Tiger SUPERCLEAN Operating Instructions

THE INSTALLATION AND SERVICING OF THIS APPLIANCE MUST BE SUPERVISED BY A
QUALIFIED SOLID FUEL ENGINEER. THE SUPPLIERS WILL ACCEPT NO RESPONSIBILITY
WHATEVER FOR APPLIANCES NOT SO INSTALLED.
UK: The Solid Fuel Association, 7 Swanwick Court Alfreton Derbyshire DE55 7AS Tel:0845-601-4406 www.solidfuel.co.uk
THIS APPLIANCE BECOMES
AND CAN PRODUCE
A fire-guard should be used if children or the infirm are present. The
installer is required to EXACTLY follow these instructions and to
completely comply with all local, national and international standards.
Building regulations for the UK, RoI and IoM can be found at
ASBESTOS: Tiger does not contain asbestos, but you should be careful to
avoid disturbing any asbestos when removing an old installation.
FIRE CEMENT is caustic - wash your hands thoroughly after using it.
WEIGHT Protect your spine by moving the stove only with assistance.
FUME EMISSION: Properly installed and operated this appliance will not
emit fumes into the dwelling. Occasional fumes from de-ashing and refuelling
may occur. However, persistent fume emission is potentially dangerous and
must not be tolerated. If fume emission persists, then the following immediate
action should be taken:
(a) open doors and windows to ventilate the room. (b) let the fire go out or
eject and safely dispose of fuel from the appliance. (c) check the flue or
chimney for blockage and clean if required. (d) do not attempt to re-light the
fire until the case of the fume emission has been identified and corrected. If
necessary seek expert advice

BEFORE YOU BEGIN

YOUR CHIMNEY creates the draught which makes your Tiger work - it must:
• Generate a draught in use of at least 12Pa (0.05ins wg)
• Be capable of withstanding the temperatures generated.
• Be incapable of leaking fumes into the dwelling
This will commonly be achieved by it:
• Being at least 5m high.
• Terminating at least 1m above any roof ridge.
• Having an internal cross-section not less than 0.018m² (eg 150mm dia) and never more than 0.14m² (eg 375 x 375mm)
• Being free from even the slightest crack or source of leakage.
• Having no bends sharper than 45º.
• Being entirely free of obstructions and swept by a qualified chimney sweep.
• Being connected only to this one appliance.
• Being of thick (100mm+) masonry or otherwise adequately insulated.
• Conforming to local building regulations.
Special rules apply where the flue passes through timber, thatch or other vulnerable materials- take specialist advice.
INSTALLATION CLEARANCES The stove must be placed on a solid non-combustible hearth conforming to building regulations.
There must be no combustible material, including fuel, within: Rear 40cm, sides 30cm. If the Europa Hi-Leg unit is fitted hearth
temperature will not exceed 100ºC, and light duty hearth material may be used. If the Europa Hi-Leg unit is used as a log store, logs
must not be placed higher than the central 'bridging' member.
LOAD BEARING Tiger is heavy - take care to ensure that the floor has adequate load-bearing capacity and consider fitting a load
distributing plate if necessary
Tiger SuperClean Stoves may be used in smoke control areas strictly in accordance with these instructions, when burning:
UK: Untreated wood logs or smokeless fuels (s21 of the Clean Air Act 1993)
RoI: Wood logs, smokeless fuels or peat briquettes, but not petroleum coke (Control of Atmospheric Pollution Regulations,
1970)
TIGER SUPERCLEAN
CAST-IRON MULTI-FUEL STOVE
INSTALLATION AND OPERATING
LEAVE THIS DOCUMENT WITH THE HOUSEHOLDER !
RoI: Irish Nationwide Fireplace Organisation, 162 Capel Street, Dublin 1 Tel:01-801-5959 www.fireplace.ie
EXTREMELY
POISONOUS
www.tiger-stoves.com
INSTRUCTIONS
document v. 152 of 03/08/10
A register of qualified engineers is available from:
HOT
Conforms to
GASES.
EN 13240:2001+A2 2004
Independently tested in 2010 by SGS
Approved Laboratory No 0608
Efficiency
Rated Output
CO (at 13% O
Mean Flue
Temperature
Clearance to
combustibles
Smoke Emission
Flue Draught
Other fuels: Anthracite, peat and smokeless fuels
1
Intermittent burning solid fuel roomheater for
installation with a single dedicated chimney
Fuel Wood (Beech)
)
2
Gas flow
Minimum 12 Pa
Mass
74%
5 kW
0.15 %
320º C
40cm
78 mg/m³
4.9 g/sec
96 kg
