- Page 1 Cambodian Advance Technology., Co.Ltd. Address: house No.D01, St.101, Sk. Boeng Trabek, Khan Chomkamon. Phnom Pehn, Cambodia. Office phone: +85513 502 222 +85515 205 003 Email: mcadvancetech@cadgps.com Power by: SuperGuard...
- Page 2 SuperGuard GPS Vehicle Tracking System Operation Manual ---------- ---------- Compact GPS/GPRS Fleet Management Device SG-VT05...
- Page 3 Warranty The Yield Technology Co., Ltd. (YTC) warrants to the purchaser that this product, under normal use and conditions, will be free from defects in materials and workmanship for a period of 12 months from the date of original purchase. If a product proves defective during this warranty period, YTC, at its option, either will repair the defective product without charge for parts and labor, or will provide an exchange for the defective product.
-
Page 4: Table Of Contents
Table of Contents Parts & Accessories page 4 SuperGuard Vehicle Unit - Features page 6 Preparations page 7 Installation page 8 Vehicle Unit – LED Indicators page 13 Getting Started page 14 Emergency Alarms page 15 Monitoring Activities page 16... -
Page 5: Parts & Accessories
1. Parts & Accessories On receipt of your SuperGuard system, please check that all contents are complete and correct. - Page 6 1. SuperGuard GPS/GPRS Main Unit 2. 14-PIN Wiring Harness 3. SOS Emergency Button 4. 3.7V Rechargeable Li-Ion Battery pack 5. Engine Immobilizer Relay...
-
Page 7: Superguard Vehicle Unit - Features
2. SuperGuard Vehicle Unit – Features The SuperGuard SG-VT05 is a GPS vehicle tracking device, ideal for fleet management and commercial data centers. The SG-VT-05 is easy and quick to install, saving costly installation time and fees. Data exchange between device and server is maintained over GPRS and Internet connection. -
Page 8: Preparations
3. Preparations In order to install the SuperGuard Vehicle Unit properly, the following preparations should be carried out: Prepare one operational GSM SIM card. Make sure that the SIM card can operate without PIN protection and has GPRS with unrestricted Internet access enabled (ask your GSM operator for APN and GPRS dial up requirements). -
Page 9: Installation
4. Installation NOTE: Please note that installation methods may vary between vehicle models. For expert wiring and connecting please contact a professional car electronics workshop for installation support and maintenance. The Vehicle Unit will only operate on 12 V systems with negative earth (Negative to body). - Page 10 Connecting The Vehicle Unit: NOTE: Finish all wiring and connections to the correct vehicle outputs and inputs before you apply the connector to the Vehicle Unit ! To obtain maximum functionality of your Vehicle Unit you should locate and connect the following electrical output and input wires from the vehicle to the complying pigtails of the device connector: •...
- Page 11 Wire Harness Description and Colors Cable Description Color +12V Battery Power Input (+) Power Ground (GND) Black Connect to SOS Emergency Button (+) Blue Power Ground (GND) Brown Free (not connected) Brown/White Connect to alarm out Purple Ignition ACC (+12V) Yellow Free (not connected) White...
- Page 12 Installation of Relay for Immobilizer function: To apply the Engine Enable/ Disable Relay, connect the following cables from the relay socket: PIN1 = 30: Connect to one end of Ignition line (A) PIN2: = 86: Connect to Vehicle Unit, PIN9 (Purple/White) PIN3: =87a: Connect to engine end of ignition line (B) PIN4: free...
-
Page 14: Vehicle Unit - Led Indicators
5. Vehicle Unit – LED Indicators GSM Status LED (green) If LED flashes (once per second): Device is scanning SIM, registering to GSM network or connecting to carrier. If LED stays on continuously: Device is connected to GPRS network. Device is able to receive commands over GPRS and SMS and send data to server. -
Page 15: Getting Started
6. Getting Started After applying the wire harness to the Vehicle Unit, the device will power up and automatically attempt to register to GSM network. Provided that your vehicle and the device is positioned in a location with clear un-obstructed view of the sky, the device will then start scanning for GPS satellites to obtain its first GPS lock. -
Page 16: Emergency Alarms
7. SOS Emergency Button The SuperGuard system includes one SOS button that can save your life in case of accidents, hijacking or emergency cases. SOS Emergency Call The SOS button can be installed at a hidden place within reach of the driver. -
Page 17: Monitoring Activities
8. Monitoring Activities Users are able to setup and configure monitoring activities and alerts to the Vehicle Unit, using Control Base software or Tracking Web services via Internet Explorer or mobile on GPRS enabled cell phones. Geo-Fence Alarms The Vehicle Unit can been configured with a set of up to four restricted geographic areas (Geo-Fences), the following activities will be triggered when a Geo-Fence violation occurs: The Vehicle Unit will send an alarm message and GPS... - Page 18 Vehicle Battery Cut Off If the Vehicle Unit has been removed or cut from the main power source, the following report feature will come into effect: The Vehicle Unit will send an alarm message with GPS position to the Control Base. The Control Base software will find the street name and closest intersection from a map server and send these details through SMS short messages to a list of up to...
-
Page 19: Locating And Tracking
9. Locating and Tracking Authorized users can interrogate the Vehicle Unit to receive locations, street names and details. In addition, they can poll and track their vehicles through Control Base software or Tracking Web services via Internet Explorer or mobile on GPRS enabled cell phones. -
Page 20: Technical Specifications
10. Technical Specifications SIZE (L/W/H): 88 (119) x 58 x 30 mm POWER SUPPLY: DC 9V ~ DC 16V POWER CONSUMPTION: - 45mA ~ 60mA Standby current - 22mA ~ 30mA Idle mode current - 3 mA ~ 5 mA Sleeping mode current - 40mA ~ 100mA operating (SMS) - 60mA ~ 110mA operating (GPRS online) SPARE BATTERY: 3.7V 700 mAh... - Page 21 Max : 30dBm ± 5dB ; Min : 0dBm ± 5dB o RX Sensitivity: GSM-850: < -106 dBm E-GSM-900: < -106 dBm DCS-1800: < -104 dBm PCS-1900 : < -104 dBm GSM Application Programming Interface AT Commands UI APIs GPS MODULE o Chipset Solution: ATMEL SUPERSENSE ANTARIS4 o Center Frequency: 1575.42 MHz L1 band;...
