Thank you for purchasing HME's "ServerCall" Server Paging System. Your system has
been pre-programmed at the factory and will function once mounted and plugged in.
Transmitter Set Up & Mounting Instructions:
1) Mount the transmitter unit onto the cook line using the included brackets, or remove the rear
brackets and mount it directly to the wall if desired. The unit will mount using the 4 keyhole
cutouts in the back panel. To mount to the wall, drill holes for the wall inserts included using
the included template. To stand unit up remove the small bracket, flip over the large bracket
and tighten at desired location.
2) Plug the 2-amp wall transformer into any suitable AC outlet. Plug the power connector into
the power jack on the bottom right hand side of the unit. (Surge protector recommended!)
3) Mount the transmitter in a convenient location away from heat lamps, steam tables and
water.

EQUIPMENT SET UP

Jumper wire
TRANSMITTER SET UP & MOUNTING INSTRUCTION
WALL MOUNT
Wall
HME 800.919.9903
©HME WIRELESS, INC. 2012

PAGING SYSTEM SETUP

OFFICE
Always store pagers in
a clean, dry location
Charger Power Supply
(Use 1 power supply per 5
charger bases)
Transmitter
ServerCall ® Paging System
Server Call 25
Transmitter
Transmitter Power Supply
12 Volts DC . / 1.6 Amp.
KITCHEN TOP MOUNT
Screws
KITCHEN
OPTIONAL
Cancel Panel
Ethernet Cable
Metal Brackets
