Elecom TK-FBM032EBK User Manual page 2

3
Pairing the Keyboard with a Connected Device
When using Mac OS X
When using Mac OS 10.5.x
„
„ When using Mac OS 10.6.x
From the Bluetooth menu,
From the Bluetooth menu,
click [Set up Bluetooth
click [Set up Bluetooth
Device].
Device...].
The Bluetooth Setup Assistant is
The Bluetooth Setup Assistant is
displayed.
displayed.
If the Bluetooth menu is not displayed, from the Apple menu,
click [System Preferences]. When the [System Preferences]
window is displayed, click [Bluetooth], and then click on
the [Bluetooth] window.
Press the CONNECT button.
The Connect/Battery lamp flashes green Click
during the pairing procedure and turns off
when the procedure is complete (step ).
CONNECT button
If a message saying that registration failed is displayed,
check that this product is turned on, and then click
.
Select [TK-FBM032
series], and click Select [Keyboard], and
click
The system starts searching
The passkey is displayed on for Bluetooth devices to add.
the screen.
Use this pro duct to
enter the passkey that
Press the CONNECT button.
displays on the screen.
The Connect/Battery lamp flashes green
Enter the passkey using the
keyboard numerical keys, and during the pairing procedure and turns off
press the "Enter" key.
when the procedure is complete (step
Click .
Select [TK-FBM032
series], and click
The passkey is displayed on
When registration is completed the screen.
successfully, [TK-FBM032
series] appears in the
[Bluetooth] window.
Us e t h is p r o d u c t t o
enter the passkey that
displays on the screen.
Enter the passkey using the
I f t h e k e y b o a rd s e t u p keyboard numerical keys, and
assistant cannot detect the press the "Enter" key.
keyboard, click
and select [ANSI] from the
list of keyboards that is
displayed on the screen.
Click
Then click .
When registration is completed
successfully, [TK-FBM032
You can now use the keyboard.
series] appears in the
[Bluetooth] window.
You can now use the keyboard.
When using PlayStation
This product supports PlayStation
details, refer to "Troubleshooting".
* The following operation example uses System Software ver. 3.66.
From the XMB™ home
menu, select [Settings],
s e l e c t [ A c c e s s o r y
Settings], and then select
[Manage Bluetooth®
Devices].
T h e M a n a g e B l u e t o o t h
Devices screen is displayed.
If the Bluetooth menu is not displayed, from the Apple menu,
click [System Preferences]. When the [System Preferences]
"There ar no Bluetooth®
window is displayed, click [Bluetooth], and then click on
Devices registered. D o
the [Bluetooth] window.
you want to register a
. device?" is displayed.
Select [Yes].
If your Bluetooth device
is already paired with
a Pl a y St a ti o n
of registered Bluetooth
devices will appear. Select
[Register a new device].
Select [Register a new
.
device].
Select [Start Scanning].
The system starts searching
for Bluetooth devices to add.
Press the CONNECT
button.
). The Connect/Battery lamp flashes green
during the pairing procedure and turns off
CONNECT button
when the procedure is complete (step
If a message saying that registration failed is displayed,
check that this product is turned on, and then click
.
Select [TK-FBM032
series].
The pass key is displayed on
the screen.
Use this product to
enter the passkey that
displays on the screen.
Enter the passkey using the
keyboard numerical keys, and
press the "Enter" key.
If this product cannot be found or if a message is displayed
indicating that registration has failed and prompts you to
perform the pairing registration operation again, check that
.
this product is turned on, and perform the following:
• If no Bluetooth devices are already registered with the
PlayStation
• If there are any Bluetooth devices which are already regis-
tered with the PlayStation®3, perform the procedures from
step .
When registration is completed
successfully, [TK-FBM032
series] appears in the list of
registered devices.
S e l e c t [ E n g l i s h ( U S
Standard)] in [Settings] >
[Nearby device settings]
I f t h e k e y b o a rd s e t u p
> [Keyboard type].
assistant cannot detect the
keyboard, click
and select [ANSI] from the
list of keyboards that is
You can now use the keyboard.
displayed on the screen.
Then click .
Troubleshooting
When the product appears to be malfunc-
tioning
3
®
When text cannot be entered or keyboard does not
„
® 3 system software version 3.66. For
work/is unstable
 When key input does not occur for approximately 10 minutes, this
product will automatically switch to power save mode.
It will return to normal mode once any key is pressed.
Enter characters after this has occurred.
 Check that this product and the connected device's Bluetooth function
or Bluetooth adapter are turned on.
 Check pairing status to ensure that this product is paired correctly with
the connected device and that pairing has not been cancelled.
• The Connect/Battery lamp flashes green during the pairing pro-
cedure and turns off when the procedure is complete.
• For details on the PC's Bluetooth function and Bluetooth adapter,
refer to the relevant instruction manuals. Alternatively, contact the
manufacturer.
 The connected device and the keyboard are too far apart or there is a
possibility that the connected device is facing in a direction from which
it cannot receive radio signals.
A d j u s t t h e p o s i t i o n o f t h e
connected device.
The operable range of this
product is the area within a circle
with a radius of 10 m from the
connected device. Depending
on the usage environment, the
keyboard may not operate even
3 , a l is t
®
when it is within approximately
10 m of the connected device.
I n s u c h c a s e s , m o v e t h e
keyboardcloser to the connected
device until operation stabilizes.
 When using this product on a metallic surface such as a steel desk,
radio wave outreach may be shortened. In such cases, move the
keyboard closer to the connected device until keyboard operation
stabilizes.
 Interference may occur if multiple units of this product are used
together or if this product is used with other wireless devices. In this
case, change the channel of other wireless devices.
 Operation becomes unstable when battery power is low. Refer to
"Installing/Replacing the Batteries" on the reverse of this sheet, and
replace the batteries as soon as possible.
• The alkaline batteries supplied with this product are for checking
product operation. These batteries may discharge and drain during
storing and shipping.
• When the remaining battery level gets low, the Connect/Battery lamp
begins flashing green.
* When not using the product, turn the keyboard off to save battery
).
power.
CONNECT button
Checking the PlayStation
version
You must have system software version 3.66 or later to use this product with
PlayStation ® 3.
Follow the procedure below to check the system software version.
From the XMB™ home
menu, select [Settings],
select [System Settings],
and then select [System
Information].
Check that the system software version is 3.66 or
later.
If the system software version is not 3.66 or later, perform a system
update to update the PlayStation
recent version. For details regarding the system update procedure,
refer to the PlayStation 3 manual.
®
® 3, perform the procedures from step .
- 2 -
Basic Specifications
Product name Folding Bluetooth ® Keyboard
Article No. TK-FBM032E series
Devices that support the Bluetooth
Supported devices •
Mac OS X (10.5 to10.5.8, 10.6 to 10.6.7)
•
iPad2, iPad, iPhone 4, 4G iPod touch
•
iPhone 3GS and 3G iPod touch (32GB/64GB) with
•
software updated to iOS 4.0 or later
* Cannot be used with iPhone 3G or first and second
generation iPod touch.
• PlayStation ® 3 (System Software ver. 3.66)
* Depending on the model of the device being used,
the assigned function for various keys and the actual
functions which they perform when pressed may
differ.
Connection method Bluetooth ® wireless
Compliant standard Bluetooth ® v2.0 Class 2
HID (Human Interface Device)
Profile
Radio frequency 2.4 GHz bandwidth
Radio wave method FH-SS modulation
Radio wave outreach Non-magnetic substance (e.g. wooden desk): Approx.
10 m
Magnetic substance (e.g. metal desk): Approx. 3 m
* Values indicated are those obtained by ELECOM
and are not guaranteed.
No. of keys 66 (English layout)
Key type Membrane
Approx. 10 m
Key pitch 17.0 mm
Key stroke 2.2 mm
290.0 (W) x 100.0 (D) x 15.2 (H) mm (when unfolded)
Dimensions
137.3 (W) x 100.0 (D) x 27.0 (H) mm (when folded)
Weight Approx. 230 g * Not including batteries
Operating 5 to 40°C, 90% RH max. (no condensation)
temperature/humidity
-10 to 60°C, 90% RH max. (no condensation)
Storing temperature/
humidity
Batteries x1 AAA alkaline/manganese/rechargeable nickel
hydride battery
Operating time Measure of operating time when alkaline battery is
used
Approx. 2 months
* Values indicated are those obtained by ELECOM
and are not guaranteed.
3 system software
®
® 3 system software to the most
ELECOM CO., LTD.
1-1 Fushimi-machi 4-Chome Chuoku, Osaka Japan 541-8765
URL: http://www.elecom.co.jp/global/
overseas@elecom.co.jp
宜麗客 （上海） 貿易有限公司
上海市徐匯区肇嘉浜路1065甲号飛雕国際大厦704 号
電話 : 86-21-33680011
FAX : 86-21-64271706
URL : http://www.elecom-china.com/
ELECOM Korea Co., Ltd.
5F Suam Bldg. 1358-17 , Seocho2-dong, Seocho-gu, Seoul 137-862,
Korea
TEL : 1588-9514
FAX : (02)3472-5533
URL : www.elecom.co.kr
ELECOM Singapore Pte. Ltd
33 UBI AVENUE 3 # 03-56. VERTEX SINGAPORE (408868)
TEL : (65)-6347-7747
FAX : (65)-6753-1791
ELECOM India Pvt. Ltd.
408-Deepali Building, 92- Nehru Place, New Delhi-110 019, India
TEL: 011-40574543
e-mail: support@elecom-india.com
URL: http://www.elecom-india.com/
HID profile
®
Folding Bluetooth ® Keyboard
TK-FBM032EBK
User's manual
1st edition, January 10, 2012
ELECOM Co., Ltd
This manual is copyright of ELECOM Co., Ltd.
•
Unauthorised copying and/or reproducing of all or part of this manual is
•
prohibited.
• The specifications and appearance of this product may be changed
without prior notice for product improvement purposes.
• ELECOM Co., Ltd. shall bear no responsibility for any and all affects
resulting from the use of this product regardless of the above reasons.
Export or service transaction permission under the Foreign Exchange
•
and Foreign Trade Control Law is required in order to export this product
or parts of this product that constitute strategic materials or services.
iPad, iPhone, iPod touch, Mac, Mac OS, and Macintosh are trademarks
•
of Apple Inc.
• "PlayStation" and "PS3" are trademarks or registered trademarks of Sony
Computer Entertainment Inc.
• "XMB" is a trademark of Sony Corporation and Sony Computer Entertain-
ment Inc.
The Bluetooth word mark and Bluetooth logo are all trademarks that
•
are owned by the Bluetooth SIG and licensed out for use to ELECOM
Co., Ltd. that are incorporating Bluetooth wireless technology into their
products
Company names, product names, and other names in this manual are
•
generally trademarks or registered trademarks.
©2012 ELECOM Co., Ltd. All Rights Reserved.
