Block Diagram
Basic Specification
Display
Media format
I/O
Speaker
Power
TFT LCD
Number of Pixel
Back‐light
Video
Audio
SD card slot
USB
Micro USB
Mini HDMI
Module slot
High quality speaker
AC/DC adapter
10.1" (16:9 diagonal) inch configuration
1024 RGB (H) x 600(V)
LED Side‐light type
MKV, TS, FLV, AVI, VOB, MPG, DAT, ASF,
RM, MOV, 3GP, MP4, WMV
MP2, WMA, WAV, AAC, OGG, ASF
JPG, BMP, GIF
SD card (SDHC Class10 compatible)
USB 2.0 host type A×1
Micro USB 2.0 × 1
Mini HDMI out, Type C ×1
USB 2.0 x 1
3W×2
12V/1.5A AC/DC adapter
