Key Digital KD-ZRC300 Programming Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Video
Audio
Automation
Key Digital
, led by digital video pioneer Mike Tsinberg, develops
®
and manufactures high quality, cutting-edge technology solutions
for virtually all applications where high quality video imaging and
control are important. Key Digital
industry for Home Theater Retailers, Custom Installers, System
Integrators, Broadcasters, Consultants, Builders, Designers,
Architects and Consumers.
521 East 3rd Street, Mount Vernon, NY 10553
Phone :: 914.667.9700
Fax :: 914.668.8666
Web :: www.keydigital.com
KD-ZRC300_Manual.indd 2-3
Climate
Lights
Shades
Web
®
is at the forefront of the video
Rev 0 – Aug 2014
KD-ZRC300
Programming Guide
Security
The Experts in Digital Video Technology and Solutions
Discover The Possibilities
ON
OFF
CBX
TV
ATV
AVR
SEC
BRP
L/S/H
SELECT
DVR
EXIT
GUIDE
+
+
MUTE
VOL
CH
–
–
PREV CH
ZOOM
AV
PC
LIGHT
SHADES
HVAC
AM/FM
INT RADIO
SURR
1
2
3
4
5
6
7
8
9
–
0
A
B
C
HEAT
AUTO
COOL
D
MENU
www.keydigital.com/compass
™
®
8/20/14 2:43 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KD-ZRC300 and is the answer not in the manual?

Questions and answers

Related Manuals for Key Digital KD-ZRC300

Summary of Contents for Key Digital KD-ZRC300

  • Page 1 , led by digital video pioneer Mike Tsinberg, develops ® and manufactures high quality, cutting-edge technology solutions for virtually all applications where high quality video imaging and – control are important. Key Digital ® is at the forefront of the video HEAT AUTO...

  • Page 2: Table Of Contents

    For more information regarding KD-ZRC300’s key features, visit: › http://keydigital .com/items .asp?itemCode=KDZRC300&Company=Key © 2014 Key Digital, Inc . All rights reserved . ZigBee is a registered trademark of ZigBee Alliance . KD-ZRC300_Manual.indd 4-1 8/20/14 2:43 PM...

  • Page 3: Connectivity

    3. As the KD-ZRX200 lights flash, hold down the buttons on the ZigBee RF KD-ZRC300 remote until the blue lights stop flashing . RJ45 L/S/H WiFi Router 4. The KD-ZRC300 and KD-ZRX200 connected to KD-MC1000 are now paired . (Only Necessary SELECT for iOS Control) Satellite EXIT GUIDE...

  • Page 4: Kd-Zrc300 Remote Overviiew And Connections

    KD-ZRC300 Remote Overview and Connections Default Button Assignment Apple TV (Switch) ON/OFF Indication Keys Sets Apple TV as source for display Turns on / off selected device Low Battery indicator: Power OFF LED and remote will control Apple TV blinks every second while in active mode.

  • Page 5: Setup Master Controller Ip Address

    Setup Master Controller IP address Fill in the desired IP information for the KD-MC1000 (AKA host) and Router IP address Use provided USB Cable to connect the PC to the KD-MC1000 . and click Apply Must use a PC or Mac with PC software . Open Master Controller Device Manager Software Click Setup In Connection Port make sure USB is selected and click on Next...

  • Page 6: Programming

    » 2. Enter your Compass Control ® login information b . Select the KD-ZRC300 remote by going into the dropdown menu and selecting » (If you don’t have a username, please type in the default one: Zigbee@keydigital.com, » “ZigBee Remote”...
  • Page 7 . there is a serial number on the bottom of a serial bar . The Device ID Local Module: A pre-installed library made by Key Digital with variety of device codes for »...
  • Page 8 6. In the “Connection” section, be sure to click “MC” . 7. To make changes to the connection types in the KD-ZRC300 remote, go to the Device Modes section in the “Properties” window, and determine if the device is to be controlled via line-of-sight IR, ZigBee or both .
  • Page 9 1. Press “Edit System” button in the Program tab Add Delay Add Link 2. Select the KD-ZRC300 remote in the System Designer control tree . The KD-ZRC300 has been named “Zigbee” in the below figure . 3. Expand the Default Hard Buttons hierarchy in the Controller Designer tree 4.
  • Page 10 F. Delays can be added to insert time between each command sent . 6. When completed, KD-ZRC300 remote is ready for use with the KD-MC1000 controller IMPORTANT: Since the default function of the blue Device Select buttons is to simply Figure 1 determine the device that the next button presses will apply to, G.
  • Page 11 Only if you need to upload IR data into Zigbee Remote for line-of-sight control. Add Placeholder to 3 .5mm Stereo jack at KD-ZRC300 Zigbee There are two ways to load IR data into the KD-ZRC300 . Method 1 is the default method and Add Page Jump Remote Control and RS232(COM) port at PC Add IR Command is most convenient .

  • Page 12: Safety Instructions

    Please be sure to follow these instructions for safe operation of your unit. Repairs and Warranty Service 1. Read and follow all instructions . Should your product require warranty service or repair, please obtain a Key Digital ® Return 2. Heed all warnings .
