www.visiontek.co.in
User's Manual
VEHICLE TRACKING UNIT 86VT
Congratulations !!!
equipped with state of the art GPS receiver that provides reliable and accurate navigation data. This
User's manual will help you in knowing all the features of the system including installation. Operational
and programming procedure in a step by step manner. Please keep this handy manual for easy
reference.
For Servicing and other details kindly look at the corporate address and email id at the backside of
the manual.
Introduction
1
SIM Installation
2
Configuration
3
Unit Installation
4
We thank you for purchasing VISIONTEK VEHICLE TRACKING UNIT 86VT
GPRS
GPS
Triband GSM
Advertisement
Table of Contents
Related Manuals for VisionTek 86VT
Summary of Contents for VisionTek 86VT
- Page 1 VEHICLE TRACKING UNIT 86VT Congratulations !!! We thank you for purchasing VISIONTEK VEHICLE TRACKING UNIT 86VT equipped with state of the art GPS receiver that provides reliable and accurate navigation data. This User's manual will help you in knowing all the features of the system including installation. Operational and programming procedure in a step by step manner.
- Page 2 The communication is either through Short Message Service (SMS) or GPRS network. The Visiontek 86VT is provided with a RS-232 port for configuration of the unit. The unit can be also remotely configured (OTA Configuration). In addition the unit is provided with two switches (One for Voice &...
- Page 3 Open the SIM tray, Insert the SIM card and close the tray Internal battery installation GSM and GPS antenna...
- Page 4 Configuration It is recommend to involve a computer technician for proper configuration of Visiontek 86VT and an automobile electrician in order to install the system properly. Follow the following steps for configuration of Visiontek 86VT. INITIAL SET UP FOR CONFIGURATION: 1.
- Page 5 3. Select comport to be used for the configuration from the drop down menu and press “connect” . 4. Following options are provided in configuration application. 1. Priority. 2. Connection Information. 3. Service Information. 4. SMS Message. 5. Incoming Numbers. 6.
- Page 6 4.3 SERVICE INFORMATION: Vehicle ID: Enter the Vehicle ID to which the unit is connected. Enter the server number (Mobile Number) to which the data Server Number: to be sent when “SMS” communication mode is selected. Enter the number to which voice communication is required. Voice Number: This number will be activated when the switch on the unit...
-
Page 7: Delete All
4.9 Edit: Select any configuration details from the history and select “Edit” to edit the details. The edited details can be stored in to the unit. 4.10 Export: Select the function to Export the configuration history details. 4.11 Find: Select the function to find the configuration details of a particular vehicle from the history. -
Page 8: Product Pictures
WARRANTY VISIONTEK 86VT, Vehicle Tracking Unit is warranted for a period of 12 months from the date of sale against manufacturing defects. GSM, GPS antennas and Battery are warranted for six months against manufacturing defects. Linkwell Telesystems Pvt. Ltd., obligation under this warranty shall be limited to servicing or replacing the defective parts provided that notice of such defects and satisfactory proof thereof is given to Linkwell Telesystems Pvt.
