VisionTek 84VT User Manual

OTA Service No.: The VTU can be configured remotely through SMS. Enter the
number (GSM) from which the unit should accept the Over
the air Configuration.
GPS Frequency: Enter the time duration for which the unit should read the
GPS parameters. The time can be from 001 seconds to 255
seconds.
GSM Frequency: Enter the time duration for which the unit should send the
received data to the central server. The time duration entered
here will be applicable for both "SMS" and "GPRS" .
Select the country GMT time difference. In case of India it is
GMT Time Offset:
+0530.

4.4 SMS MESSAGE:

Enter the pre-defined message content to be sent when the switch is pressed.

4.5 INCOMING NUMBERS:

Enter the incoming numbers which are to be allowed. Any number received by the unit
other than the entered numbers will not be allowed.
A maximum of 10 numbers can be entered.

4.6 Send:

Select the option to store all the configured parameters in to the unit.
4.7 Clear Date:
Select the option to clear all the parameters displayed on the screen.
4.8 Configuration History:
When "Send" option is selected, all the parameters configured will be stored into the
unit and the same are stored in the configuration history.
Customer can recall the configuration history as and when required for review. The
application will store approximately 1000 configurations.

4.9 Edit:

Select any configuration details from the history and select "Edit" to edit the details. The
edited details can be stored in to the unit.
4.10 Export:
Select the function to Export the configuration history details.
4.11 Find:
Select the function to find the configuration details of a particular vehicle from the
history.
4.12 Delete All:
Select to delete the configuration history details.
4.13 Close:
Select to close the application.
NOTE: After completion of the configuration, switch OFF & ON the VTU.

Unit Installation

3
1. Initial Setup for Installation:Select the location where the unit to be fixed /
installed. Connect the GSM antenna to the GSM connector provided on the unit. Connect
the GPS antenna to the GPS connector provided on the unit. GSM & GPS marking is
provided near to the connectors for easy identification.
For good GPS coverage, make sure that the GPS antenna has a clear view at the sky
preferably outdoors. Ensure that the top of the antenna is aimed at the open sky.
2. Power Connection: Connect the unit to battery for powering ON. Ensure that the
battery / battery voltage is between 9V to 28V.
When the units is powered ON, all the three LED's (Red, Yellow and Green) related to
power, GSM and GPS will glow continuously and after some time, the unit will give
"Beep" sound indicating that the unit is ready.

3. LED Indications

LED Status Flashing
Red Unit Power ON
Searching for GPS GPS Fix available
Yellow
GPS Not available.
Green Searching for the GSM GSM Network available.
network GSM Network not
available. Sending the data
to the central server.
NOTE: When the unit is in programming mode, Yellow and Green LED's will not
glow and only Red LED will glow with low intensity.
WARRANTY
VISIONTEK Vehicle Tracking Unit 84VT is warranted for a period of 12 months from the date of sale against
manufacturing defects. Linkwell Telesystems Pvt. Limited, obligation under this warranty shall be limited to
servicing or replacing the defective parts provided that notice of such defects and satisfactory proof
thereof is given to Linkwell Telesystems Pvt. Limited.
The warranty does not cover any defect in the product caused by accident, misuse, mishandling,
negligence, alteration, modification or substitution of any of the components or parts or any attempt at
internal adjustments, any form of tampering by unauthorized/unskilled service personnel, loss of
components or accessories, natural calamities and over voltage of electricity.
5
Under no circumstance shall Linkwell Telesystems Pvt. Limited, be liable for any consequential or resulting
injury or for loss, damage or expenses directly or indirectly arising from the use of this product Linkwell
Telesystems Pvt. Limited will make every effort to carry out repairs/replacement under this warranty as
early as possible and it is expressly made clear that the company shall not be liable to do so within any
specified time or period.
The decision of Linkwell Telesystems Pvt. Limited as to the nature of the defect and applicability of this
warranty shall be final.
Claims if any, to this warranty shall be only made before the courts having jurisdiction in Secunderabad,
Andhra Pradesh.
Product Pictures
Connectors LED Indicators
Linkwell Telesystems Pvt. Ltd.
Gowra Klassic, 1-11-252/1/A, Begumpet, Hyderabad - 500 016. Andhra Pradesh, INDIA.
Ph. : +91-40-66388000 | Fax : +91-40-66388006, 27763838
BRANCHES: NOIDA - 0120-2549090, 2549095, 2541427, 2541437 | KOLKATTA - 033-22176549, 22169301 |
AHMEDABAD - 079-40062001, 40062002 | MUMBAI - 022-24916940, 24916942 | VIZAG - 0891-2550725,
2564752,2508088 | BANGALORE - 080-25598811, 25550729, 25591457 | CHENNAI - 044-24797950, 24797960
| KERALA - 94471-37717
6
www.visiontek.co.in
User's Manual
VEHICLE TRACKING UNIT 84VT
Congratulations !!!
We thank you for purchasing VISIONTEK VEHICLE TRACKING UNIT 84VT
equipped with state of the art GPS receiver that provides reliable and accurate navigation data. This
User's manual will help you in knowing all the features of the system including installation. Operational
and programming procedure in a step by step manner. Please keep this handy manual for easy
reference.
For Servicing and other details kindly look at the corporate address and email id at the backside of
the manual.

Introduction

1
2

SIM Installation

3

Configuration

Unit Installation
4
7
GPRS
GPS
SMS
Triband GSM
