Instruction Manual
Rosendahl nanosyncs HD
Rosendahl nanosyncs HD is a professional video and audio
sync reference generator.
www.rosendahl-studiotechnik.com
- 0 -
Contents
11. Updating the Firmware
- 1 -
page
2
page
3
page
4
page
6
page ..8
page 10
page 12
page 15
page 16
page 19
page 20
page 21
page 23
page 24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the nanosyncs HD and is the answer not in the manual?

Questions and answers

Summary of Contents for Rosendahl nanosyncs HD

  • Page 1: Table Of Contents

    Instruction Manual Rosendahl nanosyncs HD 1. Unpacking and Mounting into a 19" Rack page 2. Installation page Rosendahl nanosyncs HD is a professional video and audio 3. Front Panel page sync reference generator. 4. Rear Panel page 5. Video Reference page ..8...
  • Page 2: Unpacking And Mounting Into A 19"Rack

    HD ultra low jitter clocks. 115VAC and 230VAC The optimum solution is to mount the nanosyncs HD in the same 19“ rack as the most important AD/ DA digital audio converters in your Please check the mains voltage marking on the original package studio.
  • Page 3: Front Panel

    3. Front Panel L9 L10 L11 L12 L13 (S1) Power Switch: (L9) (L10) Sample Rate: Switches the unit from standby power down mode to normal The base sample rate of the audio clock generator can be set to 44.1 operation mode and vice versa. or 48kHz.
  • Page 4: Rear Panel

    (C9) LTC Time Code Input (RCA): outputs are transformer balanced and drive 3,5 Vpp into standard LTC time code (also called SMPTE) is read by the nanosyncs HD 110 ohm inputs. and translated into MTC via the USB midi port. The audio clock generator can also be resolved to the LTC applied on this input.
  • Page 5: Video Reference Page

    A 30 fps "black & white" input signal is indicated by the 30 fps LED without -0.1% LED. The nanosyncs HD will also lock to 30 fps signals. Enter the setup mode and select the video reference section. EXT.TRI LEVEL: INTERNAL: The internal 0.5 ppm accurate crystal oscillator is the...
  • Page 6: Sd/Hd Video Generator Settings

    6. SD / HD Video Generator Settings 1080 P x1: 1080 lines , progressive The nanosyncs HD generates one SD video sync standard and one 23.98, 24, 25, 29.97, 30 fps rates HD tri level standard simultaneously. You can set the frame rates and formats independent for the SD and...
  • Page 7: Audio Reference

    = LTC and the denomination left of the slash If you want to use the nanosyncs HD as a studio master set the video relates to the FPS value for LTC operation and the value right of the reference to INTERNAL and the audio reference to FOLLOW VIDEO.
  • Page 8: Sample Rate And Multipliers

    The base sample rate of the audio clock generator can be set to 44.1 or 48kHz. The nanosyncs HD is also able to resolve audio word clock signals to external, free running LTC time code signals. The next section (L10) allows you to enter a so called pull factor.
  • Page 9: Usb Midi Port, Mtc And Mmc

    9. USB midi port, MMC and MTC To synchronise a DAW to MTC time code open the nanosyncs HD The nanosyncs HD has a USB (Universal Serial Bus) port for midi port in your DAW application software and make the according bidirectional communications with a host computer.
  • Page 10: Configuration Protection

    A free nanosyncs HD utility software (coming soon) will also allow to configuration. set and start the LTC generator via MMC for using the nanosyncs HD In the protected mode all keys are disabled. as a time of day LTC master generator.
  • Page 11: Nanosetup Software

    A premature termination of the software update process leads to the The firmware version installed in your nanosyncs HD is displayed complete loss of the firmware but does not erase the nanosyncs HD every time the unit is switched on.
  • Page 12: Declaration Of Conformity

    "NTSC" LED in column L3 indicates activated NTSC pedestals. Andechser Str. 5 D-86919 Utting a.A. Germany "VO6=HD" LED in column L6 indicates "Black Rosendahl on VO6" herewith confirms that the product: Type: professional video and audio sync reference generator "x256" LED in column L12 indicates "Pilottone on WO8".
  • Page 13: Specifications

    14 . Specifications USB: USB 2.0, class compliant midi device, plug and play under windows XP or Mac OSX MTC, MMC and Rosendahl SYSEX for firmware updates video input: BNC, 75 ohms terminated, accepts SD bi-level syncs and HD tri-level syncs...
