Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
Model Series CS 2210
Chipper Shredder — Model Series CS 2210 & CS 3210
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-07268
(July 20, 2011)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S 2210 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cub Cadet S 2210 Series

Summary of Contents for Cub Cadet S 2210 Series

  • Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No. 769-07268...

  • Page 2: Table Of Contents

    Visit us on the web at www.cubcadet.com ◊ Call a Customer Support Representative at (800) 965-4CUB ◊ Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write us at Cub Cadet • P.O. Box 361131 • Cleveland, OH • 44136-0019...

  • Page 3: Safe Operation Practices

    Important Safe Operation Practices WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
  • Page 4 Safe Handling of Gasoline: If it becomes necessary to push material through the shredder hopper, use a small diameter stick. Do not use To avoid personal injury or property damage use extreme care your hands or feet. in handling gasoline. Gasoline is extremely flammable and the If the impeller strikes a foreign object or if your machine vapors are explosive.
  • Page 5 Notice Regarding Emissions Before cleaning, repairing, or inspecting, stop the engine and make certain the impeller and all moving parts have Engines which are certified to comply with California and federal stopped. Disconnect the spark plug wire and ground it EPA emission regulations for SORE (Small Off Road Equipment) against the engine to prevent unintended starting.
  • Page 6 Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate WARNING—...

  • Page 7: Assembly & Set-Up

    Assembly & Set-Up Contents of Carton • One Chipper Shredder • One Operator’s Manual • One Engine Operator’s Manual • One Tow Bar • One Bag • One Safety Glasses • One Bottle of Oil Assembly To attach the bag: NOTE: This unit is shipped without gasoline or oil in the engine.
  • Page 8 Tow Bar Set-Up To attach the tow bar: Gas and Oil Fill-Up Remove the spring pin and clevis pin from the end of the Refer to the separate engine owner’s manual for additional tow bar receiver. See Fig. 3-3. engine information. Add oil provided before starting unit for the first time out of the box.

  • Page 9: Controls & Features

    Controls and Features Hopper Handle Spring Latch Chipper Chute Recoil Starter Tow B Lock Rod Receiver Model Series CS 3210 Shown Figure 4-1 Recoil Starter Chipper Chute The recoil starter is located on the engine. Pull the recoil starter Branches up to two inches (model series CS 2210) or three inches to start engine.

  • Page 10: Operation

    Operation WARNING: NOTE: A “clanking” noise may be heard when pulling the The operation of any chipper shredder starter rope. It is completely normal and does NOT indicate can result in foreign objects being thrown into the a malfunction of any kind. eyes, which can damage your eyes severely.
  • Page 11 Shredding Chipping Yard waste such as leaves and pine needles can be placed in WARNING: Never operate the chipper shredder the hopper for shredding. After material has been processed by without chipper chute lowered into the operating the shredder blade and flails, it will be forced out of the chute position.

  • Page 12: Maintenance & Adjustment

    Maintenance & Adjustments Maintenance Equipment Care • Clean the chipper shredder thoroughly after each use. General Recommendations • Wash bag periodically with water. Allow to dry thoroughly • Always observe safety rules when performing any in shade. maintenance. • If the reduction chamber becomes clogged, remove and •...
  • Page 13 Cleaning The Reduction Chamber Remove the hairpin clip from the clevis pin which extends through the housing and shredder screen. See Fig. 6-1B. WARNING: The impeller’s shredder blade and Remove clevis pin. chipper blades are sharp. Wear leather work gloves Pivot the shredder screen upward.

  • Page 14: Service

    Service Blade Care Install a replacement blade (Part No. 742-0544) with the hardware removed earlier or sharpen. Chipper Blades IMPORTANT: When sharpening the blade, protect hands by using gloves. Follow the original angle of grind and make WARNING: The impeller’s chipper blades are sure to remove an equal amount from each blade.
  • Page 15 Remove six flange nuts which secure hopper inlet guide to Remove the two internal hex screws, hex lock nuts, and impeller housing. See Fig. 7-3A. lock washers which secure the shredder blade to the impeller. See Fig. 7-3B. NOTE: Use a 3/16” hex key (Allen) wrench on the outside of the shredder blade and a 1/2”...

  • Page 16: Troubleshooting

    Troubleshooting Problem Cause Remedy Engine Fails to start 1. Throttle lever not in correct starting position. 1. Move throttle lever to FAST or START position. 2. Spark plug wire disconnected. 2. Connect wire to spark plug. 3. Choke not in CHOKE position (if equipped). 3.

  • Page 17: Replacement Parts

    Replacement Parts Component Part Number and Description 942-04050 Shredder Blade 942-0544B Chipper Blade 719-04308 Flail Blade (3 total) 634-04627 10 x 4.0 Pneumatic Wheel with Bearings Phone (800) 965-4CUB to order replacement parts or a complete Parts Manual (have your full model number and serial number ready).
  • Page 18 Notes...
  • Page 19 10 — n ection oteS...

  • Page 20: Back Cover

    MANUFACTURER’S LIMITED WARRANTY FOR CHIPPER-SHREDDERS & CHIPPER-SHREDDER VACUUMS The limited warranty set forth below is given by Cub Cadet LLC with d. Cub Cadet does not extend any warranty for products sold or respect to new merchandise purchased and used in the United States,...
