX IN: 3.5 mm Stereo Jack. Power supply: 12 VDC Connects to any B&O PoweLlink speaker and amplifier like:...
