Elecom TK-FBS035E series User Manual

If an abnormality is found with this product (emission of heat,
smoke or abnormal smell from the product), immediately stop
using the product, shut down connected devices, and after
thoroughly checking that heat from the product will not cause
Bluetooth ® Silicone Keyboard burns, remove the batteries from the keyboard. After doing this,
contact the retailer from whom you purchased the product. If you
continue to use the product under these conditions, it may cause
TK-FBS035E series
a fire or electric shock.
Do not drop or hit this product.
If this product is damaged, immediately stop using it, turn it off,
User's Manual
and remove the batteries.
If you continue to use the product in a damaged condition, it may
cause a fire or electric shock.
Do not attempt to disassemble, modify or repair this product by
yourself. Doing so may cause a fire, electric shock, or product
damage and may void the warranty.
Thank you for purchasing the ELECOM Bluetooth Silicone Keyboard.
®
Do not put this product in fire, as the product may burst, resulting
This product employs an English keyboard layout and Bluetooth wireless
®
in a fire or injury.
technology.
This manual describes the operating instructions and safety precautions
for using this product. Ensure that you have read this manual before using
the product. After reading this manual, store it somewhere safe for future
reference. Do not place this product in any of the following environments:
* Except in certain cases, the TK-FBS035E Series is referred to as "this •
product" in this manual.
•
Meaning of symbols •
„
•
Failure to observe precautions may result in
WARNING
serious personal injury or death due to fire,
•
electric shock, or other causes.
This product does not have a waterproof structure. Use and
Failure to observe precautions may result in
store this product in a place where the product body will not be
CAUTION
personal injury due to electric shock or other
splashed with water or other liquid.
causes, and may damage other equipment.
Rain, water mist, juice, coffee, steam or sweat may also cause
product damage.
Prohibited action
• Do not use this product with any device that may have a serious
Mandatory action
impact in the event this product fails.
• When you no longer need to use this product, be sure to dispose of it
Situation that needs attention
in accordance with the local ordinances and laws of your area.
Notes and reference information
„ Batteries
Safety Precautions
Use AAA alkaline batteries, AAA manganese batteries, or
rechargeable AAA nickel hydride batteries with this product.
Observe these precautions carefully to avoid personal injury, damage, fire,
and other problems.
If this product will be unused for a long period of time, remove the
batteries to avoid battery leakage and failure.
WARNING
Cleaning the Keyboard
„
If a foreign object (water, metal chip, etc.) enters the product,
If the product becomes dirty, wipe it with a soft, dry cloth.
immediately stop using the product and remove the batteries
from the keyboard. If you continue to use the product under these
Use of a volatile liquid (paint thinner, benzene, alcohol, etc.) may
conditions, it may cause a fire or electric shock.
affect the material quality and colour of the product.
Part Names
Connection indicator lamp
• Flashes green when the keyboard is in a pairing standby state.
• Indicates when to replace the batteries.
Lights red when the remaining battery level gets low during use.
Connect button Power switch
Battery compartment cover (rear)
key (Function key)
While the key is held down, the func-
tions indicated in the can be used.
Cautions for Wireless Equipment
WARNING
This product is wireless equipment using the entire range of the 2.4 GHz
band and it is possible to avoid the band of mobile object identification
systems. GFSK is used for the radio wave method. The interference
distance is 10 m.
The 2.4 GHz band is also used by medical equipment, and wireless LAN
equipment conforming to the IEEE 802.11b/11g/11n standard.
• Before using this product, check that there are no other "radio stations"*
operating nearby.
• If electromagnetic interference occurs between this product and other
"radio stations", move this product to another location or stop using this
product.
* Other "radio stations" refer to industrial, scientific and medical devices using
the 2.4 GHz band like this product, other radio stations of this type, licensed
radio station premises for mobile object identification system that is used in
factory production lines, certain non-licensed low power radio stations and
amateur radio stations.
• Do not use this product with any device that may have a seri-
ous impact in the event of a malfunction. There are rare cases
CAUTION
where an external radio wave at the same frequency or the
radio wave emitted from a mobile phone causes this product to
malfunction, slow down, or fail to operate.
In a car exposed to sunlight, a place exposed to direct sunlight,
• Do not use this product in a hospital or other locations where the
or a place that becomes hot (around a heater, etc.)
use of radio waves is prohibited. The radio waves of this product
In a moist place or a place where condensation may occur
may affect electronic and medical devices (e.g. pacemaker).
In an uneven place or a place exposed to vibration
• The use of a wireless keyboard in an aircraft is prohibited by
In a place where a magnetic field is generated (near a magnet,
aviation law because doing so may interfere with flight safety.
etc.)
Turn off the keyboard before boarding an aircraft and do not
In a dusty place
use it in the aircraft.
* ELECOM is not liable for any accident or social damages
incurred by the failure of this product.
Package Contents
This product's packaging contains the items listed below. Before using the
product, check that all items are present. We make every effort to ensure that all
products are packaged correctly. However, in the event that an item is missing
or damaged, contact the retailer from whom you purchased the product.
• Keyboard x1
• AAA alkaline battery x2
CAUTION
• Roll-up strap x1
• User's Manual x1
Function key
Enable to adjust the system volume or operate iTunes, etc by pressing the [F1] to [F6] key while pressing down the
Mute
Stops system sound output. Increases the system volume.
Press the key again to cancel mute.
Volume
Plays media such as music.
Decreases the system volume. Pressing this key during playback stops
playback temporarily. *
Basic Instructions
Open the keyboard.
Before using this product for the first time, you
WARNING
must install the batteries. Refer to "Installing/
Replacing the Batteries" for detailed instructions.
Installing/Replacing the Batteries
Before using this product, install two AAA batteries in the keyboard.
Remove the battery
compartment cover.
Insert the batteries.
key.
Volume To previous track
Press this key to skip to the previous track.* ※
To next track
Playback/Pause
Press this key to skip to the next track.*
* When a program such as iTunes is active
- 1 -
Turn on the keyboard. Pair the keyboard.
Power Switch
Connect button
Press the Connect button to pair this product with the
Slide the power switch to the ON position.
connected device.
For detailed instructions on the pairing
The connection indicator lamp lights up
procedure, refer to "Pairing the Keyboard
green for about 3 seconds.
with a Connected Device".
To use this product, the connected device
must support the Bluetooth HID profile or
have a Bluetooth adapter that supports the
HID profile connected.
• Make sure that the polarity is correct.
• Do not mix different types of batteries or use old batteries
with new batteries to avoid battery leakage and failure.
Install the battery
compartment cover.
Home key
Works the same as the Home button on an
iPad, iPhone, or iPod touch.
Software keyboard key
Shows/Hides the software keyboard in the
character input mode for the iPad/iPhone/
iPod touch.
Press [Command] key + Space bar to switch the
character input mode.
Jpn, Eng key
Switches the character input mode for the
iPad/iPhone/iPod touch to
[Eng] English input or
[Jpn] Japanese input.
Space bar
• Inserts a space.
• Converts characters when using two-
byte fonts.
Enter text from the keyboard.
Turning on the Keyboard
Turn on the keyboard to use it.
Slide the power switch to the ON position.
The connection indicator lamp lights up green for
about 3 seconds.
When not using the product, turn the keyboard off to
save battery power.
Slide the power switch to the OFF position.
Using the roll-up strap
When not using this product, you can roll it up and tie it with the roll-up strap
for easy storage.
It is also convenient for carry and transport.
Roll it up with the keyboard side facing up.
Tie it with the roll-up strap.
