MAESTRO
Service Manual
TABLE OF CONTENTS
Specifications ........................... ..........................................................
Mechanical Instructions Set Disassembly....................................
Mechanical Instructions Set Re-assembly...................................
Exploded view & Mechanical Parts list............................................
Exploded view - Docking station.......................................................
Electrical diagrams - Docking station.............................................
Mechanical instructions & Set Disassembly..................................
Mechanical & Electrical Parts list - Docking station.....................
Published by AVS 0639 Service RCS
Subject to modification
TSU9600
/00/05/37/79
DS9600
Page
1
2
3
4
5
6
7
8
3104 205 5026-1
Advertisement
Related Manuals for Philips Maestro DS9600
Summary of Contents for Philips Maestro DS9600
- Page 1 MAESTRO TSU9600 /00/05/37/79 DS9600 Service Manual TABLE OF CONTENTS Page Specifications ..................Mechanical Instructions Set Disassembly........Mechanical Instructions Set Re-assembly........Exploded view & Mechanical Parts list..........Exploded view - Docking station............Electrical diagrams - Docking station..........Mechanical instructions & Set Disassembly........Mechanical &...
- Page 2 A. GENERAL REQUIREMENTS Operating temperature : between 5 °C and 45 °C Storage temperature : between -25 °C and +70 °C Atmospheric pressure : 96 K Pa ± 6 K Pa Relative humidity : between 40 and 80 % Transmitted code : RC5, RC6, and learnable format Infrared wavelength: : 950nm ±...
- Page 3 MECHANICAL INSTRUCTIONS Set Disassembly 1. Remove carefully the approbation sticker 2. Remove one rubber feet item 07 item 676 with the help of a label remover. on the right upper corner to make the screw accessible. 3. Remove 5 x screw (Torx screw M2x10). 3.
- Page 4 MECHANICAL INSTRUCTIONS Set Disassembly 4. Remove PB (item 1002) includes docking insert (item 22) by release the two “plastic snap hooks” as shown in the picture. 5b. Take battery out, disconnect battery plug 5a. Disconnect PB (item 1002) to release the flex-cable (item 251) on connector 1701 (unlock connector 1003 with the help of a pincet).
- Page 5 MECHANICAL INSTRUCTIONS Set Disassembly 7. - Release bottompart (item 02) from toppart (item 01). step 2: continue with the “top” as shown in the picture. - Put a sharp knife between toppart and bottompart and use this as a lever to separate the two parts. - Important: push up the toppart compared with the bottompart.
- Page 6 MECHANICAL INSTRUCTIONS Set Disassembly 11. To release the PB (item 1001), remove 5 X screws (Torx M2X6) as shown in the picture. item 01 item 05 toppart sub assy Backlight key item 25 spring pen item 08 keymat stdby item 09 keymat cursor 12.
- Page 7 MECHANICAL INSTRUCTIONS Set Disassembly Overview mechanical toppart components. Set Disassembly components. 1001 1002 Overview snap holes in bottompart. (for info only)
- Page 8 MECHANICAL INSTRUCTIONS Set Disassembly and Re-assembly Replacement off LCD module item 16 release the LCD bezel item 17 from PB 1001, release the flex cable from LCD item 16 to unlock the push downwards to unlock the 4 plastic snaps in connector 1401 by till up the lid from connector 1401 the snap holes as indicated in the picture.
- Page 9 MECHANICAL INSTRUCTIONS Set Re-assembly item 01 toppart sub assy includes touchscreen (item 10) add 2 X screw M2X4 1. take toppart assy item 01 2. mount Cursor ring item 27 3. mount Cursor holder item 28 4. Add 2 X screw (Torx M2X4) on the position as shown in the picture item 27 item 28...
- Page 10 MECHANICAL INSTRUCTIONS Set Re-assembly connect the speaker plug into connector 1601 12. take the bottompart item 02. 13. plug in the speaker plug (item 254) to connector 1601. 14. plug in the flex cable touchscreen into connector 1402. 15. lock connector 1402. item 8000 mount the flex cable from touchscreen into flex cable...
- Page 11 MECHANICAL INSTRUCTIONS Set Re-assembly 25. place PB item 1002 same with Docking insert (item 22) includes On-Off switch (item 33) on the correct position between the two”snap hooks” Remark: Be sure that item 33 is in the same position as the position from switch 1706 located on PB item 1001 snap hook snap hook...
- Page 12 PERSONAL NOTES:...
- Page 13 Note: Only the parts mentioned in this list are normal service parts 3104 200 07120 Approbation sticker For more information: E-mail: erik.gybels@philips.com 3140 118 33800 AC/DC Adaptor AY3192/00 only for /00 3140 118 33810 AC/DC Adaptor AY3192/05 only for /05...
- Page 14 DOCKING STATION DS9600...
- Page 15 EXPLODED VIEW - Docking Station DS9600...
- Page 16 ELECTRICAL DIAGRAMS Docking Station DS9600 V5V0 V5V0 1003 1001 HEC3600-016110 MX21_BOOTSEL V_USB D-_R 1002 D+_R V_USB GND_USB D-_R UART1_TXD D+_R UART1_RXD LED_DOC GND_USB SFV20R-2STE1 TCX0101-111177 1005 MX21_BOOTSEL RE-H022TD-1130 1004 UART1_TXD UART1_RXD RE-H032TD-1130 OPTION V5V0 6001 3001 330R LTL-1CHEE-072A 3002 V5V0 6002 WHITE 3004...
- Page 17 ELECTRICAL DIAGRAMS Docking Station DS9600 V5V0 V5V0 FF9-20A-R16A 1002 MX21_BOOTSEL V_USB D-_R D+_R GND_USB UART1_TXD UART1_RXD LED_DOC TZG-RD14-S1-FA 1001 3104 203 3578-2 SH130 2006-08-25 3104 203 3578-2 SH132 2006-08-25...
- Page 18 MECHANICAL INSTRUCTIONS Docking Station DS9600 Set Disassembly To release the Docking Station from the groundplate (item 34) remove 2 x screw as indicated in the picture. 2 X screw (Torx M2X10) 2 X screw (Torx M2X4) Till up toppart, all PB’s are accessible now 1.
- Page 19 3104 207 15630 Service Docking station Note: Only the part mentioned in this list is a normal service part For more information : E-mail: erik.gybels@philips.com for information only! (no service parts): 3104 207 82090 Toppart sub assy_TSU9600 3104 207 82100 Bottompart dock.
