  • Page 1 RICHIE SAMBORA MEX. STD. STRAT 1132700 Pg. 1 of 4 12-20-2000 Rev. A...
  • Page 2 RICHIE SAMBORA MEX. STD. STRAT 1132700 PICKGUARD ASSEMBLY GROUND TO SPRING CLAW BRIDGE ASSEMBLY USE 3MM ADJUSTMENT WRENCH (2) PLCS. P/N 051548 USE 2.5MM ADJUSTMENT WRENCH (6) PLCS. P/N 051549 USE 3MM ADJUSTMENT WRENCH (6) PLCS. P/N 051548 Pg. 2 of 4 12-20-2000 Rev.
  • Page 3 RICHIE SAMBORA MEX. STD. STRAT 1132700 REF.# DESCRIPTION 0047387000 Neck, Sambora Stratocaster, R/W 0037429000 Tuning Key, (1) Set 0053106000 Washer 0053107000 Bushing 0051554000 Top Nut 0051551000 Mounting Screw 0051548000 Adjusting Wrench 0051559000 Top Nut Section 0051560000 Mounting Screw 0053379000 Shim, .004 Thick 0053380000 Shim, .008 Thick...
  • Page 4 RICHIE SAMBORA MEX. STD. STRAT 1132700 SWITCH & CONTROL FUNCTION 5 WAY SWITCH POSITION 5 WAY SWITCH POSITION T1&T2 TONE CONTROL NECK PICKUP MIDDLE PICKUP BRIDGE PICKUP (A) BRIDGE PICKUP (B) PICKUP IS OFF PICKUP IS ON NECK PICKUP MIDDLE PICKUP...
