SMART BOOSTER
(SMB413)
User's Manual
TABLE OF CONTENTS
SAFETY INSTRUCTIONS ...........................................................................................................................................................2
Chapter 1 : INTRODUCTION .......................................................................................................................................................4
Chapter 2 : INSTALLING .............................................................................................................................................................5
Chapter 3 : TECHNICAL DESCRIPTION....................................................................................................................................6
Chapter 4 : TECHNICAL SPECIFICATIONS ..............................................................................................................................7
Chapter 5 : CONNECTIONS .........................................................................................................................................................9
WARRANTY...............................................................................................................................................................................11
®
ANALOG WAY
SMART BOOSTER™
EDITION : 04/02
.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Analog way SMART BOOSTER SMB413
Summary of Contents for Analog way SMART BOOSTER SMB413
-
Page 1: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ................................2 Chapter 1 : INTRODUCTION ...............................4 Chapter 2 : INSTALLING ................................5 Chapter 3 : TECHNICAL DESCRIPTION............................6 Chapter 4 : TECHNICAL SPECIFICATIONS ..........................7 Chapter 5 : CONNECTIONS .................................9 WARRANTY....................................11 ® ANALOG WAY SMART BOOSTER™ EDITION : 04/02... -
Page 2: Safety Instructions
SMART BOOSTER™ SAFETY INSTRUCTIONS All of the safety and operating instructions should be read before the product is operated and should be retained for further reference. Please follow all of the warnings on this product and its operating instructions. CAUTION : WARNING : To prevent the risk of electric shock and fire, do not expose this device to rain, humidity or intense heat sources (such as radiators or direct sunlight). - Page 3 SMART BOOSTER™ SICHERHEITSHINWEISE : DEUTSCH Um den Betrieb dieses Geräts zu verstehen, raten wir Ihnen vor der Inbetriebnahme alle Sicherheits und Betriebsanweisungen genau zu lesen. Diese Sicherheits- und Betriebsanweisungen für einen späteren Gebrauch sicher aufbewahren. Alle in den Unterlagen, an dem Gerät und hier angegebenen Sicherheitsanweisungen einhalten.
-
Page 4: Chapter 1 : Introduction
Chapter 1 : INTRODUCTION SMART BOOSTER™ ™ SMART BOOSTER Chapter 1 : INTRODUCTION 1-1. SUPPLIED EQUIPMENT • 1 SMART BOOSTER ™ (SMB413). • 1 AC Power Supply Cord. • 1 VGA M / M HD 15 Cable (1.8 m / 6 ft). •... -
Page 5: Chapter 2 : Installing
SMART BOOSTER™ Chapter 2 : INSTALLING Chapter 2 : INSTALLING 2-1. TABLE TOP MOUNTING ™ The SMART BOOSTER can be used directly on a table. The unit is delivered with 4 plastic feet. 2-2. RACK MOUNTING ™ The SMART BOOSTER is compatible with a 19"... -
Page 6: Chapter 3 : Technical Description
Chapter 3 : TECHNICAL DESCRIPTION SMART BOOSTER™ Chapter 3 : TECHNICAL DESCRIPTION 3-1. FRONT PANEL POWER: LED Indicator. 3-2. REAR PANEL POWER INPUT: Standard IEC connector (100-250 VAC, 50-60 Hz, Automatic). COMPUTER INPUT: On HD 15 female connector. OUTPUTS (1→3): On HD 15 female connector. -
Page 7: Chapter 4 : Technical Specifications
SMART BOOSTER™ Chapter 4 : TECHNICAL SPECIFICATIONS Chapter 4 : TECHNICAL SPECIFICATIONS 4-1. COMPUTER INPUT(ON HD 15 OR BNC CONNECTORS) Software compatibility: All software compatible. PC, MAC , WORKSTATION. Hardware compatibility: Resolution : From VGA (640 x 480) to UXGA (1600 x 1280). RGsB, RGBS, RGBHV compatible. - Page 8 Chapter 4 : TECHNICAL SPECIFICATIONS SMART BOOSTER™ 4-4. C.VIDEO (ON 1 BNC FEMALE CONNECTOR) 15.625 kHz / 50 Hz (625 L) ..… 15.735 kHz / 60 Hz (525 L). Levels: 1 Vp/p (0.7 Vp/p Luma + 0.3 Vp/p Sync.). Impedance: 75 Ohms.
-
Page 9: Chapter 5 : Connections
SMART BOOSTER™ Chapter 5 : CONNECTIONS Chapter 5 : CONNECTIONS 5-1. SMART BOOSTER ALONE VIDEOTAPE COMPUTER (YUV) CAMERA PC/MAC) (S.VIDEO) VCR (C.VIDEO) AC POWER SUPPLY DATA MONITOR MONITOR MONITOR MONITOR UP TO 3 UP TO 3 UP TO 3 UP TO 3 PAGE 9... - Page 10 Chapter 5 : CONNECTIONS SMART BOOSTER™ 5-2. SMART BOOSTER WITH SMART-CUT 2 PAGE 10...
-
Page 11: Warranty
SMART BOOSTER™ WARRANTY Analog Way warrants the product against any defects in materials and workmanship for a period of three years from the date of purchase (back à the factory). In the event of any malfunction during the warranty period, Analog Way will, at its option, repair or replace the defective units, including free materials and labor.
