DISASSEMBLING YOUR BREVILLE 800 CLASS JUICER

STEP 1. STEP 2.
Push the "OFF" button on the 800 Class Juicer Remove the pulp container by holding the
and then unplug from the power outlet. handle and pivoting the bottom of the Pulp
Container away from the juicer.
16
DISASSEMBLING YOUR BREVILLE 800 CLASS JUICER
STEP 3.
Place both hands on either side of the Locking
Arm and pull back and lift over the grooves on
either side of the Juicer Cover.
STEP 4. STEP 5.
Move the Locking Arm down. Lift the Juicer Cover off the 800 Class Juicer.
STEP 6.
To remove Stainless Steel Filter Basket, hold
base of juicer and turn Filter Bowl Surround by
the Juice Spout.
17
