Summary of Contents for Fender Squier
- Page 1 P/N 991-6027-108 © 2002 FMIC...
- Page 2 TROUBLESHOOTING SQUIER PACK AND SETUP GUIDE...
-
Page 3: Troubleshooting Guide
SQUIER ® PACK TROUBLESHOOTING GUIDE No sound from the instrument or amplifier. 1. Is the instrument cable plugged into both the guitar and amplifier properly? 2. Is the amplifier power cord properly plugged into an electrical outlet? 3. Is there power at the electrical outlet? 4. - Page 4 Broken String. Visit your local Fender Dealer to purchase replacement strings. If you need detailed information or assistance with restringing your guitar, ask your Dealer or visit the Setup page of our...
- Page 5 (i.e. how hard you pick, strum or fret the guitar or bass). If you are not comfortable performing these adjustments to your instrument, take it to an Authorized Fender Service Center for a “setup”. Note: Setups and adjustments are not covered under warranty.
- Page 6 Truss-Rod Adjustment String tension exerts a tremendous bending force on the neck of the instrument. The adjustable steel truss rod in the neck employs a counter-force to the pull of the strings. If these two opposing forces are not in harmony with each other, the result will be a poorly playing instrument.
- Page 7 If you don’t have feeler gauges, don’t give up. You can approximate the gap, which is about the thickness of a regular business card and a piece of paper put together. Squier ® Fingerboard Relief Instrument...
- Page 8 If you meet excessive resistance, if your neck needs constant adjustment, or you’re not comfortable adjusting it yourself, take your instrument to an authorized Fender ® Service Center. String Height Adjustment (Action) for Electric Guitars & Basses First, check your tuning. Then, using your ruler, measure the distance between the bottom of each string and the top of the 17th fret.
-
Page 9: Warranty
Musical Instruments Corporation warrants that the instrument and accessories included in the Squier Pack you have purchased shall be free of defects in parts and workmanship, if used under normal operating conditions, for a period of one (1) year from the date of purchase. This warranty applies only to the original retail purchaser when this Squier Pack is purchased from an Authorized Squier Dealer and is subject to the limitations set forth herein. - Page 10 Defective products that qualify for coverage under this warranty will be repaired or replaced with a like or comparable model, (at Fender's discretion), without charge, by the Dealer. To receive warranty service, return the complete product to the Authorized Fender Dealer from whom it was purchased, with your sales receipt as proof of purchase, during the applicable warranty period.
- Page 11 NOTES...
