- Page 1 User's Manual USB DOCK - Einstein Omnidirectional Control Technology Inc.
-
Page 2: Table Of Contents
Omnidirectional Control Technology Index INTRODUCTION..............................3 .............................3 YSTEM EQUIREMENTS ............................3 ACKAGE ONTENTS ................................4 ONNECTORS USB DOCK F ............................4 UNCTIONS LED I ..............................5 NDICATOR INSTALLING USB DOCK..........................6 ............................7 RIVER NSTALLATION ...........................18 P THE RINTER EVICE ................21 ET UP THE YPER ERMINAL WITH TO SERIAL PORT ......................23 NINSTALLING THE... -
Page 3: Introduction
Omnidirectional Control Technology I n t r o d u c t i o n Thank you for ordering the USB DOCK. The USB DOCK is an intelligent expansion module which connects to a PC or notebook via Universal Serial Bus (USB) port, providing one high-speed RS-232 serial port, one printer port, one PS/2 keyboard &... -
Page 4: Connectors
Omnidirectional Control Technology Connectors l One DB-9 RS-232 serial interface connector supports baud rates from 1,200 to 115.2K. l One DB-25 parallel connector supports IEEE-1284 bi-directional printer port. l One Mini-din for PS/2 keyboard, mouse. l Four USB receptacle type A downstream ports. l One USB type B upstream connector. -
Page 5: Led Indicator
Omnidirectional Control Technology LED Indicator l Power Indicator The Power Indicator will turn ON when bus power is supplied. l USB Indicators There are four USB indicators to show if the USB Downstream Ports are ready for use. 1. If the USB DOCK is not ready for use or only bus power is supplied, the USB Indicators will turn OFF, and the USB Downstream Ports can not be used. -
Page 6: Installing Usb Dock
Omnidirectional Control Technology I n s t a l l i n g U S B D O C K 1. This installation guide is written in accordance with Windows 98/98SE. For Windows 2000/XP, the step A, B, and C of the "Driver Installation" section will be skipped. -
Page 7: Driver Installation
Omnidirectional Control Technology Driver Installation The driver installation is divided into 4 steps. Please install USB DOCK step by step by following the instruction from Step A-D. Step A: (This step for Windows 98 only) To install the HUB function of the USB DOCK: A1. - Page 8 Omnidirectional Control Technology A4. Click “Next” to continue (Ref Figure A-4) Figure A-4 A5. Click “Next” to continue (Ref Figure A-5) Figure A-5 A6. Click “Finish”, Windows has finished installing USB Hub driver (Ref Figure A-6) Figure A-6 USB-DOCK User’s Manual - 8 -...
-
Page 9: Figure
Omnidirectional Control Technology Step B: (This section for Windows98/98SE/Me only) To install the software for USB to Printer Converter of the USB DOCK: B1. Insert the “USB DOCK driver diskette” into drive A. Click “Next” to continue (Ref Figure B-1) Figure B-1 B2. -
Page 10: Figure
Omnidirectional Control Technology B4. Click “Next” to continue (Ref Figure B-4) Figure B-4 B5. Click “Finish”, windows has finished installing the printer driver (Ref Figure B-5) Figure B-5 Before connecting the printer on the parallel port of USB DOCK-Einstein, the printer driver must be installed in advance, or it might print unknow format of character. -
Page 11: Figure
Omnidirectional Control Technology Step C. (This section for Windows98/98SE only) To install the PS/2 keyboard & mouse driver of USB DOCK: C1. Click “Next” to continue (Ref Figure C-1) Figure C-1 C2. Click “Next” to initiate search for the best driver for your device (Ref Figure C-2) Figure C-2 C3. - Page 12 Omnidirectional Control Technology C4. Click “Next” to continue (Ref Figure C-4) Figure C-4 C5. Click “Finish”, Windows has finished installing the USB HID driver for PS/2 keyboard & mouse. (Ref Figure C-5) Figure C-5 USB-DOCK User’s Manual - 12 -...
- Page 13 Omnidirectional Control Technology Step D: To install the USB to serial port driver of the USB DOCK, please make sure the driver diskette is inserted: D1. Click “Next” to continue (Ref Figure D-1) Figure D-1 D2. Click “Next” to initiate a search for the best drive for your device (Ref Figure D-2)
- Page 14 Omnidirectional Control Technology D4. Click “Next” to continue (Ref Figure D-4) Figure D-4 D5. Click “Finish”, Windows has finished installing RS-232 port driver (Ref Figure D-5) Figure D-5 USB-DOCK User’s Manual - 14 -...
- Page 15 Omnidirectional Control Technology Step E. (For Windows 2000/XP only) To install the USB to serial port driver of the DOCK COMMANDER, please make sure the driver diskette/CD is inserted: E1. Click “Next” to continue (Ref Figure E-1) Figure E-1 E2. Click “Next” to initiate search for the best driver for your device (Ref Figure E-2)
- Page 16 Omnidirectional Control Technology E4. Click “Next” to continue (Ref Figure E-4) Figure E-4 E5. Click “Finish”, Windows has finished installing Serial port driver. (Ref Figure E-5) Figure E-5 l Before connecting the modem on the serial port of USB DOCK, the modem driver must be installed in advance, otherwise it might operate unexpectedly.
- Page 17 Omnidirectional Control Technology Congratulations!! You have finished installing USB DOCK. Please click on Start, Settings, Control Panel, double click System, and click on Device Manager. Double check the Human Interface Devices, Keyboard, Mouse, Ports, and Universal serial bus controller of the dialog box to see if they work properly.
-
Page 18: Set Up The Printer Device
Omnidirectional Control Technology Set Up the Printer Device Follow the steps below to connect your printer to the USB DOCK with your PC: For Windows 98/98SE and Me: 1. Turn off your printer. Plug the cable to connect USB DOCK parallel port and printer. - Page 19 Omnidirectional Control Technology Figure 6 6. If you do not have a printer installed yet, click on Start, Settings, Printers, Add Printer. The Add Printer Wizard will start and assist you in installing a new printer device. Select the printer manufacturer and model name from the list provided by the wizard or use the printer driver diskette supplied by your printer.
- Page 20 Omnidirectional Control Technology For WINDOWS 2000 and XP: 1. Turn off your printer. Plug the cable to connect USB PORT REPLICATOR parallel port and printer. Turn on the printer afterwards. 2. Turn on your computer and plug in the USB cable to connect the USB PORT REPLICATOR and the USB port of PC.
-
Page 21: Set Up The Hyperterminal With Usb To Serial Port
Omnidirectional Control Technology Set up the HyperTerminal with USB to serial port Follow the steps below to configure your HyperTerminal with USB to serial COM port setting: 1. Make sure that HyperTerminal is installed in your system. If not, please click Start, Settings, Control Panel, double click Add/Remove Programs, choose Windows Setup page, Communications, click Details button, enable HyperTerminal to install the program to your Windows system. - Page 22 Omnidirectional Control Technology Figure 9 4. Click the "Connect using" item to indicate the proper COM port which appeared in step 1, and follow the succeeding instructions to complete the setup. USB-DOCK User’s Manual - 22 -...
-
Page 23: Uninstalling The Driver Program
Omnidirectional Control Technology Uninstalling the Driver Program If you want to remove the USB DOCK driver program, you can uninstall it by following the steps below: WINDOWS 98/98SE and Me: a. Unplug the USB cable from your PC. b. Run the Uninst_USBDock_98_Me.exe program from the USB DOCK driver diskette and reboot the PC. -
Page 24: Application Note
Omnidirectional Control Technology A P P L I C A T I O N N O T E 1. Determine why support of USB port is not present: First, download Usbready.exe from the web site www.octinc.com.tw, if you have any problem to download, please contact us via service@octinc.com.tw. Please run the program, and click the Details button, it will help you find the reason why USB support is disabled. -
Page 25: Technical Support
Omnidirectional Control Technology D i s c l a i m e r Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any other commercial damage, including but not limited to special, incidental, consequential, or other damages.
