INSTALLATION INSTRUCTIONS
PLEASE READ THIS MANUAL COMPLETELY AND CAREFULLY BEFORE PROCEEDING.
IMPORTANT: Save these instructions for local inspector's use.
IMPORTANT: Observe all governing codes and ordinances.
NOTE TO THE INSTALLER: Please leave this manual with the range for the consumer.
NOTE TO THE CONSUMER: Please retain this manual for future reference.
The installation of this range must conform with local codes or, in the absence of local
codes, with the National Fuel Gas Code ANSI Z223.1 - latest edition. If installed in
Canada, installation must conform with local codes, or with CAN/CGA B149.1, Natural
Gas Installation Code or CAN/CGA B149.2 Propane Gas Installation Code.
This appliance must be electrically grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical Code, ANSI/NFA 70- latest edition.
In Canada, it must be electrically grounded in accordance with local codes or with CSA
C22.1 Canadian Electrical Code Part 1.
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property dam-
age, personal injury or death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone
in the building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
• Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
7355 E. SLAUSON AVENUE, COMMERCE, CALIFORNIA 90040 (323) 889-4888 Fax: (323) 889-4890
P/N 2400030000
JADE GAS RANGE
MODEL RJGR
06/03
IMPORTANT
MADE IN USA
1
Advertisement
Table of Contents
Related Manuals for Jade RJGR
Summary of Contents for Jade RJGR
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS JADE GAS RANGE MODEL RJGR PLEASE READ THIS MANUAL COMPLETELY AND CAREFULLY BEFORE PROCEEDING. IMPORTANT: Save these instructions for local inspector’s use. IMPORTANT: Observe all governing codes and ordinances. NOTE TO THE INSTALLER: Please leave this manual with the range for the consumer. -
Page 2: Table Of Contents
Range Specifications................Legs Installation.................. Casters Installation................Curb Base Installation................. Stub Back Installation................. Clearances Against Combustible Surfaces......... Gas Connection.................. Gas Conversion For RJGR Series ..........9-10 Electrical Connection................Initial Start-up and Burner Adjustment Open top / Simmer ..............Infrared Broiler............... Oven.................. -
Page 3: Range Specifications
RANGE SPECIFICATIONS MODEL: RJGR - 30 MODEL: RJGR - 36 MODEL: RJGR - 48 MODEL: RJGR - 60 MODEL TOTAL NET WEIGHT ELECTRICAL BTU/HR LBS(APPROX) REQUIREMENT RJGR3070A 99,500 RJGR3670A 142,000 RJGR3671A 128,000 RJGR3673A 119,000 RJGR3674A 132,000 120 VAC RJGR4873A 173,000... -
Page 4: Casters Installation
CASTERS INSTALLATION: Casters are used for easy access in servicing or clean- IMPORTANT: The top of the range must be even or ing the appliance. However, unlike the legs, casters higher than the counter top. The heat from the top burn- are not adjustable. -
Page 5: Curb Base Installation
CURB BASE INSTALLATION The curb base must be installed after the range has been leveled and set properly in its final location. To install the curb base, simply remove the kick plate (the panel immediately below the oven door) and lo- cate the mounting holes at the front of the range base. - Page 6 ISLAND BACK/STUB BACK/HIGH SHELF INSTALLATION: TO INSTALL ISLAND BACK: 1 INSTALL FRONT. 2 SECURE THE SIDE FLANGES OF THE FRONT USING BOLT, AND NUT ON EACH END. 3 SECURE THE BOTTOM LIP OF THE FRONT AGAINST THE BACK OF THE RANGE USING 2 SCREWS (4 SCREWS ON DOUBLE OVENS).
-
Page 7: Clearances Against Combustible Surfaces
Because of the high heat output of the Jade RJGR Gas Ranges, a suitable exhaust hood must be installed above the range. Because the design... -
Page 8: Gas Connection
GAS CONNECTION: IMPORTANT Installation of this range must conform with local codes. Call the local gas supplier for the applicable codes in Shut off gas supply before removing an existing range the area. If there are no codes, the installation must and leave it off until new installation is completed. -
Page 9: Gas Conversion For Rjgr Series
GAS CONVERSION FOR RJGR SERIES All Jade cooking appliances are designed and engineered to operate efficiently and safely with either natural or propane gas. However, each gas requires its own specific regulator and gas orifice setting. The name plate on your unit identifies its original gas setting. This conversion must be done by an approved service agent. - Page 10 GAS CONVERSION FOR RJGR SERIES TO FRONT OF OVEN SHUT OFF VALVE RANGE LIFT UP AS SHOWN FOR OPEN POSITION REGULATOR CAP CLOSED END EXPOSED IS SET FOR NATURAL GAS GAS INLET REGULATOR CAP OPEN END EXPOSED IS SET FOR LP-PROPANE...
-
Page 11: Electrical Connection
ELECTRICAL CONNECTION RJGR models require a 120 volt, 60 hertz, 15 AMP, This appliance is equipped with a three prong (ground- AC properly grounded household circuit. The circuit ing) plug for your protection against shock hazard and must be protected with a circuit breaker or time delay should be plugged directly into a properly grounded fuse. -
Page 12: Open Top / Simmer
3. Put a carpenter’s spirit level or a measuring cup partially filled with water on one of the oven racks. Every RJGR Range is fully tested and adjusted in 4. Adjust the leg’s feet using the wrench. the factory. Due to the difference in gas heating... -
Page 13: Infrared Broiler
If the flames are yellow, soft, lazy with indistinct cones, Turn the burner knob to LOW (simmer) setting. At it signifies insufficient air. For natural gas it is normal this setting, the burner ports must be fully lit with the that the burners have blue flames with little orange smallest possible flames without flickering. -
Page 14: Charbroiler
WOK BURNERS Ignition and adjustment procedures for the wok burners are the same as the open top burners. CHARBROILER Similar to the open top burners, the charbroiler uses spark ignition. To light ½” burner, push knob in, turn knob to HI and then turn to LITE.
