  • Page 1 Bixolon SRP-770II Manual More information available at POSMicro.com QUESTIONS? BULk DISCOUNTS SE HaBLa Ask the experts at POSMicro.com. ESpañOL FREE SHIPPING* 1.800.241.6264 Live Chat Now support@POSMicro.com Monday - Friday 6 AM to 5 PM Pacific Time *Free ground shipping to the continental USa on orders over $100.
  • Page 2 User's Manual SRP-770II/770IIE Label Printer Rev. 1.18 http://www.bixolon.com...

  • Page 3: Table Of Contents

    SRP-770II/770IIE ■ Table of Contents ※ Manual Information & Usage Precautions ························································ 3 1. Content Confirmation ····················································································· 7 2. Product Part Names ······················································································· 8 3. Installation & Usage ····················································································· 10 3-1 Power Connection ····················································································· 10 3-2 Interface Cable Connection ········································································· 11 3-3 Paper Installation ······················································································...

  • Page 4: Manual Information & Usage Precautions

    SRP-770II/770IIE ■ Manual Information ※ Manual Information & Usage Precautions This user manual contains basic information for product usage as well as for emergency measures that may be required. ※ The following separate manuals provide more detailed content on various technological issues and areas.

  • Page 5: Safety Precautions

    SRP-770II/770IIE ■ Safety Precautions In using the present appliance, please keep the following safety regulations in order to prevent any hazard or material damage. WARNING Violating following instructions can cause serious injury or death. Do not plug several products in one multi-outlet. You must use only the supplied adapter.
  • Page 6 SRP-770II/770IIE CAUTION Violating following instructions can cause slight wound or damage the appliance. If you observe a strange smoke, odor or noise from Keep the desiccant out of children’s reach. the printer, unplug it before taking following • If not, they may eat it. measures.

  • Page 7: Other Precautions

    SRP-770II/770IIE ■ Other Precautions The copyright for this user manual and various other manuals is property of the BIXOLON Co., Ltd. Any copying or conversion into electronic firm and saving of this material without the express written permission of BIXOLON Co., Ltd. is strictly prohibited. Use of the information contained in this manual is not subject to any patent liability.

  • Page 8: Content Confirmation

    SRP-770II/770IIE 1. Content Confirmation The following items should all be contained in the printer package. Contact the dealer from which the purchase was made if any item is damaged and/or missing. SRP-770II/770IIE Power Cord AC Adapter User’s Manual ※ Optional items RS-232C(Serial) Cable IEEE1284 (Parallel) Cable USB Cable...

  • Page 9: Product Part Names

    SRP-770II/770IIE 2. Product Part Names Feed Button Power Switch Cover Peel-off Cover Lever Printer Head Paper Cover Paper Holder Paper Gap Sensor Paper Guide Peel-off Sensor - 8 - Rev. 1.18...
  • Page 10 SRP-770II/770IIE Fan-Fold RS-232C Receptacle Dip Switch Power Receptacle IEEE1284 Receptacle USB Receptacle Auto Cutter (Option) - 9 - Rev. 1.18...

  • Page 11: Installation & Usage

    SRP-770II/770IIE 3. Installation & Usage 3-1 Power Connection Connect power to the printer as shown below. Power Switch AC Adapter Power Cord 1) Turn off the printer power switch. 2) Check to see that the AC adapter voltage matches that of the power source. 3) Connect the AC adapter jack to the printer power connector.

  • Page 12: Interface Cable Connection

    SRP-770II/770IIE 3-2 Interface Cable Connection Connect the interface cable as shown below. This printer supports the following communications interface standards. - RS-232C (Serial) - IEEE1284 (Parallel) - USB - Ethernet (exclusively for SRP-770IIE) USB Cable RS-232 (Serial) Cable IEEE1284 (Parallel) Cable or LAN (Ethernet ) Cable 1) Turn off the power switch.

  • Page 13: Paper Installation

    SRP-770II/770IIE 3-3 Paper Installation 1) Open the Paper Cover. 2) Spread the paper holder and insert paper as shown. 3) Keep note of paper printing direction. 4) Adjust the paper guide to the width of the paper. 5) Close the Paper Cover. - 12 - Rev.

  • Page 14: Led Display

    SRP-770II/770IIE 3-4 LED Display Feed button Paper feed or cancel the print job. The current printer status can be viewed. (Refer to below) The current printer status can be viewed via the printer’s LED display. 1) Green LED on - The printer waits for the data from Host (PC) in normal mode. 2) Orange LED on - It means paper gap sensing error.

  • Page 15: Test Printing

    SRP-770II/770IIE 3-5 Test printing 3-5-1 Printing using Windows driver 1) Install the Windows driver. Refer to the “Windows driver manual” in the CD for the installation procedure. 2) Set the “port” of Windows driver to the appropriate interface to be used. Refer to the “Ethernet interface user’s manual”...

  • Page 16: Self-Test

    SRP-770II/770IIE 4. Self-Test The self-test checks whether the printer has any problems. (Users cannot perform this procedure if using the printer’s label peel-off option.) If the printer does not function properly, contact an authorized dealer. The self-test checks the following; 1) Make sure that the paper roll has been installed properly.

  • Page 17: Detailed Features

    SRP-770II/770IIE 5. Detailed features 5-1 Printer Settings with Dip switches The dip switches are located on the bottom of the printer. The dip switches are used to set the printer to perform various functions. Follow these steps when changing dip switch settings: 1) Turn the printer power switch off.

  • Page 18: Pause/Restart

    SRP-770II/770IIE [Table 1] Dip Switch 1 Functions Details 4.0 ips Speed Selection 5.0 ips Density Density Selection Normal Mode Exhibition Selection Demo Mode Label Paper Media Selection Thermal Continuous Paper Without Auto Cuter Auto Cutter With Auto Cuter Back Feeding Enable Back Feed Option Back Feeding Disable [Table 2] Dip Switch 2...

  • Page 19: Gap Sensor Auto-Calibration

    SRP-770II/770IIE 5-3 Gap Sensor Auto-Calibration Gap sensor auto-calibration is used when the printer does not detect a gap on the label paper correctly. Generally a printer is set to detect most of gap types but sometimes it fails to detect and keep feeding the paper without a stop when special paper used.

  • Page 20: Gap Sensor Manual-Calibration

    SRP-770II/770IIE 5-4 Gap Sensor Manual-Calibration Manual-calibration of media detection can be used when the printer cannot detect a media gap (or black mark) even after auto-calibration has been executed. Users can calibrate sensor parameters in detail by using the utility program provided by the manufacturer.

  • Page 21: The Peel-Off

    SRP-770II/770IIE 5-5 The Peel-Off This function is used to automatically separate labels from the liner. - The peeler is for Label Paper only. - When the peeler switch is on, labels are not printed if previous printed labels have been removed from the peeler. - When the peeler function is not required, turn the peeler switch off.
  • Page 22 SRP-770II/770IIE 3) Adjust the paper guides and close the cover. ( O ) ( X ) 4) Turn the printer off and back on. - 21 - Rev. 1.18...

  • Page 23: Using Fan-Fold Paper

    SRP-770II/770IIE 5-6 Using Fan-Fold Paper Insert paper through both the rear slot and guides. Adjust holders and guides to the width of the paper. 1) Open the Dust Cover and insert paper. Dust Cover 2) Adjust Paper Holders to the paper width 3) Adjust Paper Guides and close the Paper and fixed Paper Holders with fixing tool.

  • Page 24: Auto Cutter (Option)

    SRP-770II/770IIE 5-7 Auto Cutter (option) Auto cutter should be used for continuous paper only. ( i.e. roll paper) 1. Open the Dip switch cover, and make the switch 1 number 7 “On”. (Refer to printer mode setting at Chapter 5-1.) 2.

  • Page 25: Cleaning Head

    SRP-770II/770IIE 6. Cleaning Head Paper dust on the heating elements may lower the printer quality. When dirty, clean the print head as follows: ※ CAUTION - Make sure to turn the printer power off prior to cleaning. - As the print head gets very hot during printing, if intending to clean the print head, turn the printer power off and wait approximately 10 minute before commencement.

  • Page 26: Appendix

    SRP-770II/770IIE 7. Appendix 7-1 Specifications Item Description Printing Method Direct Thermal Printing Dot Density 203 dpi (8 dot/mm) Printer Printing Width 104 mm Printing Speed 127 mm/sec Roll 42~ 106mm Paper Fan-Fold Type 45 ~ 112 mm SMPS Input Voltage AC 100~240V Frequency 50/60 Hz...

  • Page 27: Certification

    SRP-770II/770IIE 7-2 Certification 1) EMC & Safety Standards • Europe: CE EMC,CB-Scheme:IEC60950-1, GS: EN60950-1: 2001 • North America: FCC rules parts 15B WARNING Use of an unprotected interface cable with this printer conflicts with EMC standards. Users should only use cables approved by BIXOLON. 2) CE Mark •...
