- Page 1 ATV BOOM KIT ITEM #268195 ® M268195H.1 OWNER’S MANUAL 0 2 3 8 SHOWN ATTACHED TO ATV SPOT SPRAYER #268199 (NOT INCLUDED) Any Questions, Comments or Problems? Call Customer Service 1-800-270-0810...
- Page 2 THANK YOU Thank you for purchasing the North Star ATV Boom Kit. The assembly instructions that follow will help you attach the kit to your existing North Star Spot Sprayer. The numbers in parenthesis throughout the manual refer to the diagram number on the parts explosion and corresponding component list.
- Page 3 FASTENERS-268195 PARTS Any Questions, Comments or Problems? Call Customer Service 1-800-270-0810...
- Page 4 PRE-ASSEMBLY STEP 1: Loosen the hose clamp on the existing gun hose. Remove the hose from the pump. Save the hose clamp for step 3. 01394 STEP 2: Slide on one hose clamp onto one end of the supply hose. Push the hose onto the outlet of the pump.
- Page 5 STEP 4: Attach the nozzle arm to the boom mount pivot with (2) 5/16-18 x 3/4” flange bolts, (2) 5/16 flat washers, and (2) 5/16-18 flange Nuts. do not tighten NOZZLE ARM bolts until STEP 5. 5/16-18 X " FLANGE BOLT 5/16"...
-
Page 6: Operating Instructions
STEP 7: Attach the 3/8” boom supply hose to the " BO O M S U PP LY H O S E 3/8” hose barb and attach with the hose " H O S E C LA M P clamp. Complete the adjustment of the boom mount pivot by rotating the boom assembly until the upright of the nozzle arm is perpendicular to the ground. - Page 7 BOOM KIT CALIBRATION Below are some guidelines to help you calibrate your boom sprayer. This is a very important step in operating your boom sprayer so that you don’t apply too much or too little chemical. 1. Use the suggested application rate (i.e. gallons per acre, 1000 sq.ft., or 100 sq.ft.) 2.
- Page 8 Parts Explosion 268195 Rev. H.1 EXISTING GUN HOSE PUMP, ELBOW , SUCTION HOSE, INTAKE TUBE, AND TANK ARE PART OF THE SPRAYER AND ARE NOT INCLUDED W ITH THIS BOOM KIT PUMP ELBOW SUCTION HO SE INTAKE TUBE TANK Diag. #...
- Page 9 This page has intentionally been left blank.
- Page 10 Manufactured by Northern Tool + Equipment Co., 2800 SouthCross Drive West P.O. Box 1499 Burnsville, MN 55337-0499...
