- Page 1 Installation & Quick Start Guide Aqua PC Range – AquaMedia Version 2 QUICK START Aqua Media PC VR2.00...
-
Page 2: Before You Start
Aqua Media 2 PC Quick Start Guide DIGITAL YACHT LTD 1. Introduction Congratulations on the purchase of your AquaMedia PC. It is recommended that your new computer is installed by a professional installer. Do not disconnect the White wire from the Red on the main power/data cable until you have read and understood the Remote Switch operation (Installation Step 3+4) explained in this Quick Start Guide. - Page 3 Aqua Media 2 PC Quick Start Guide DIGITAL YACHT LTD Installation Step 2 The AquaMedia PC is supplied with four mounting brackets which are screwed (wrong way round) to the base of the AquaMedia PC for transit. Unscrew the brackets, reverse them and screw them back in place. Use suitable fixings (not supplied) to fix the AquaMedia PC to a flat surface –...
- Page 4 Aqua Media 2 PC Quick Start Guide DIGITAL YACHT LTD Installation Step 3 On the rear of the AquaMedia PC is a single black cable that has three wires. This is the Power cable. Connect the Red (+) and Black (-) wires in the Power cable to the ship’s 12v or 24v supply.
- Page 5 Aqua Media 2 PC Quick Start Guide DIGITAL YACHT LTD To connect a remote power switch for the AquaMedia PC, at another location in the boat, simply remove the white wire from the red wire and connect the white wire to the ship’s supply (+12v or +24v) via a SPST toggle switch as shown below.
